DEVICE DESCRIPTION: The SHOUT nano comprises a touchscreen, a Power/Enter button, an LED Status Display, a
guarded Emergency button, navigation buttons, and a USB mini port.
IMPORTANT: The SHOUT nano must have a clear view of the sky during transmission.
Iridium Antenna
LED Status Display
Touchscreen
Up Nav Button
Check-In Soft Key
Left Nav Button
Down Nav Button
SHOUT nano QUICK START GUIDE
GPS Antenna
(embedded)
Power/Enter Button
Rotating Guard
Device Status
USB Mini Port
Emergency Button
Way Point Soft Key
Right Nav Button
Support Phone#: 571-833-2169
Support@Nalresearch.com
451-92681-003
2023-03-31
1
Advertisement
Table of Contents
Related Manuals for NAL RESEARCH CORPORATION SHOUT nano
Summary of Contents for NAL RESEARCH CORPORATION SHOUT nano
- Page 1 451-92681-003 2023-03-31 DEVICE DESCRIPTION: The SHOUT nano comprises a touchscreen, a Power/Enter button, an LED Status Display, a guarded Emergency button, navigation buttons, and a USB mini port. IMPORTANT: The SHOUT nano must have a clear view of the sky during transmission.
- Page 2 SHOUT nano QUICK START GUIDE Support Phone#: 571-833-2169 Support@Nalresearch.com 451-92681-003 2023-03-31 DEVICE STATUS SYMBOLS: Device status symbols are displayed along the top three lines of all screens. Some symbols do not appear until an event is initiated, such as sending or receiving a message.
- Page 3 911 EMERGENCY The red 911 emergency button is located underneath a rotating guard on the back of the SHOUT nano. Activate 911 Emergency: Press the 911 Emergency button on the device. The Status device bars turn red and the LED status display turns solid green.
- Page 4 A Power-down Screen appears. Press Turn Off to turn off the SHOUT nano. Press Lock to go back to the power-up screen, or press Cancel to return to the previous screen.
- Page 5 SHOUT nano QUICK START GUIDE Support Phone#: 571-833-2169 Support@Nalresearch.com 451-92681-003 2023-03-31 MESSAGES Check Messages Select Messaging from the Home screen. Select Inbox from the Messaging screen. • Read messages have a white opened envelope symbol next to them. •...
- Page 6 451-92681-003 2023-03-31 CHARGING BATTERY Fully charge the SHOUT nano before use. The SHOUT nano must be kept in environments between 0°C (32°F) and 45°C (113°F) when charging. When charging is complete, the icon displays five bars (not counting the last battery icon.
