- Page 1 451-22013-001A SHOUT nano 100 User Guide Version A May 30, 2023 Copyright © 2023 by NAL Research Corporation 11100 Endeavor Ct., Suite 300 Manassas, Virginia 20109 USA Phone: 703-392-1136 Email: contact@nalresearch.com...
- Page 2 ISCLAIMER AND ONDITION OF This document contains information for the SHOUT nano 100 tracker and accompanying accessories (“Product”), which is provided “as is.” Reasonable effort has been made to make the information in this document reliable and consistent with specifications, test measurements and other information.
- Page 3 SHOUT nano 100 User Guide Version A EVISION ISTORY Revision Date Description 04/30/2023 Formal Release EFERENCE OCUMENTS The latest revisions of the NAL documents are available by request via email. Support@nalresearch.com. Reference Title Revision/Date Revision A, AT Commands for Model SHOUT nano 100...
-
Page 4: Table Of Contents
Encryption ........................... 21 Remote Updates ......................... 22 Pairing the SHOUT nano 100 ..................23 Pairing the SHOUT nano 100 to Android Device (Without SatTerm) ......... 23 Pairing the SHOUT nano 100 With SatTerm ............... 23 SHOUT App Overview ....................24 Using the SHOUT nano 100 ....................25... - Page 5 C.1.2: Direct Internet Connection ....................37 C.1.3: RUDICS Data ........................38 C.1.4: Short Burst Data........................38 C.1.5: Short Messaging Service ..................... 39 C.2: Iridium Geolocation ....................... 39 Appendix D: SHOUT nano 100 Design Specifications .............41 Document Number: 451-22013-001A 5 of 44...
- Page 6 Appendix E: SHOUT nano 100 Mechanical Drawing ...............44 ABLE OF IGURES Figure 1: SHOUT nano 100 External Components ................10 Figure 2: SHOUT nano 100 Accessories ................... 11 Figure 3: Emergency 911-Activate ....................12 Figure 4: Emergency 911-Status Symbol Field ................. 13 Figure 5: USB Connector Port ......................
- Page 7 SHOUT nano 100 User Guide Version A CRONYM AES ......Advanced Encryption Standard API ......Application programming interface AT .......Attention BATT ......Battery BIS ......Bureau of Industry and Security BLE ......Bluetooth Low Energy BT .......Bluetooth CE .......Conformité Européenne CRUD ......create, read, update, and delete DAV ......Data After Voice...
- Page 8 SHOUT nano 100 User Guide Version A LEO ......Low-Earth Orbit MMC ......Mission Management Center NIST ......National Institute of Standards and Technology NOAA ......National Oceanic and Atmospheric Association NOC ......Network Operations Center NORTHCOM ....Northern Command OFAC ......Office of Foreign Asset Controls PMS ......PECOS Message Structure...
-
Page 9: Introduction
OLED display and embedded antennas. The SHOUT nano 100 can send Short Burst Data (SBD) messages over the Iridium satellite network in NAL Research’s defined report formats compatible with NAL 9602-LP, 9602-AB, A3LA series modems, and SHOUT series tracking devices. -
Page 10: Device Description
Geofencing features to reduce reporting frequency when a platform is not in motion or is outside an area of interest. In addition to normal tracking, the SHOUT nano 100 also has a real-time clock allowing power-up delay as well as scheduled daily Call Outs. -
Page 11: Accessories
SHOUT nano 100 User Guide Version A CCESSORIES AC Wall Adapter USB-A to USB-C Cable Figure 2: SHOUT nano 100 Accessories Document Number: 451-22013-001A 11 of 44... -
Page 12: User Interfaces
NTER UTTON The SHOUT nano 100 has a single power ON/OFF button (see Figure 1). The SHOUT nano 100 can be turned off and on again by momentarily holding down the Power button for two seconds and releasing it. If the device is sleeping, press the Power/Enter button for two (2) seconds to wake up/turn on the SHOUT nano 100. -
Page 13: Usb-C Connector Port
Figure 5: USB Connector Port The SHOUT nano 100 USB-C connector port is located on the left side of the chassis, as shown in Figure 5. This connector has a rubber O-ring sealed cover required to achieve the IP67 rating of the device. -
Page 14: Dc Power Inputs
LUETOOTH The SHOUT nano 100 utilizes a Bluetooth Low Energy (BLE) transceiver to provide a secondary command interface path alternative to the USB-C connector port. Like the USB port, this interface can connect with SatTerm running on a Windows® PC. You can also establish a Bluetooth connection with a Bluetooth enabled Android device running the SHOUT nano 100 App (see section 5.1 Pairing the SHOUT nano 100 to Android Device). -
Page 15: Initial Setup
Home screen displays (see Figure 6). Figure 6: Home Screen NOTE: If the device is not used for 10 minutes, the SHOUT nano 100 enters sleep mode. The SHOUT nano 100 can be removed from the sleep mode by pressing the Power / Enter button for two (2) seconds. -
Page 16: Charge Device
The SHOUT nano 100 ships with a partially charged battery. Before use, charge the SHOUT nano 100 for one (1) hour. NOTE: Upon battery depletion, the SHOUT nano 100 should reach full charge within three (3) hours when continuously plugged in. -
Page 17: At Command Mode
“+++”. If “+++” is not entered within 10 seconds, the SHOUT nano 100 goes back to sleep. See section 4.2 Modes of Operation for a more detailed description of the command mode, and see the NAL document AT Commands for SHOUT nano 100 [1] for a full list of the AT command capabilities. -
Page 18: Important Features
ODES OF PERATION The SHOUT nano 100 is always in one of two modes: (1) command mode or (2) tracking mode. It can be configured to turn on in one of these modes. The factory-set Start-up Mode is tracking mode, which can be changed using the ^START command. For normal operational tracking scenarios, set the Start-Up Mode to tracking mode so that the unit continues tracking after waking up from sleep. -
Page 19: Command Mode
[1]. Use the commands to configure the SHOUT nano 100 operating parameters, to allow the SHOUT nano 100 be operated as a modem, and to query the GNSS receiver. Command mode can be switched to tracking mode by the AT command ^TRK. To switch back, use the escape sequence +++. -
Page 20: Call-Outs And Turn-On Delay
100 enters or exits a geofence. Priorities are assigned to the different stimuli and the SHOUT nano 100 only switches to the associated tracking profile if it has a higher priority. Emergency tracking has the highest priority, Geofence is the second highest, and normal tracking is the default. -
Page 21: Geofencing
Refer to the SatTerm for SHOUT nano 100 Manual [5]. A geofence is defined by a minimum of three (3) coordinates and a maximum of 50. Multiple geofences can be configured, each with a unique set of tracking parameters that cause the SHOUT nano 100 to change its tracking behavior while in a specific geofence. -
Page 22: Remote Updates
(refer to the SatTerm for SHOUT nano 100 Manual [5]. NAL Research provides two software applications that can be used to compose and transmit remote updates: Server for Trackers and Remote Configure. -
Page 23: Pairing The Shout Nano 100
SHOUT nano 100 User Guide Version A SHOUT AIRING THE NANO This section provides instructions on how to pair a SHOUT nano 100. The SHOUT nano 100 can be paired to a device with or without the SatTerm application. SHOUT AIRING THE... -
Page 24: Shout App Overview
6 SHOUT A VERVIEW The SHOUT nano 100 can communicate with an Android device by running the SHOUT App. The SHOUT App, developed by NAL Research, is available for download from the Google Play Store. This Android application provides all the capabilities of the display screens seen on other NAL Research tracking devices such as the SHOUT nano, and SHOUT ts. -
Page 25: Using The Shout Nano 100
SING THE NANO CREEN Immediately after it is powered up, the SHOUT nano 100 momentarily displays the NAL Research logo followed by the Home screen, as shown in Figure 9. Figure 9: Home Screen The Home screen menu displays the following functionalities: ... -
Page 26: Status Symbols
SHOUT nano 100 User Guide Version A TATUS YMBOLS Table 1: Status Symbols Denotes the Iridium transceiver is off. The Iridium transceiver is always kept off to preserve battery life, until a message is required to be transmitted. Denotes: (1) the Iridium transceiver is on with real-time signal strength represented by the number to the right of the hash tags. -
Page 27: Canned Messages
SHOUT nano 100 User Guide Version A A Recv’d message associated with the selected message displays. Scroll down to view the entire message (tracking data). 7.3.2 ANNED ESSAGES Select Messaging>Canned Msgs. The Canned Msgs window displays. Select the applicable canned message (report). -
Page 28: Check Mailbox Rate
SHOUT nano 100 User Guide Version A 7.4.3 HECK AILBOX Select Configuration>Chk Mbx Rate. The Check Mailbox Rate window displays. The current check mailbox rate displays at the top of the window. Select (scroll for) the desired mailbox rate. 7.4.4 ONTRAST Select Configuration>Contrast. -
Page 29: Sanitize
SHOUT nano 100 User Guide Version A 7.5.1 ANITIZE Select Sanitize. This resets the device to default factory settings and also clears all memory and encryption keys. A Confirmation window displays. Select Sanitize. 7.5.2 RASE ESSAGES Select Erase All Msgs. -
Page 30: Enable Bt Pairing/ Passkey
A white Bluetooth icon indicates the SHOUT nano 100 is Bluetooth enabled. A green icon indicates the SHOUT nano 100 is connected to a Bluetooth Android device. The Unit Info function displays the following data on the device: IMEI, APP firmware version, power firmware version, boot firmware version, and Iridium firmware version. -
Page 31: Technical Support
SHOUT nano 100 User Guide Version A ECHNICAL UPPORT For technical support, please contact us at: Phone: 571-833-2169 Email: support@nalresearch.com Technical documents are also available to download on NAL Research’s website www.nalresearch.com. Document Number: 451-22013-001A 31 of 44... -
Page 32: Appendix A: Standards Compliance
TANDARDS OMPLIANCE The Iridium 9603 transceiver inside the SHOUT nano 100 is designed to meet the regulatory requirements for approval for the Federal Communications Commission (FCC), Canada, and Conformité Européenne (CE), assuming an antenna with a gain of approximately 3 dBic and adequate shielding. -
Page 33: Appendix B: Export Compliance
XPORT OMPLIANCE The SHOUT nano 100 is controlled by the export laws and regulations of the United States of America (USA). It is the policy of NAL Research to fully comply with all U.S. export and economic sanction laws and regulations. The export of NAL Research products, services, hardware, software and technology must be made only in accordance with the laws, regulations and licensing requirements of the U.S. -
Page 34: Appendix C: The Iridium Network
SHOUT nano 100 User Guide Version A C: T PPENDIX RIDIUM ETWORK The Iridium satellite network is owned and operated by Iridium Communications Inc. It is constructed as a constellation of 66 satellites in low-earth orbit (LEO), terrestrial gateways, and Iridium subscriber units (ISUs). -
Page 35: C.1: Iridium Network Data Capabilities
SHOUT nano 100 User Guide Version A beams are shut down. The satellite footprint is approximately 4,700 km in diameter. Under each footprint, a satellite is power-limited to approximately 1,100 simultaneous circuits. The Iridium network uses a time division duplex (TDD) method and transmits and receives in an allotted time window within the frame structure. -
Page 36: C.1.1: Dial-Up Data Service
SHOUT nano 100 User Guide Version A Figure 11: Iridium Network Data Capabilities C.1.1: D ERVICE Dial-up data service provides connectivity through the Iridium satellite network to another Iridium modem, to the PSTN, to the Defense Switch Network (DSN), to a remote LAN (e.g., a corporate network), or to an internet service provider (ISP) at a nominal data rate of 2.4 kilobits... -
Page 37: C.1.2: Direct Internet Connection
SHOUT nano 100 User Guide Version A modem actually dials and initiates a connection with the Iridium gateway through the Iridium satellite constellation. Because the Iridium modem is requesting to establish a data connection, the switch at the gateway routes the call through another modem. The modem at the Iridium gateway then dials into and connects to another modem at the other end. -
Page 38: C.1.3: Rudics Data
SHOUT nano 100 User Guide Version A internet and optimizes server-to-Iridium modem communications. The dial-up networking setup is similar to the dial-up networking setup for a landline telephone. The only difference is that the dialed telephone number is an international number provided by Iridium. Figure 12 illustrates how an Iridium internet call is routed. -
Page 39: C.1.5: Short Messaging Service
SHOUT nano 100 User Guide Version A and internet) to servers and applications that process data from one or multiple fielded Iridium modems. SBD service also supports the transfer of messages to Iridium modems, where messages may originate from terrestrial sources. Delivery methods and options are initially configured when the Iridium modem is first purchased and may be easily modified via webpages at a later time. - Page 40 SHOUT nano 100 User Guide Version A The Iridium network can locate an ISU to within 10 km only about 78% of the time. The so- called error ellipse can have a large eccentricity with the major axis oriented in the azimuth dimension and the minor axis oriented in the radial dimension.
-
Page 41: Appendix D: Shout Nano 100 Design Specifications
PECIFICATIONS D.1: M ECHANICAL PECIFICATIONS Dimensions – SHOUT nano 100: ........76 x 46 x 18 mm (3.3” x 1.8” x 0.7”) Weight – SHOUT nano 100: ........85 g (3.0 oz.) Enclosure Material: ............Hard ABS plastic Interface Connector: ..........USB-C receptacle Antennas: ..............Embedded Iridium, GNSS, and Bluetooth ON/OFF and Arrow buttons: ........Dome push buttons... -
Page 42: Bluetooth Rf Specifications
Velocity: 500 m/s (1,640 feet/second) Dynamics: ≤ 4 g As long as power is provided to the SHOUT nano 100, the GNSS receiver provides real-time clock functionality and stores ephemeris data in its memory before turning off (sleeping between reports). The ephemeris data are valid up to two hours and can be used in future startup to improve time-to-first-fix. -
Page 43: Related Hardware
SHOUT nano 100 User Guide Version A Software Interface: ............AT commands via USB D.8 R ELATED ARDWARE AC Power Adapter: .............LA-3098 (100–240 VAC, 47–60 Hz input) 12 V Car Adapter: ............LA-7021 (12 VDC car battery input)) Document Number: 451-22013-001A 43 of 44... -
Page 44: Appendix E: Shout Nano 100 Mechanical Drawing
SHOUT nano 100 User Guide Version F E: SHOUT 100 M PPENDIX NANO ECHANICAL RAWING Figure 13: SHOUT nano 100 Mechanical Drawing Document Number: 451-01037-001F 44 of 44...
