- Page 1 Dual Monitor + Laptop Desk Stand SKU: STAND-V003FGL Instruction Manual Assembly Video & Product Info www.vivo-us.com/products/stand-v001fgl...
- Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
-
Page 3: Package Contents
Package Contents A (x1) B (x1) C (x1) D (x3) Lower Pole Upper Pole Single Arm VESA Plate F (x1) G (x1) H (x1) E (x1) Base Laptop Tray Upper Mounting Plate Dual Arm I (x1) J (x1) K (x1) L (x5) Lower Mounting Plate Cover... -
Page 4: Assembly Steps
ASSEMBLY STEPS STEP 1 Attach Upper Mounting Plate (H) to the non-threaded end of Lower Pole (A) using M6x16mm Flat Head Screws (S-C) and 4mm Allen Wrench (T-B) Press the Raised Threads on Lower Mounting Plate (I) into the holes on Upper Mounting Plate. S-C (x3) Raised Threads... - Page 5 STEP 2 Remove the protective film from Foot Pads (N) and adhere to the corners on the underside of Base (F) Slide Cover (J) onto Lower Pole (A) to and press to lock into holes on Upper Mounting Plate (H) STEP 3 Slide Pole Clip (M) and Single Arm (C) onto Lower Pole (A) Secure Single Arm at desired...
- Page 6 STEP 3.2 Thread Upper Pole (B) secure into Lower Pole (A) Slide Dual Arm (E) onto the Upper Pole. Secure Single Arm at desired height by tightening the Locking Screw with 5mm Allen Wrench (T-C). Press Pole Cap (K) into the top of Upper Pole. Locking Screw Attach the Cable Clips...
- Page 7 STEP 4 Install one VESA Plate (D) onto the back of Laptop Tray (G) using M4x8mm Flat Head Screws (S-A) and 4mm Nuts (S-B). Tighten using Wrench (T-D) and a Phillips screwdriver. Assembly Tip: VESA Plate should be installed on the back side of the Tray, with the pointing towards the bottom.
- Page 8 STEP 5 Install remaining VESA Plates (D) onto your monitors using M4x12mm Thumbscrews (M-A) or M4x30mm Screws (M-B), and Spacers (M-C). Tighten using a Phillips screwdriver, being careful not to overtighten screws. Assembly Tip: VESA Plate should be installed with V pointing towards the bottom of monitor.
- Page 9 STEP 6 Slide your monitors onto Dual Arm (E) and secure using M6 Cap Nuts (S-F). S-F (x2) STEP 7 Manage cables using Cable Clips (L) and Pole Clip (M).
- Page 10 STEP 8 Adjust the tilt joint resistance using 5mm Allen Wrench (T-C). Adjust the height of VESA plate locations using 3mm Allen Wrench (T-A).
- Page 11 STEP 8.2...
-
Page 12: Last Updated
LAST UPDATED: 10/30/23 REV1 v1.0 Need Help? Get In Touch Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303 Chat live with an agent! FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us...
