Pneumatic Arm Dual Monitor and Laptop Desk Mount
Instruction Manual
SKU: STAND-V003KL
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v003kl
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-V003KL
Summary of Contents for Vivo STAND-V003KL
- Page 1 Pneumatic Arm Dual Monitor and Laptop Desk Mount Instruction Manual SKU: STAND-V003KL Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v003kl GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Assembly Steps
ASSEMBLY STEPS STEP 1 Loosen the screws on Clamp (F) using the 4mm Allen Wrench (T-A) and seperate into Upper Clamp (F1) and Lower Clamp (F2). STEP 2 OPTION A: Clamp Installation OPTION B: Grommet Base Installation Assemble Upper Clamp (F1) to Pole (E) using the Cut Soft Pad (J) along the indentations. - Page 4 STEP 2 (Continued) OPTION A: Clamp Installation OPTION B: Grommet Installation For thinner desktops, re-attach Lower Clamp (F2) Using a 10mm (⅜”) drill bit, drill through the to Upper Clamp (F1) and tighten the screws using desktop at least 2” away from the edge. the 4mm Allen Wrench (T-A).
- Page 5 STEP 4 Loosen the screw on the back of Dual Arm (A) and Arm (B) using 6mm Allen Wrench (T-B). Slide Dual Arm (A) and Arm (B) onto Pole (E) and retighten screws. Secure Cable Clip (L) to Pole (E). STEP 5 Place Laptop Arms (G) underneath each side of Laptop Tray (C), aligning square holes in arms with the edge and long slot oneach side.
- Page 6 STEP 8 Attach VESA Plates (D) to the back of the monitors using Screws (M-A through M-D) and Washers (M-E). If needed, use Spacers (M-F). STEP 9 Slide VESA Plates (D) with monitors over bracket on Dual Arm (A). Secure using Thumbscrews (S-C). Release locks on underside of Laptop Arms (G).
- Page 7 STEP 10 Remove bottom covers from Dual Arm (A) and Arm (B) by sliding them off. Organize cables and re-attach covers. STEP 11 Adjust tilt support using 6mm Allen Wrench (T-B). Store Allen Wrenches (T-A and T-B) in Cable Clip (L). Adjust as desired.
- Page 8 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
