Triple Monitor Desk Mount
Instruction Manual
SKU: STAND-V003Y
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v003y
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-V003Y
Summary of Contents for Vivo STAND-V003Y
- Page 1 Triple Monitor Desk Mount Instruction Manual SKU: STAND-V003Y Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v003y GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Tools Needed
TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 15.4 lbs Failure to do so may result in serious injury. (7 kg) PER ARM Phillips Screwdriver ASSEMBLY STEPS STEP 1 Attach pole cap (G) to top of pole (D). STEP 2 OPTION A: Clamp Installation Mount pole (D) to clamp (C) with bolts (J) using 4mm Allen Key (L). - Page 4 STEP 2 (Continued) OPTION B: Grommet Base Installation Remove screw from clamp bolt, and remove clamp bolt from clamp (C). Align pin on top of grommet base (F) with the small hole on the bottom of pole (D), position over hole in desktop, and install to desktop using clamp bolt and grommet plate (K). STEP 3 Install swivel arms (B) and cable clip (E) to pole (D).
- Page 5 STEP 4 For flat back monitor, install VESA Plate (A) to monitor using bolts (M-A or M-C) and washers (M-E). For curved back monitor, install VESA Plate (A) to monitor using bolts (M-B) or (M-D), washers (M-E), and spacers (M-F). For curved back monitor, install VESA Plate (A) to monitor using bolts (M-B or M-D) and washers (M-E), and spacers (M-F).
- Page 6 STEP 6 Manage the cables using the installed cable clips. STEP 7 Store the Allen Keys in cable clip (E) for future use.
- Page 7 STEP 8 Be careful not to extend the arms too far forward or backward. STEP 9 Adjust monitor alignment using 5mm Allen Key (M). +45° 360° -45° 360° +45° 360° -45°...
- Page 8 - 92% within < 3hr www.vivo-us.com : < 15 M AVG. RESOLUTION TIME (within office hrs) Chat live with an agent! : 5M 4S 309-278-5303 AVG. RESOLUTION TIME (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
