Tunnel Gateway LED Indicators
7. Tunnel Gateway LED Indicators
Tunnel Gateway
SP3196 Version 1.0
LED Operation
Indicator Status
LED A N/A
LED B N/A
LED C N/A
Status Off
Green
Green, blink
Power Green
Off
®
Anybus Tunnel Gateway
Description
For future use.
For future use.
For future use.
Reset/Reboot function is inactive.
Reboot function is active.
Factory reset function is active.
Tunnel Gateway is powered.
Tunnel Gateway is not powered.
