Connect to Power

Power Connector Pinout

Power port
Procedure
Figure 4. Connect to power
SP3196 Version 1.0
Anybus
Pin
Description
1
Voltage Common Collector
(VCC)
24 VDC
2
Ground (GND)
3
Functional Earth (FE)
®
Tunnel Gateway
Page 11 of 20
