Connect Ethernet Devices
Ethernet RJ45 Connector Pinout
Ethernet RJ45 Connector
SP3196 Version 1.0
Pin
1
2
3
4
5
6
7
8
®
Anybus
Tunnel Gateway
Description
TD+
TD-
RD+
Not used
Not used
RD-
Not used
Not used
