Login to the Built-In Web Interface
5.3. Login to the Built-In Web Interface
The Tunnel Gateway built-in web interface can be accessed from a standard web browser.
Before You Begin
IMPORTANT
For cybersecurity reasons, you are prompted to change the password at
first login using the Tunnel Gateway factory default password. You are
redirected to the Change password page, see
Password.
NOTE
The Tunnel Gateway comes with a default password. You find the default
password on the Tunnel Gateway product housing.
NOTE
The Tunnel Gateway default IP address is 192.168.1.96 and the subnet
mask is 255.255.255.0.
Procedure
Login to the Tunnel Gateway built-in web interface:
1. Open a web browser.
2. Click to select the Address bar and enter https:// and the Tunnel Gateway IP address.
Figure 7. Enter IP address in web browser
3. Press Enter.
