superbrightleds EL3-SW User Manual

Important: Read all instructions prior to installation. SAVE THESE INSTRUCTIONS.
LED Emergency Light
Warning
Read and follow all safety instructions. When using
electrical equipment, basic safety precautions should
always be followed including the following:
• Disconnect power before performing work on
electrical equipment.
• For indoor use only.
• Do not let the power cords touch hot surfaces.
• Do not install in hazardous locations or near gas or
electric heaters.
• The use of auxiliary equipment not recommended
by manufacturer, may cause and will void the unit's
warranty.
• Do not use this equipment for other than its intended
purpose.
• Servicing of this equipment should be performed by a
qualified service technician
• All electrical connections should be made in
accordance with National and Regional electrical
code.
• Equipment should be mounted in locations and
heights where it will not readily be subjected to
tampering by unauthorized personnel.
• Allow battery to charge for 24 hours before first use.
• Unused wires must be capped.
Important Safeguards
Battery in this unit may not be fully charged at the time
electrical connection is made. Let the battery charge for
at least 24 hours for normal operation. To check charge,
press the "test" button.
¹Limited 2-year warranty on battery.
EL3-SW
N/C RED
120 V POWER BLACK
NEUTRAL WHITE
¹
Specifications
Battery Type
Operating Temperature
Check product label for specific electrical
specifications related to installation.
Improper installation will void warranty.
Wiring Diagram
Supply Power
(120 VAC)
Supply Power
(277 VAC)
Testing
Manual Test
Test button can be held to illuminate lights for manual testing
purposes.
Rev Date: V1 04/14/2023
4400 Earth City Expy, St. Louis, MO 63045
User Manual
EL3-SW
EL3-SW
3.6 V 1000mAh Ni-Cd
32°–104° F (0°–40° C)
N/C RED
120 V POWER BLACK
NEUTRAL WHITE
277 V POWER RED
N/C BLACK
NEUTRAL WHITE
866-590-3533 superbrightleds.com
