BARRON TRACE-LITE SLW Series Installation Instructions Manual

BARRON TRACE-LITE SLW Series Installation Instructions Manual

Advertisement

Quick Links

SLW Series
Installation Instructions
READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
When using electrical equipment, basic safety precautions should always be followed including the following:
• DISCONNECT AC POWER SUPPLY BEFORE SERVICING.
• Installation and servicing of this equipment should be performed by qualified service personnel only.
• Ensure that the electrical wiring conforms to the National Electrical Code NEC® and local regulations
if applicable.
• Do not mount near gas or electrical heaters.
• Do not use outdoors.
• Equipment should be mounted in locations and at heights where it will not be readily subjected to tampering
by unauthorized personnel.
• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
• Any modification or use of non-original components will void the warranty and product liability.
• Do not use this equipment for other than intended use.
• Allow battery to charge for 24 hours before first use.
• For use with metal enclosed wiring systems.
20070101 REV 8 - 08/24
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS!
Technical Support
■ (623) 580-8943 ■ technicalsupport@barronltg.com
1
800-533-3948 www.barronltg.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the TRACE-LITE SLW Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BARRON TRACE-LITE SLW Series

  • Page 1 SLW Series Installation Instructions IMPORTANT SAFEGUARDS READ AND FOLLOW ALL SAFETY INSTRUCTIONS. When using electrical equipment, basic safety precautions should always be followed including the following: • DISCONNECT AC POWER SUPPLY BEFORE SERVICING. • Installation and servicing of this equipment should be performed by qualified service personnel only. •...
  • Page 2 SLW Series Installation Instructions Wall Mount Installation (Fig. 3) Fig. 1 1. Insert a flat blade screwdriver into the two slots to remove front cover from backplate. (Fig. 1). 2. Remove knockout from center of backplate and route wires through the hole.
  • Page 3: Wiring Diagrams

    SLW Series Installation Instructions Wiring Diagrams Fig. 5 Fig. 6 Operation The battery in this unit may not be fully charged. After electricity is connected to the unit for at least 24 hours, then normal operation of this unit should take effect. To check, press the “TEST” button. The EXIT sign should stay illuminated by battery backup and the LED indicator will be turned off.
  • Page 4 SLW Series Installation Instructions Networking Operations for “-G3/G3PRO” Models Model with "-G3/G3PRO" suffix is our world winning design equipped with "wireless testing and reporting" features. Unit that has "-G3/G3PRO" suffix in its model number is capable of joining Guardian G3 emergency lighting management system.
  • Page 5 SLW Series w/EM Installation Instructions IMPORTANT SAFEGUARDS READ AND FOLLOW ALL SAFETY INSTRUCTIONS. When using electrical equipment, basic safety precautions should always be followed including the following: • DISCONNECT AC POWER SUPPLY BEFORE SERVICING. • Installation and servicing of this equipment should be performed by qualified service personnel only. •...
  • Page 6 SLW Series w/EM Installation Instructions Wall Mount Installation (Fig. 3) Fig. 1 1. Insert a flat blade screwdriver into the two slots to remove front cover from backplate. (Fig. 1). 2. Remove knockout from center of backplate and route wires through the hole.
  • Page 7 SLW Series w/EM Installation Instructions Convert Unit Control from Photosensor to Wall Switch 1. Slide the switch away from the driver to convert photosensor to wall switch. (Fig. 4) 2. Remove jumper, connect wall switch on terminal 1 and 2. (Fig. 6) If jumper cable is left in terminal block, fixture will always turn on under normal supply.
  • Page 8 SLW Series w/EM Installation Instructions 3. “-G2” and “-G3/G3PRO” models also have a manual test function, press test button as follows: Press test button once (within 2 seconds) 30 seconds discharge test Press test button twice (within 2 seconds) 3 minutes discharge test Press test button 3 times (within 2 seconds) 30 minutes discharge test Press test button 4 times (within 2 seconds)
