SCL Series
Installation Instructions
READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
When using electrical equipment, basic safety precautions should always be followed including the following:
• DISCONNECT AC POWER SUPPLY BEFORE SERVICING.
• Installation and servicing of this equipment should be performed by qualified service personnel only.
• Ensure that the electrical wiring conforms to the National Electrical Code NEC® and local regulations, if
applicable.
• Do not mount near gas or electrical heaters.
• Do not use outdoors.
• Equipment should be mounted in locations and at heights where it will not be readily subjected to tampering by
unauthorized personnel.
• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
• Any modification or use of non-original components will void the warranty and product liability.
• Do not use this equipment for other than intended use.
• Allow battery to charge for 24 hours before first use.
10070159 REV 8 - 08/22
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS!
Technical Support
■ (623) 580-8943 ■ technicalsupport@barronltg.com
1
800-533-3948 www.barronltg.com
Advertisement
Related Manuals for BARRON EXITRONIX SCL Series
Summary of Contents for BARRON EXITRONIX SCL Series
- Page 1 SCL Series Installation Instructions IMPORTANT SAFEGUARDS READ AND FOLLOW ALL SAFETY INSTRUCTIONS. When using electrical equipment, basic safety precautions should always be followed including the following: • DISCONNECT AC POWER SUPPLY BEFORE SERVICING. • Installation and servicing of this equipment should be performed by qualified service personnel only. •...
-
Page 2: Installation
SCL Series Installation Instructions Installation Fig. 1 1. Remove the (2) 6-32 X 1/4” screws (A) securing the front cover and set aside. (Fig. 1) 2. Slide the front cover (B) forward and flip down. (Fig. 2a, b) 3. Stem mount option: a. - Page 3 SCL Series Installation Instructions Installation, Continued Fig. 6 Orange 4. Remove the desired knockouts on the back of the enclosure (for 277V) and mount to the J-box using the hardware supplied with the J-box. Green (Ground) 5. Make electrical connections. All electrical connections should be made inside the J-box.
- Page 4 SCL Series Installation Instructions Self-Test/Self-Diagnostics (G2) with LED Indicator I M P O R T A N T: Once all emergency lamps have been connected to the unit equipment, apply normal AC power and charge for 48 hours. For units equipped with G2 and the tri-color LED indicator: Following installation and after AC power has been supplied, charge for 48 hours, then press and hold the test button until the LED indicator turns orange.
