BARRON Exitronix LED-90 Series Installation Instructions

READ CAREFULLY AND FOLLOW ALL INSTRUCTIONS FOR YOUR OWN SAFETY
• DISCONNECT AC POWER SUPPLY BEFORE SERVICING.
• Installation and servicing of this equipment should be performed by qualified service personnel only.
• Ensure the electricity connections conform to the National Electrical Code and local regulations if applicable.
• Do not mount near gas or electrical heaters.
• Equipment should be mounted in locations and at heights where it will not readily be subjected to tampering by
unauthorized personnel.
• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition. Any
modification or use of non-original components will void the warranty and product liability.
• Do not use this equipment for other than intended use.
JUNCTION BOX / WALL CEILING MOUNT
1. Remove backplate by pushing through the two tabs at the bottom using a narrow screwdriver.
2. Feed fixture leads through backplate.
3. All Electical connections should be made inside junction box.
Make Electrical Connections as follows:
120V AC
White - Common
Black - 120V
Green - Ground
Note: Cap unused leads to prevent shorting.
4. Mount backplate to junction box using hardware provided with junction box.
5. Connect battery only after continuous AC power can be provided to the unit.
6. Align tabs and push housing directly onto backplate.
10070145 Rev 1 - 03/14
SAVE THESE INSTRUCTIONS!
INSTALLATION INSTRUCTIONS
277V AC
White - Common
Orange - 277V
Green - Ground
INSTALLATION INSTRUCTIONS
1
LED-90 SERIES
Use Flexible Conduit Only.
800.533.3948 • www.barronltg.com
