BARRON EXITRONIX ILX Series Installation Instructions

READ CAREFULLY AND FOLLOW ALL INSTRUCTIONS FOR YOUR OWN SAFETY
• DISCONNECT AC POWER SUPPLY BEFORE SERVICING.
• Installation and servicing of this equipment should be performed by qualified service personnel only.
• Ensure the electricity connections conform to the National Electrical Code and local regulations if applicable.
• Do not mount near gas or electrical heaters.
• Equipment should be mounted in locations and at heights where it will not readily be subjected to tampering by
unauthorized personnel.
• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition. Any
modification or use of non-original components will void the warranty and product liability.
• Do not use this equipment for other than intended use.
BACK MOUNTING
1. Remove faceplate and set aside.
2. Drill 3/8" hole into the center of the backplate. Drill 1/4" inch hole into the oblong indent on backplate that
corresponds with the junction box being used.
3. Feed leads through center hole and make the proper connections. All Electrical connections should be made inside
junction box.
Make Electrical connection as followed:
120V AC
White – Common
Black – 120V
Green – Ground
Note: Cap unused leads to prevent shorting.
4. Feed excess wire into junction box and secure backplate to junction box using screws provided with junction box.
5. Connect battery only after continuous AC power can be provided to unit. (If Applicable)
6. Snap in arrows to faceplate as required, storing unused arrows in safe place. Then snap faceplate to housing.
10070073 Rev 1 - 03/14
SAVE THESE INSTRUCTIONS!

INSTALLATION INSTRUCTIONS

277V AC
White – Common
Orange – 277V
Green –Ground
1
ILX SERIES
INSTALLATION INSTUCTIONS
800 533.3948 • www.barronltg.com
