- Page 1 Armadillo A ANNEX USER MANUAL...
-
Page 2: Package Contents
Armadillo A USER MANUAL Congratulations on the purchase of the 23ZERO Armadillo A Annex. The Annex attaches directly to an Armadillo A rooftop tent. The annexes are available in 2 sizes, A2 & A3 each made to fit corresponding 23ZERO Armadillo A tents. - Page 3 Armadillo A USER MANUAL • Locate Kedar rope on 2 sides of opening - Fig.3 • Locate rope tracks on underside of Armadillo A tent - Fig.4 Fig.4 Fig.3 • Begin sliding Kedar rope into Armadillo A rope track - Fig.5 •...
- Page 4 Set up ladder as per roof top tent instructions before climbing. • Locate zip slide on annex and attach to zip on Armadillo A tent canopy - Fig.9 • Lift annex to relieve weight from zip and continue zipping with opposite hand - Fig.10 Fig.9...
- Page 5 Armadillo A USER MANUAL • Extend telescopic poles to approx baseboard height and twist to lock • Locate eyelets on annex roof beside each side of entry door and insert pole spigot - Fig.13 • Repeat on other side. Adjust telescopic poles to taut annex - Fig.14 Fig.13...
- Page 6 Armadillo A USER MANUAL Pack up / Folding...
