Installation Manual
JVS-1V (A set including JV-1MD, JV-DV and power supply)
JVS-1F (A set including JV-1MD, JV-DVF and power supply)
JV-1MD (Hands free color video intercom master monitor station)
To installers:
After installation is completed, be sure to hand the
•
accessories to the customer.
NOTE:
The illustrations and images used in this manual may
•
differ from the actual ones.
HTML manual
https://www.aip-info.net/file/manual/j/JV-1MD/JV-
1MD_INS/JV-1MD_INS_EN/content/
Issue date: Dec. 2023 FK2966 Ⓐ 1223 (H1.00) DL GZ 65292
Table of contents
Package contents ............................................. 2
Precautions ....................................................... 2
Part names and functions ............................... 3
Wiring ................................................................ 5
Precautions for wiring .......................................... 5
Wiring diagram and specifications ....................... 6
Before installation ............................................ 7
Precautions for installation ................................... 7
area ..................................................................... 8
Mounting ........................................................... 8
JV-1MD ................................................................ 8
JV-DV ................................................................ 10
JV-DVF .............................................................. 11
After installation ............................................. 11
Check after installation....................................... 11
Installer settings ................................................. 12
Privacy notice ................................................. 12
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Aiphone JVS-1V
Summary of Contents for Aiphone JVS-1V
-
Page 1: Table Of Contents
Issue date: Dec. 2023 FK2966 Ⓐ 1223 (H1.00) DL GZ 65292 Installation Manual JVS-1V (A set including JV-1MD, JV-DV and power supply) JVS-1F (A set including JV-1MD, JV-DVF and power supply) JV-1MD (Hands free color video intercom master monitor station) -
Page 2: Note
✔ ✔ (PS-2420UL, PS-2420-O, This may result in fire or electrical shock. PS-2420DM, PS-2420S or Do not use the power supply other than Aiphone PS-2420BF) (*) specified. This may result in fire or malfunction. Nameplate (×2) ✔ ✔... -
Page 3: Part Names And Functions
CAUTION Part names and functions Negligence could result in injury to people or damage to property. Do not install or connect the product with the Master monitor station (JV-1MD) power on. This may result in electrical shock or malfunction. Make sure the wiring is correct and there are no wiring shorts before switching on the product. - Page 4 Notification LED Door station Refer to the "Operation Manual" for other indicators not listed. Description Blue light Blue LED is lighting during startup. Blue LED is lighting when the ringtone volume is set to "0". Blue LED is lighting when talk direction is monitor station to door station.
-
Page 5: Wiring
How to connect low voltage wires Wiring each other Crimping with a crimp sleeve Precautions for wiring Twist the stranded conductor around the solid conductor at least three times, then crimp them. Cable Use a parallel 2-conductor wiring cable for connection of a video door station. -
Page 6: Wiring Diagram And Specifications
Wiring diagram and specifications NOTE The sequence of terminals in the diagram may differ from the actual product. Also refer to the instructions for each device to be connected. Wiring distance PE Φ0.65 mm (22 AWG): 50 m (165') PE Φ0.8-1.2 mm (20-16 AWG): 100 m (330') PE Φ0.65 mm (22 AWG): 50 m (165') PE Φ0.8-1.2 mm (20-16 AWG): 150 m (490') -
Page 7: Before Installation
Before installation Precautions for installation The monitor station is designed for indoor use only. Do not install at outdoor location. Installing the device in the following locations could cause malfunction: * Locations under direct sunlight (except for door stations) * Locations near heating equipment * Locations subject to liquid, iron filings, dust, oil, or... -
Page 8: Door Station Mounting Positions And Image View Area
Door station mounting positions Mounting and image view area JV-1MD JV-DV, JV-DVF ATTENTION Do not embed the station inside a wall. To prevent malfunction, install the station at least 20 cm (8") away from other devices (e.g., floor heating remote control). - Page 9 Fasten the mounting bracket to the wall with ATTENTION the screws [B] (×2). Be careful not to trap cables between the station When using a 3-gang box, use screws [C] (×4). and the mounting bracket. Be careful not to damage the cable sheath with the mounting bracket.
-
Page 10: Jv-Dv
JV-DV Connect wires to the station [B]. Slide down and then open the terminal cover on Installation video the back of the station, and strip 8 mm (5/16") of https://www.aip-info.net/file/manual/j/JV-1MD/JV-1MD_INS/JV- the wire jacket and insert it into the terminal. If it is 1MD_INS_EN/content/attachments/101959275/101968975.mp4 difficult to insert, press and hold the release button while inserting. -
Page 11: Jv-Dvf
JV-DVF After installation Installation video Check after installation https://www.aip-info.net/file/manual/j/JV-1MD/JV-1MD_INS/JV- 1MD_INS_EN/content/attachments/101959398/101968992.mp4 After installation, check that the system is functioning in accordance with the operation manual. If not operating properly Remove the door station, and then connect it directly to the master monitor station with short, low-voltage wires to check its operation. -
Page 12: Installer Settings
Setting procedure (e.g., setting the Installer settings door release duration) ATTENTION Tap one of the function buttons in standby mode. Be sure to configure the settings according to the connected devices. Otherwise, the station may not The menu screen will be shown. operate properly.
