FK1460
P0109YI
JK-1SD
AUDIO ONLY SUB MASTER STATION
POSTE SECONDAIRE AUDIO
APARATO PRINCIPAL ANEXO AUDIO SOLAMENTE
PARLOFOON-BIJPOST
POSTAZIONE PRINCIPALE SECONDARIA CON SOLO AUDIO
JK-1SD
AUDIO ONLY SUB MASTER STATION
POSTE SECONDAIRE AUDIO
APARATO PRINCIPAL ANEXO AUDIO
SOLAMENTE
PARLOFOON-BIJPOST
POSTAZIONE PRINCIPALE SECONDARIA
CON SOLO AUDIO
INSTALLATION & OPERATION MANUAL
MANUEL D'INSTALLATION ET D'UTILISATION
MANUAL DE INSTALACIÓN Y OPERACIÓN
INSTALLATIE- EN BEDIENINGSHANDLEIDING
MANUALE D'INSTALLAZIONE E USO
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Aiphone JK-1SD
Summary of Contents for Aiphone JK-1SD
- Page 1 FK1460 P0109YI JK-1SD AUDIO ONLY SUB MASTER STATION POSTE SECONDAIRE AUDIO APARATO PRINCIPAL ANEXO AUDIO SOLAMENTE PARLOFOON-BIJPOST POSTAZIONE PRINCIPALE SECONDARIA CON SOLO AUDIO JK-1SD AUDIO ONLY SUB MASTER STATION POSTE SECONDAIRE AUDIO APARATO PRINCIPAL ANEXO AUDIO SOLAMENTE PARLOFOON-BIJPOST POSTAZIONE PRINCIPALE SECONDARIA CON SOLO AUDIO INSTALLATION &...
-
Page 2: Package Contents
The JK-1SD has switches on both sides. Allow at least 5 cm (2") of open space on either side. Allow at least 15 cm (6") of vertical open space from the center of the mounting bracket in order to mount the JK-1SD. - Page 3 2-2 Wiring method, wiring distance Wire the inside units from station-to-station (daisy-chained). JK-DA JK-1SD JK-DV JK-DVF JK-1MED/1MD Ø 0.65 mm 22 AWG Ø 1.0 mm 18 AWG IER-2 50 m 165' 100 m 330' PS-1820 10 m PS18 PS-1810DIN 75 m...
- Page 4 WIRING JK-1MED/1MD JK-1SD Master monitor station Audio only sub master station (To optional units) (AC/DC 24 V, 1.6 A N/O dry closure contact) (Minimum Contact : 100 mV DC, 0.1 mA) DC 18 V Power supply +, - (DC 18 V)
- Page 5 OPERATIONS 6-1 Answering a door call (HANDS-FREE mode, PTT mode) Press CALL button. Instant voice call function Even without answering, door area can be heard with audio (for approx. 45 seconds). Inside sound is not heard outside. The chime tone sounds and incoming audio will be heard. Audio turns off after approx.
-
Page 6: Room-To-Room Communication
6-3 Room-to-room communication Press CALL button to talk with the other person. If the other person presses TALK button, hands free communication A call-in is sent to the master monitor station. is possible. The reply of the other person is not heard. Press and release OFF button to end communication.
