Faults Diagnostic System - Zapi ACE3 User Manual

Flow Chart showing how to use the ALARMS function via the Digital Console.
1) Opening Zapi Display.
2) Press ENTER to go into the General menu.
3) The Display will show:
4) Press ROLL UP or ROLL DOWN button until
PARAMETER CHANGE appears on the display.
5) The Display will show:
6) Press ENTER to go into the ALARMS function.
7) The Display will show the most recent Alarm.
8) Each press of the ROLL UP button brings up
following Alarms. Pressing ROLL DOWN returns to
the most recent.
9) If an Alarm has not occurred, the Display will
show: ALARM NULL.
10) When you have finished looking at the Alarms,
press OUT to exit the ALARMS menu.
11) The Display will ask "CLEAR LOGBOOK?".
12) Press ENTER for yes, or OUT for NO.
13) Press OUT to return to the Opening Zapi
Display.

9.7 Faults diagnostic system

The fault diagnostic system of ACE3 controller is divided into 2 main groups of
faults:
ALARMS: these are the faults which open the power section, which means the
power bridge is opened and, when possible, the LC is opened and EB is applied.
These are faults related to:
- failures in the motor/controller that the power system is not anymore able to
drive the truck
- safety related failures
AFFZP0BA – ACE3 - User Manual
A3MT2B ZP0.12
80V 450A 00000
' % '
' ' '
MAIN MENU
PARAMETER CHANGE
% ' '
% ' '
MAIN MENU
ALARMS
' % '
' ' '
CODE
00005 #02 20°C
% ' '
% ' '
CODE
00007 #03 18°C
' ' '
' % '
CLEAR LOGBOOK?
YES=ENTER NO=OUT
' % ' ' ' '
' ' ' ' % '
' ' '
' % '
