H-SPARTAN-1

Step 1: Connections

Connect included power supply

Step 2: Login to NMS

Connect the NMS port to your PC using an ethernet cable

Open web browser and go to http://192.168.0.188

Step 3: Choose Input

https://thorbroadcast.com

Select

"Encode"

from the

main menu

800-521-8467

SDI

HDMI

ANALOG

DATA NMS

LEDs on the front

panel will indicate

the active input

sales@thorfiber.com

Quick Setup Guide

Choose

Input

Click

"Apply"

Need help?

Do you have a question about the H-SPARTAN-1 and is the answer not in the manual?

Page 1 800-521-8467 sales@thorfiber.com H-SPARTAN-1 Quick Setup Guide Step 1: Connections HDMI ANALOG Connect included power supply Step 2: Login to NMS DATA NMS Connect the NMS port to your PC using an ethernet cable Open web browser and go to http://192.168.0.188...
Page 2 Step 4: Streaming IMPORTANT: TO ACCESS STREAMS, CONNECT DEVICES TO THE DATA PORT USING AN ETHERNET CABLE Select “Streaming” from the main menu Change Protocol to view other options IP Addresses and Port Numbers may be customized Connect to the stream using the appropriate Click “Apply”...
Page 3 Step 5: Backup Configuration IMPORTANT: The H-SPARTAN-1 will automatically save changes to settings, however it is highly Select “Configuration” recommended to make a from the main menu backup file of your configuration Click “Save” Scan for more info: Click “OK”...
