- Page 1 Manual de instalación y uso de la lavadora Manuel d’installation et d’utilisation du lave-linge Manual de instalação e utilização da máquina de lavar roupa Washing machine installation and operation manual...
- Page 2 índice ADVERTENCIAS ESPECIFICACIONES INSTALACIÓN Y MONTAJE USO DEL APARATO Y CONSEJOS PRÁCTICOS MANTENIMIENTO Y LIMPIEZA DEL APARATO SEGURIDAD Y SOLUCIÓN DE PROBLEMAS ADVERTENCIAS SOBRE EL MEDIO AMBIENTE lave-linge index AVERTISSEMENTS SPÉCIFICATIONS INSTALLATION ET MONTAGE UTILISATION DE L’APPAREIL ET CONSEILS PRATIQUES MAINTENANCE ET ENTRETIEN DE L’APPAREIL...
-
Page 3: Table Of Contents
í ndice ADVERTÊNCIAS QUADRO TÉCNICO INSTALAÇÃO E MONTAGEM UTILIZAÇÃO DO APARELHO E CONSELHOS PRÁTICOS MANUTENÇÃO E LIMPEZA DO APARELHO SEGURANÇA E SOLUÇÃO DE PROBLEMAS ADVERTÊNCIAS SOBRE O MEIO AMBIENTE washing machine contents... -
Page 4: Warnings
Our new range of washing machines has been designed to make life more convenient for you: WITH YOUR CONVENIENCE ALWAYS IN MIND Washing in less time. • The wash programmes do not last as Large hatch. -
Page 5: Washing Machine
Power cord Work top Control Detergent panel dispenser Drain hose Hatch Stainless steel drum Filter Kickplate Levelling feet ACCESSORIES LOCATED INSIDE THE DRUM Rear plugs Drain pipe bender Water inlet hose... -
Page 6: Installation And Assembly
UNPACKING a Remove the base, corner protectors and top cover. UNBLOCKING a There are 3 blocking screws on the back of the washing machine. b To loose and completely remove the 3 screws together with the metal washer and the black rubber and plastic tubes that make up the blocking system. - Page 7 CONNECTION TO THE MAINS WATER SUPPLY The water supply hose is inside the drum: a Connect the bent end of the hose to the threaded inlet of the electrovalve located at the rear of the washing machine. b Connect the other end of the hose to the water intake.
- Page 8 Consult the specifications plate located on the hatch door of the washing machine before making the electrical connections. Ensure that the voltage reaching the plug is the same as that on the plate. Do not remove the specifications plate. The information on it is important.
- Page 9 When your washing machine has been correctly installed, we recommend that you pre-clean the machine. This is to check that the installation, the connections and the drainage are all correct, and to thoroughly clean the inside of the washing machine before any wash programmes are run (see the operating instructions on the following pages).
-
Page 10: Practical Tips
This improves the washing action and also aids the correct distribution of the garments in the drum when spin-drying, and the washing machine will therefore be quieter. It is a good idea to put small garments Cold in a wash bag. - Page 11 WASH FABRIC SOFTENER PREWASH b If you are going to use liquid detergent you must close the wash compartment flap. Take the blue tab protruding from the bottom of the compartment between 2 fingers and pull outwards as far as it will go.
- Page 12 To select a wash programme, proceed as follows: a Switch the washing machine on by pressing ON / OFF. b Activate the programme selector by pressing it to release it (depending on the model).
- Page 13 Normal 30ºC Delicate 40ºC Drain/End Wool programmes Normal 40ºC Delicate 60ºC Auxiliary programmes Normal 60ºC Normal 90ºC Prewash 60ºC eco-note We recommend you choose a wash programme without prewash whenever possible. This will save you money and help protect the environment.
- Page 14 YES NO light soil Cotton/cotton mix Rinses YES NO Synthetic/Delicate Wool/wool mix Cotton/cotton mix Spin-drying Synthetic/Delicate Wool/wool mix Cotton/cotton mix Drain /End Synthetic/Delicate Wool/wool mix Programme for wash and energy consumption assessment in accordance with standard EN60456, press intensive wash button...
- Page 15 0,05/0 Drain and final long spin Drain and end of programme. 0,00/0 Takes programme to final position NOTE: the KWh and litre consumptions and programme durations may vary depending on the type and amount of clothes, mains water pressure, etc.
-
Page 16: Spin Speed Selection
A button with a slot will appear on the right. Turn the button to the left with the aid of a coin and the hatch will open. If your model of Washing machine does not... -
Page 17: Additional Functions
ADDITIONAL FUNCTIONS using the appliance TIME DELAY Time delay selection button A delay of up to 24 hours can be selected. The delay must be selected after choosing the wash programme. To select the delay time, press the clock button. - Page 18 The various buttons can be blocked to prevent them from being pressed and affecting the selected wash programme and options. This can be used to stop children playing with the buttons, etc. The block function should be activated after the wash programme has been selected together with all its options.
-
Page 19: Using The Appliance
PROGRAMME PHASES When the programme is running you can see which phase it is at on the display, as well as how long there is to the end of the programme. The active phases will appear successively at the top of the display as the programme progresses. -
Page 20: Maintenance And Cleaning
MAINTENANCE After each wash, leave the door open for a while to allow the air to circulate freely inside the machine. From time to time, depending on the hardness of your water, it is recommendable to run a full wash cycle using a decalcifying product. - Page 21 Remove the drain pipe, place it on the container and open the cover. Water will start to come out. c When all the water has come out of the machine, turn the filter several times until it can be completely removed, by pulling gently on it.
-
Page 22: Safety And Troubleshooting
This may be due to the following: PROBLEMS The washing machine is not plugged into the mains or Why won’t the washing there is no voltage in the mains supply. machine start? The Start/Pause button has not been pressed. - Page 23 Indicator F01, no water coming in, this may be due to a cut in the water supply, a tap turned off or a blocked water inlet filter. The possible solutions are as follows: wait for the water supply to be reconnected, turn on the tap, or remove the water inlet hose and clean the filter.
- Page 24 One of them is that the washing machine cannot has finished? be opened until it is certain that the drum is quite still. This is why the hatch cannot be opened for 2 minutes. The washing machine can detect other indications.
-
Page 25: Environmental Warnings
It can be taken, free of charge, to a specific waste collection centre, run by your local authority, or For further information, contact dealers who provide this service. - Page 26 Fagor Electrodomésticos, S.Coop. Apartado 49 Tel. (943) 71 91 00 / 01 Fax (943) 79 68 81 Bº San Andrés, 18 20500 MONDRAGÓN (Guipúzcoa) www.fagor.com e-mail: info@fagor.com 03/06 LJ6A028G9/1...
