SUPPLIED COMPONENTS AND HARDWARE
If any pieces are missing or damaged, please
report it immediately to Technical Support at
av.support@legrand.com or (866) 977-3901.
(2x) Recessor Ears
(4x) HPQ Screws (For mounting ears to rackrail)
(8x) 10/32 Cage Nuts
NOTE:
Cage Nuts are not pre-installed. They
can be installed in any opening.
INSTALLATION
1. Install cage nuts into the desired openings
on the back of the ears.
2. Mount the ears to rackrail using provided
HPQ screws.
SUPPLIED COMPONENTS AND HARDWARE
If any pieces are missing or damaged, please
report it immediately to Technical Support at
av.support@legrand.com or (866) 977-3901.
(2x) Recessor Ears
(4x) HPQ Screws (For mounting ears to rackrail)
(8x) 10/32 Cage Nuts
NOTE:
Cage Nuts are not pre-installed. They
can be installed in any opening.
INSTALLATION
1. Install cage nuts into the desired openings
on the back of the ears.
2. Mount the ears to rackrail using provided
HPQ screws.
RR2-3RCN
RACKRAIL RECESSOR
RR2-3RCN
RACKRAIL RECESSOR
CAGE
NUTS
I-00466
Rev A
CAGE
NUTS
I-00466
Rev A
