Raritan PX2 and PX3
Thank you for purchasing the Raritan intelligent power distribution unit (PDU) -- PX2 or PX3.
The intended use of PX2/PX3 is distribution of power to IT equipment such as computers and communication equipment, typically mounted in a
rack located in a data center/equipment room.
This Quick Setup Guide explains how to install and configure the PX2/PX3. For more, access online help from the web interface or go to Raritan's
Support page
(www.raritan.com/support).

Safety Precautions

WARNING! Before installing or operating this product, read and understand all sections in this guide. Failure to heed any of the following
WARNINGS may result in electric shock, fire, personal injury and death. Prior to operating this product, the user should read the online help and
specifically the warnings in the online help.
WARNING! Connect this product to an AC power source with a voltage that is within the range specified on the product's nameplate.
WARNING! Connect this product to an AC power source that is current limited by a suitably rated fuse or circuit breaker in accordance with
national and local electrical codes.
WARNING! Use this product in a dry location.
WARNING! Connect this product to a protective earth ground. Never use a "ground lift adaptor" between the product's plug and the wall
receptacle.
WARNING! If this product is a model that requires the assembly of the line cord or plug, the assembly must be performed by a licensed
electrician, and the line cord or plugs used must be rated based on the product's nameplate ratings, as well as national and local electrical codes.
QS Rule

Unpacking the PX2/PX3

PX2/PX3 comes in Zero U, 1U, and 2U sizes. The following describes the equipment shipped with each size.
If any pieces are missing or damaged, report this to Raritan Technical Support, or contact the Raritan partner where you purchased the product.
Zero U Size
•
PX2 or PX3 PDU
•
Mounting screws, brackets and/or buttons
•
Cable retention clips for the inlet and/or outlets (for some
models only)
1U and 2U Size
•
PX2 or PX2 PDU
•
1U or 2U bracket pack and screws
•
Cable retention clips for the inlet (for some models only)
Note: An "optional" null-modem cable with DB9 connectors on both ends (Raritan number: 254-01-0006-00) for PX2 may be available per
request. For PX3, use a third party RJ45-to-DB9 adapter/cable instead of a null-modem cable.
QS Rule
Raritan PX Quick Setup Guide
PX2_PX3_QSG_A1_4.0.10  255-80-6099-00 RoHS
QUICK SETUP GUIDE
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Raritan PX2 and is the answer not in the manual?

Questions and answers

Related Manuals for LEGRAND Raritan PX2

Summary of Contents for LEGRAND Raritan PX2

  • Page 1 QUICK SETUP GUIDE Raritan PX2 and PX3 Thank you for purchasing the Raritan intelligent power distribution unit (PDU) -- PX2 or PX3. The intended use of PX2/PX3 is distribution of power to IT equipment such as computers and communication equipment, typically mounted in a rack located in a data center/equipment room.
  • Page 2 Before You Begin 1. Prepare the installation site. Make sure the installation area is clean and not exposed to extreme temperatures or humidity. Allow sufficient space around the device for cabling and outlet connections. Safety instructions are provided in the PX2/PX3 online help. Fill out the Equipment Setup Worksheet found in the online help.
  • Page 3 3. Secure with the provided end cap screws. 4. Fasten the rackmount brackets' ears to the rack using your own fasteners. Mounting Zero U Models Using Baseplate-Based Tools You can use one of the three baseplate-based tools to mount the PDU: L-brackets, buttons or claw-foot brackets. ...
  • Page 4 4. Fasten the device to the rack or cabinet using the baseplaed-based tools. ▪ Use rack screws to fasten L-brackets or claw-foot brackets on the PDU to the rack. ▪ For the buttons, press the PDU forward, pushing the mounting buttons through the mounting holes, then letting the device drop about 5/8".
  • Page 5 Note: Not all models have overcurrent protectors. 2. Connect each PX2/PX3 to an appropriately rated branch circuit. Refer to the label or nameplate affixed to your PX2/PX3 for appropriate input ratings or range of ratings. 3. When a PX2/PX3 powers up, it proceeds with the power-on self test and software loading for a few moments. At this time, the outlet LEDs cycle through different colors.
  • Page 6 Step 2: Log in to the PX2/PX3 Web Interface 1. In a web browser, enter the PDU IP address and login with the default user credentials, accepting any security warnings. ▪ Default login: admin/raritan Password change is enforced at first login. QS Rule Appendix A: Configuration via a Mobile Device or PDView An iOS or Android mobile device, such as a smartphone or tablet, can function as a local display.
  • Page 7 ▪ Android: USB-B port Step 3: Launch PDView  To access the PX2/PX3 web interface: 1. Launch PDView on your mobile device. 2. Wait until PDView detects the connected PX2/PX3 and shows the word "Connected" in green. 3. If the factory-default login credentials remain unchanged, or if PDView has been configured with accurate login credentials, PDView automatically logs in to the web interface of PX2/PX3.
  • Page 8 • Connect a USB hub to the USB-A port on the PX2/PX3. Then plug the supported USB wireless LAN adapter into the appropriate USB port on the hub. QS Rule Appendix D: More Information Identifying the Sensor Port Warning: Only connect environmental sensors to the SENSOR port, or damages may be caused to the device and the sensor packages. •...
