SMF 421- B 1
INSTRUCTION MANUAL
Texto en español, página 10
WE'RE HERE TO HELP
Want to watch a video that
shows how easy this is?
Watch it now at:
SANUS.com/3013
Your TV product sticker may be inaccessible after mounting your TV.
Brand:
Model No.:
Serial No. (S/N):
Version/SCC/Other:
Recommended placement
Get it right the first time.
HeightFinder™ shows you
where to drill.
Use it now:
SANUS.com/1173
BEFORE MOUNTING YOUR TV
Record your TV information and
save for future reference.
Or, take a photo of your TV product
sticker and save for future reference.
Our live US-based install
experts are standing by to help.
Call us at:
1-888-333-1376

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sanus SMF421-B1 and is the answer not in the manual?

Questions and answers

Summary of Contents for LEGRAND Sanus SMF421-B1

  • Page 1 Your TV product sticker may be inaccessible after mounting your TV. BEFORE MOUNTING YOUR TV Record your TV information and save for future reference. Or, take a photo of your TV product sticker and save for future reference. Brand: Model No.: Serial No.
  • Page 2: Wall Construction

    IMPORTANT SAFETY INSTRUCTIONS PLEASE READ ENTIRE MANUAL PRIOR TO USE – SAVE THESE INSTRUCTIONS Please read through these instructions completely to be sure you’re comfortable with this easy install process. Check your TV owner’s manual to see if there are any special requirements for mounting your TV. If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product, contact Customer Service.
  • Page 3: Before You Begin

    Dimensions TV INTERFACE MIN VESA MAX VESA 15.7in 3.9in 400mm 100mm 15.7in 3.9in MIN VESA MAX VESA 400mm 100mm WALL PLATE TOP VIEW - EXTENDED SIDE VIEW - EXTENDED 15 deg 21.0in [ 533mm ] OFFSET 4.3in 109mm 6.5in 165mm ±2deg 90deg 90deg...
  • Page 4 Supplied Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts! NOTE: Not all hardware included will be used.
  • Page 5 STEP 1 Attach TV Bracket to TV 1.2 Select TV Screw Length and Spacers 1.1 Select TV Screw Diameter Only one screw size fits your TV. NO SPACER SPACER NEEDED • Flat Back TV • Flat Back TV • Rounded or with Irregular Back TV Extra Space Needed...
  • Page 6 Wood Stud Installation STEP 2A Attach Wall Plate CAUTION: Avoid potential personal injury or property damage! ● Drywall covering the wall must not exceed 5/8 in. (16 mm) ● Minimum wood stud size: nominal 2 x 4 in. (51 x 102 mm) actual 1½ x 3½ in. (38 x 89 mm) ●...
  • Page 7 Solid Concrete or Concrete Block Installation STEP 2B Attach Wall Plate CAUTION: Avoid potential personal injury or property damage! Concrete Anchor Kit CMK1 is not included ● Mount arm assembly directly onto concrete surface (no wall covering) Contact Customer Service to inquire about the CMK1 ●...
  • Page 8 STEP 3 Attach TV to Arm Assembly 3.1 Attach TV to Arm Assembly HEAVY! You may need assistance with this step. CAUTION: Avoid potential personal injury or property damage! Locking screw must be installed to secure the TV to the arm assembly 3.2 Install Caps...
  • Page 9: Manage Cables

    Manage Cables Remove the cable covers IMPORTANT: Fully extend arm assembly to ensure enough slack in cables. 2. Route your cables through the arm assembly shown — to avoid pinching. 3. Reattach the cable covers over the cables. TV Adjustments TILT ADJUSTMENT Your TV should adjust easily when moved, then stay in place.
  • Page 10: Instrucciones Importantes De Seguridad

    INSTRUCCIONES IMPORTANTES DE SEGURIDAD ESPAÑOL - LEA TODO ESTE MANUAL ANTES DE UTILIZAR ESTE PRODUCTO - GUARDE ESTAS INSTRUCCIONES Lea atentamente estas instrucciones en su totalidad para asegurarse de que está familiarizado con el sencillo proceso de instalación. Consulte igualmente el manual de su televisor para conocer si existen requisitos especiales para el montaje de su aparato. Si no entiende las instrucciones o si tiene dudas acerca de la seguridad de la instalación, el montaje o el uso del producto, póngase en contacto con el Servicio de Atención al Cliente o llame a nuestro servicio técnico al número 1-888-333-1376 .
  • Page 11 PRECAUCIÓN: Verifique que el tornillo o la combinación de tornillo , arandelas , espaciador y placas de sujeción del televisor ESPAÑOL enrosquen correctamente. Si el tornillo es demasiado corto no sostendrá el televisor. Si es demasiado largo dañará el televisor. 1,3 Arme las placas de sujeción del televisor VER PÁGINA 5 PRECAUCIÓN:...
  • Page 12 Legrand AV Inc. and its affiliated corporations and subsidiaries (collectively, “Legrand”), intend to make this manual accurate and complete. However, Legrand makes no claim that the information contained herein covers all details, conditions, or variations.
