BLF 328 -B 3
INSTRUCTION MANUAL
MANUEL D'INSTRUCTIONS
Texte français page 30

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SANUS BLF328-B3 and is the answer not in the manual?

Questions and answers

Related Manuals for LEGRAND SANUS BLF328-B3

Summary of Contents for LEGRAND SANUS BLF328-B3

  • Page 1 BLF 328 -B 3 INSTRUCTION MANUAL MANUEL D’INSTRUCTIONS Texte français page 30...
  • Page 2 WE’RE HERE TO HELP NOUS POUVONS VOUS AIDER ! Recommended placement Want to watch a video that shows Get it right the first time! Our US-based install experts are how easy this DIY project will be? HeightFinder shows you where to drill. standing by to help.

  • Page 3: Before You Begin

    Before you begin Remove the stand Install any accessories Protect the face from your TV of your TV — if attached. you may have purchased — if they when laying it down for installation. require the TV to be removed from the wall for assembly.

  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS – PLEASE READ MANUAL PRIOR TO USE – SAVE THESE INSTRUCTIONS Please read through these instructions completely to be sure you’re comfortable with this easy install process. Check your TV owner’s manual to see if there are any special requirements for mounting your TV. If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product, contact Customer Service 1-800-359-5520.

  • Page 5: Wall Construction

    Wall wood studs Solid concrete or CAUTION: concrete block Construction DO NOT install ONLY install on in drywall alone these acceptable wall types. Drywall alone will hold Unsure the weight of your TV. ACCEPTABLE ACCEPTABLE Call Customer Service 1-800-359-5520 Tools Needed 1/2 in.
  • Page 6 Attach TV Bracket to TV STEP 1 WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts! NOTE: Not all hardware included will be used.
  • Page 7 1.1 Select TV Screw Diameter 1.2 Select TV Screw Length and Spacers Only one screw size fits your TV. NO SPACER SPACER NEEDED • Flat Back TV • Flat Back TV • Rounded or with Irregular Back TV Extra Space Needed [TV brackets lay flat on your TV] [for deep inset holes...
  • Page 8 1.3 Attach TV Brackets to Your TV MEASURE ADJUST TO WIDTH inches inches 7 ⅞ 11 ¾ 15 ¾ 400 mm position illustrated 19 ¾ 23 ¾ inch dimensions are approximate Measure the WIDTH and HEIGHT of your TV's mounting hole pattern. Adjust mounting tabs on TV brackets to match the width...
  • Page 9 ASSEMBLE FOR HEIGHT ASSEMBLE FOR HEIGHT For height 300 mm or less For height greater than 300 mm ≤ 300 mm > 300 mm For hole pattern height 300 mm and less, align horizontal TV For hole pattern height greater than 300 mm, align horizontal TV brackets with mounting tabs to the inside.
  • Page 10 1. 3 (continued) CENTER LOOSELY ASSEMBLE NO SPACER SPACER NEEDED Adjust TV brackets to align with your TV hole pattern. Install using the TV bracket must be centered on your TV, but can be offset up or screw /washer /spacer combination you selected for your TV.
  • Page 11 SECURE ASSEMBLY TIGHTEN ALL SCREWS Securely tighten the screws from STEP 4 and STEP 6. Secure the TV brackets using four interface screws , starting with the top two screws in the notches shown.
  • Page 12 STEP 2 Attach Wall Plate to Wall WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts! NOTE: Not all hardware included will be used.
  • Page 13 STEP 2A Attach Wall Plate Wood Stud Installation CAUTION: Avoid potential Min. 1 ½ in. (3.8 cm) personal injury or property damage! ● Drywall covering the wall Min. 16 in. (40.6 cm) Min. 3 ½ in. (8.9 cm) must not exceed 5/8 in. (1.5 cm) ●...
  • Page 14 STEP 2A (continued) DRILL POSITION TEMPLATE Visit 3 ½ in. (9 cm) HeightFinder™ sanus.com /2566 7/32 in. (5.5 mm) To calculate your precise wall plate location, check out Be sure you drill into the CENTER of the stud. TIP: CAUTION: our HeightFinder at sanus.com [www.sanus.com/2566].
  • Page 15 OPEN COVERS SECURELY TIGHTEN CAUTION: Avoid potential personal injury or property damage! All four lag bolts MUST BE firmly tightened to prevent unwanted movement of the wall plate . Ensure the wall plate is securely fastened to the wall before continuing on to the next step. Install wall plate using four lag bolts and firmly tighten...
  • Page 16 STEP 2B Attach Wall Plate Solid Concrete or Concrete Block Installation CAUTION: POSITION TEMPLATE Avoid potential personal injury or property damage! Visit ● Mount the wall plate directly onto the concrete surface HeightFinder™ sanus.com ● Minimum solid concrete thickness: 8 in. (20.3 cm) /2566 ●...
  • Page 17 DRILL INSERT 3 ¾ in. (9.5 cm) 3/8 in. (10 mm) Be sure the anchors are seated flush CAUTION: CAUTION: CAUTION: CAUTION: Never drill into the mortar between blocks. Never drill into the mortar between blocks. with the concrete surface. Drill four pilot holes using a 3/8 in.
  • Page 18 STEP 2B (continued) OPEN COVERS SECURELY TIGHTEN CAUTION: Avoid potential personal injury or property damage! All four lag bolts MUST BE firmly tightened to prevent unwanted movement of the wall plate . Ensure the wall plate is securely fastened to the wall before continuing on to the next step. Rotate the covers to expose the mounting holes.
  • Page 19 STEP 3 Attach TV to Wall Plate WARNING: Before starting assembly, verify this part is undamaged. If damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts! Parts and Hardware for STEP 3 CABLE COVERS CABLE COVERS (ATTACHED)
  • Page 20 3.1 Attach Arm Assembly to Wall Plate HANG HEAVY! You may need assistance with this step. CAUTION: Avoid potential personal injury or property damage! For CONCRETE APPLICATIONS: The arm assembly MUST remain centered in wall plate Hang the top hook of arm assembly , onto wall plate ,Then NOTE: For WOOD STUD APPLICATIONS, the arm assembly...

  • Page 21: Close Covers

    SECURE CLOSE COVERS CAUTION: Avoid potential personal injury or property damage! Always make sure both locking screws are tightened, so the arm assembly is securely fastened to wall plate Secure arm assembly onto wall plate using two locking Close the wall plate covers screws in the bottom location shown.
  • Page 22 3.2 Hang TV onto Arm Assembly ATTACH HANG YOUR TV HEAVY! You may need assistance with this step. 11 11 Press the bottom of the TV into the arm assembly until you hear Hang the TV onto the arm assembly by hooking the top support the lock click, securing the TV in place.
  • Page 23 SECURELY TIGHTEN CAUTION: Avoid potential personal injury or property damage! Always make sure your securement screw is tightened, so the TV is securely fastened to the arm assembly To lock the TV onto arm assembly , install the securement screw on the vertical TV bracket...

  • Page 24: Route Cables

    Manage Cables ROUTE CABLES ATTACH COVERS IMPORTANT: Pull arm to its full extension, to leave enough slack and prevent stretching the cables when the arms are moved. Remove the cable covers from the arm by sliding to loosen. Reattach cable covers to capture the cables.

  • Page 25: Level Adjustment

    Adjustments LEVEL ADJUSTMENT TILT ADJUSTMENT NOTE: If you do not intend to adjust the tilt for different viewing locations, you can tighten the tilt tension knob , to prevent unwanted movement. If needed, use hex key to tighten more firmly. CAUTION: Screw MUST be loosened before STEP 2.
  • Page 26 EXTEND / RETRACT -- ONLY IF NECESSARY TV LATERAL SHIFT HEAVY ! You may need assistance with this step. CAUTION : Avoid potential injuries or property damage! Do NOT adjust the arm position from center for concrete applications. MUST remain centered in wall plate for all concrete applications! For wood stud applications ONLY:...
  • Page 28 REMOVE THE TV REMOVE THE ARM ASSEMBLY HEAVY ! You may need assistance with this step. Disconnect all cables from the TV. Remove securement screw Pull down on the release cord to release the TV. Carefully lift the TV from arm assembly...

  • Page 29: Troubleshooting

    Troubleshooting If you are uncertain about your hardware selection, contact Customer Service at 1-800-359-5520 TV Supplied TV supplied spacers Spacers : Use your TV supplied spacer/adapter for flat back TVs : Use your TV supplied spacer/adapter and spacer for: (AND you want your TV closer to the wall).
  • Page 30 Français CONSIGNES DE SÉCURITÉ IMPORTANTES – CONSERVEZ CES INSTRUCTIONS – VEUILLEZ LIRE ENTIÈREMENT LE MANUEL AVANT D’UTILISER CE PRODUIT Veuillez lire au complet ces instructions pour vous assurer d’être à l’aise avec ce processus d’installation facile. Veuillez également consulter le manuel du propriétaire de votre téléviseur pour savoir si son installation présente des exigences particulières.
  • Page 31 Français Avant de commencer Retirez le support de votre téléviseur...s'il est installé, bien sûr. Installez tous les accessoires que vous prévoyez d'ajouter à votre téléviseur. Vérifiez les manuels d'installation de tous ces accessoires pour savoir s'ils doivent être INSTALLÉS AVANT de monter le téléviseur. Protégez l'écran de votre téléviseur lorsque vous le déposez pour l'installation.
  • Page 32 Français 1,3 Fixez les supports de fixation sur votre téléviseur PAGE 8 MESUREZ Mesurez la LARGEUR et la HAUTEUR des trous de montage de votre téléviseur. AJUSTEZ PAR RAPPORT À LA LARGEUR Ajustez les languettes de montage se trouvant sur les supports de fixation pour téléviseur de sorte à...
  • Page 33 Français ÉTAPE 2A Fixez la plaque murale Installation sur montants en bois PAGE 13 MISE EN GARDE : évitez les risques de blessures corporelles ou de dommages matériels ! ● L’épaisseur du revêtement de cloison sèche ne doit pas excéder 16 mm (5/8 po) ●...
  • Page 34 Français ÉTAPE 2B Fixez la plaque murale Installation sur béton plein ou blocs de béton PAGE 16 MISE EN GARDE : évitez les risques de blessures corporelles ou de dommages matériels ! ● Montez l'ensemble de bras/plaque murale directement sur la surface de béton ●...
  • Page 35 Français ÉTAPE 3 Fixez le téléviseur à la plaque murale PAGE 19 MISE EN GARDE : Avant de commencer l'assemblage, vérifiez que cette pièce n'est pas endommagée. Si elle est endommagée, ne retournez pas l'article endommagé à votre revendeur. Contactez le service clientèle. N'utilisez jamais de pièces endommagées ! 3.1 Attachez le bras à...
  • Page 36 Français Gestion des câbles PAGE 24 FAITES PASSER LES CÂBLES REMARQUE: Allongez complètement le bras pour laisser suffisamment de jeu et éviter que les câbles soient étirés lorsque les bras sont déplacés Retirez le cache-câble C du bras . Faites passer les câbles à travers le bras REPLACEZ LE CACHE-CÂBLE Refixez le cache-câble C .
  • Page 37 Français DÉCALAGE LATÉRAL DU TÉLÉVISEUR PAGE 26 MISE EN GARDE : Évitez tout dommage matériel ou toute blessure ! Ne déplacez PAS le bras du centre dans le cas d'une installation sur du béton. Le bras DOIT rester centré dans la plaque murale pour toute installation sur du béton ! Pour les utilisations sur des montants en bois UNIQUEMENT : 1.
  • Page 38 Dimensions TV INTERFACE 23.62in 600mm 7.87in 200mm 7.87in 15.75in 200mm 400mm WALL PLATE TOP VIEW - EXTENDED TOP VIEW - EXTENDED SIDE VIEW - EXTENDED 15 deg 33.68in WALL IS ON TOP DOWN 855.6mm 21.83in 554.6mm 2.36in 14.55in 18.72in 369.6mm 60mm 475.6mm 9.27in...
  • Page 39 Legrand AV Inc. et ses sociétés a liées et ses filiales (collectivement dénommées « Legrand »), se sont e orcées de rendre ce manuel précis et complet. Cependant, Legrand ne garantit pas que les informations qu’il contient couvrent tous les détails et toutes les conditions ou variations.
  • Page 40 +1 (800) 359-5520 ● SANUS.com Legrand AV Inc. and its a iliated corporations and subsidiaries (collectively, “Legrand”), intend to make this manual accurate and complete. However, Legrand AV makes no claim that the information contained herein covers all details, conditions, or variations. Nor does it provide for every possible contingency in connection with the installation or use of this product. The information contained in this document is subject to change without notice or obligation of any kind.
