XFT-V2 Strength Training System
Base Serial Number: _ _ _ _ _ _ _ _ _ _ _ _ _
Purchased Date: ___ / ___ / ______
Dealer's Name:__________________________
Please register your products at:
https://www.bodycraft.com/product-registration/
Owner's Manual
1
To see in
FULL COLOR
& additional
information,
scan this QR code.
Serial Number
Open your Camera
App and point it at
the QR Code
XFT-V2_OM v1.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XFT-V2 and is the answer not in the manual?

Questions and answers

Related Manuals for BodyCraft XFT-V2

Summary of Contents for BodyCraft XFT-V2

  • Page 1 XFT-V2 Strength Training System Open your Camera App and point it at the QR Code To see in FULL COLOR & additional information, scan this QR code. Base Serial Number: _ _ _ _ _ _ _ _ _ _ _ _ _ Purchased Date: ___ / ___ / ______ Dealer’s Name:__________________________...
  • Page 2 Thank you for selecting BODYCRAFT. Your choice reflects a wise investment in you and your facility. We hope you use it for many healthy years! BODYCRAFT offers a complete array of high-quality fitness equipment. Please refer to our website www.bodycraft.com to view more ways to enhance your lifestyle.

  • Page 3: Table Of Contents

    Recommended Training Area and ADA Compliance …………………. Weight Ratios - Stack, Pulleys & Press Bar …………………………………… Assembly Parts / Hardware List & Images ……………………………. 12 - 14 Product Assembly - How to Assemble the XFT-V2 Pre-Assembly Tips ………………………………………………………..STEP 1 - STEP 5 ……………………….……………………………………….
  • Page 4 BLUE line in this Table of Contents. Page Product Assembly - How to Assemble the XFT-V2 STEP 17b - Adjust the Cables for Correct Tension …..……….…………… STEP 18 - Weight Stack Stickers Installation …………………………… STEP 19 - STEP 21 …………………….……………….……………………...

  • Page 5: Product Safety

    It is imperative that you retain this Assembly Instructions and be sure all warning labels are legible and intact. Replacement Assembly Instructions and labels are available from BODYCRAFT. If you are unsure about the proper use of the BODYCRAFT strength machine call your local BODYCRAFT dealer or our Customer Service Department. Contact BODYCRAFT at 800-990-5556 or support@bodycraft.com...

  • Page 6: Important Notes, Recommended Tools & Cleaners

    Important Notes, Recommended Tools & Cleaners , GT Important Notes and Tips: Before assembly, read all instructions thoroughly and preview diagrams to help make the installation easier. 2. Make sure all parts are accounted for and in proper condition before beginning assembly. See the parts list.
  • Page 7 Warning Labels, Maintenance Schedule & Serial Number, XFT-V2 1 of 2 Carefully read ALL warning, caution & maintenance schedule labels # XFT-V2-175b, Warning Label - Please Utilize This Equipment # XFT-V2-184b, Warning Solely For Its Designated Purpose Label - Pinch Point,...
  • Page 8 Warning Labels, Maintenance Schedule & Serial Number, XFT-V2 2 of 2 # XFT-V2-178b, Warning Label - Pinch Point, Vertical # XFT-V2-183b, Label - Trademark (BODYCRAFT, XFT) # XFT-V2-174b, Caution Label - The Pull-PIN # XFT-V2-177b, Warning Label # XFT-V2-181b, Label - - Master Rules &...
  • Page 9 Machine Dimensions & Room Layouts, XFT-V2 Wall Wall Flat Wall Layout 61.6” L x 50.2” W x 83.5” H Corner Layout 73.5” L x 73.5” W x 83.5” H Corner Layout 73” L x 73” W x 83.5” H Machine Weight w/o Accessories:...
  • Page 10 Recommended Training Area, XFT-V2...

  • Page 11: Weight Ratios - Stack, Pulleys & Press Bar

    Weight Stack, Pulleys & Press Bar Ratios, XFT-V2 100% Standard 150lb Stack Upgraded 200 lb Stack NOTE: Weights are approximate...
  • Page 12 Assembly Parts List & Images, XFT-V2 1 of 3 NOTE: For a complete service parts list, please refer to the detailed parts list & exploded view …………………………………….at the rear of this manual. Part # Assembly Parts List Frame, Bottom, Right w/...
  • Page 13 Assembly Parts List & Images, XFT-V2 2 of 3 Part # Assembly Parts List Press Bar with Grid Pattern, φ32mm ID x φ40mm XFT-V2-024-ASM OD x 847mm L - Assembly Guide Rod for Weight Plate, φ20mm ID x φ25mm XFT-V2-026 OD x 1978mm L Guide Rod, Solid Linear for Sliding Frame, φ25mm...
  • Page 14 Bolt, Socket Cap Head w/ Hex XFT-V2-101 Recessed, 7/16" x 1-3/4" L - BLK XFT-V2-115 Bolt, Hex Head, 3/8" x 1" L - BLK XFT-V2-119 Bolt, Hex Head, 3/8" x 2-3/4" L - BLK XFT-V2-120 Bolt, Hex Head, 3/8" x 3-1/8" L - BLK...
  • Page 15 Product Assembly - Preassembly Tips, XFT-V2 PREASSEMBLY TIP #1 – “Stage Right”. During the assembly process we will be stating Right, Left, Front, Back, Top, or Bottom. These all are in the perspective of the user in the machine facing outward with feet on the ground.
  • Page 16 Product Assembly, XFT-V2 STEP 1a Please Loosely Tighten STEP 1a Bolts with # 165 Wrench TEP 1a: Install the Vertical Sliding Tube to the Bottom Connector Frame Frame Parts Part # Assembly Parts List Frame, Connector, Bottom w/ pre-assembled XFT-V2-003-ASM...
  • Page 17 Product Assembly, XFT-V2 STEP 1b - 1c Please Hand Tighten All Nuts & Bolts Until STEP 13 TEP 1b: Remove 1st the pre-assembled hardware TEP 1c: Install the Rt & Lt Bottom Frames Frame Parts Part # Assembly Parts List...
  • Page 18 TEP 1f: Install the Adjusting Frame to the Vertical Sliding Tube Frame Parts Part # Assembly Parts List XFT-V2-006 Adjuster Frame w/ pre-assembled -ASM Pulleys- Assembly XFT-V2-009 Adjusting Handle w pre-assembled -ASM hardware - Assembly XFT-V2-010 Magnetic Connecting Rod, 212mm L...
  • Page 19 Product Assembly, XFT-V2 STEP 2a - 2c Please Hand Tighten All Nuts & Bolts Until STEP 13 TEP 2a: Remove 1st the pre-assembled hardware TEP 2b: Install the Upright Post to the Bottom Frame (Left Side) TEP 2c: Remove the “A & B”...
  • Page 20 Product Assembly, XFT-V2 STEP 2d Please Hand Tighten All Nuts & Bolts Until STEP 13 TEP 2d: GENTLY place into position the #5-ASM Sliding Frame (as shown below) TIP: Use part of the cardboard box to protect painted frame parts from the sharp aluminum edges.
  • Page 21 Product Assembly, XFT-V2 STEP 3a - 3c Please Hand Tighten All Nuts & Bolts Until STEP 13 TEP 3a: Remove 1st the pre-assembled hardware TEP 3b: Install the Upright Post to the Bottom Frame (Right Side) TIP: Use part of the cardboard box to slide into position w/o damaging paint.
  • Page 22 Product Assembly, XFT-V2 STEP 4a - 4d ONLY Tighten STEP 4 Bolts at this time TEP 4a - 4c: Remove 1st the pre-assembled hardware, then swivel both sides Connecting Plates TEP 4d: Reattach the pre-assembled hardware 5 ft-lbs Tighten the 5/16” Bolts to the (+/- 0.5 lbs)

  • Page 23: Step 1 - Step 5

    Product Assembly, XFT-V2 STEP 5a TEP 5a: Guide the Cable #63 Rt & Lt Sides through the Top Connector Frame Pulleys Front CAUTION: Top Connector Frame - Assembly (4-ASM) is large and awkward to install, especially to the Upright Post, Middle - Assemblies (8-ASM), while feeding the #63 Cables though the pulleys from below.

  • Page 24: Step 7 - Step

    Product Assembly, XFT-V2 STEP 5b - 5d TEP 5b - 5c: Install the Top Please Hand Tighten Connector Frame to the Rt & Lt All Nuts & Bolts Until STEP 13 Upright Posts Front TEP 5d: Secure to the Vertical Sliding Tube...
  • Page 25 Product Assembly, XFT-V2 STEP 6a - DECISION POINT DECISION POINT XFT-V2 - STEP 6a 96” ( 8-ft ) or taller 84” ( 7-ft ) Low Ceiling Height Ceiling Height If you are installing with a Ceiling If you are installing with a Low Height of 96”...
  • Page 26 Product Assembly, XFT-V2 STEP 6b - 6c w/ Ceiling Height of 96” ( 8-ft ) TEP 6b: Remove 1st the pre-assembled hardware, Rt & Lt Sides Please Hand Tighten All Nuts & Bolts Until STEP 13 TEP 6c: Install the #27 Guide Rods by first Slightly Angle the bottom forward and pushing the Guide Rod upward.
  • Page 27 Product Assembly, XFT-V2 STEP 6d - 6f w/ Ceiling Height of 96” ( 8-ft ) TEP 6d: GENTLY lower the #27 Guide Rods down through the Linear Cartridges IMPORTANT Slide the Guide Rod gently through the upper hole, ensuring not to dislodge any ball bearings.
  • Page 28 Product Assembly, XFT-V2 STEP 6g - 6i w/ LOW Ceiling Height of 84” ( 7-ft ) NOTE: These next STEPS is for LOW Ceiling Height Installation of 84” ( 7-ft ). If you completed installation of the #27 Guide Rods in STEP 6a-6f, continue to STEP 7.
  • Page 29 Product Assembly, XFT-V2 STEP 6j - 6k w/ LOW Ceiling Height of 84” ( 7-ft ) TEP 6j: Install the #24 Linear Bearing Cartridges on the #127 Guide Rod At a Slight Angle, raise into the Upper Guide Rod Holder...
  • Page 30 Product Assembly, XFT-V2 STEP 7a - 7c TEP 7a: Lock-In #5-ASM into #6-ASM using the Adjusting Handle. CAUTION: Double Confirm the #9-ASM Adjusting Handle is full locked-In place BEFORE installing #63 Cables. TEP 7b & 7c: Install Right Side Cable #63 with Hardware to the bottom Connecting Plate...
  • Page 31 Product Assembly, XFT-V2 STEP 8a - 8c TEP 8a: Remove 1st the pre-assembled hardware for the next two STEPS (STEP 8 & STEP 9) Please Hand Tighten All Nuts & Bolts Until STEP 13 TEP 8b & 8c: Install the Rt & Lt Rear Upright Posts ●...
  • Page 32 Product Assembly, XFT-V2 STEP 9a - 9d TEP 9a & 9b: Install the Rt & Lt Front Upright Posts Please Hand ● Double Confirm the Adjustment Numbers are facing inward Tighten All Nuts & Bolts Until STEP 13 Frame Parts...
  • Page 33 Product Assembly, XFT-V2 STEP 10a - 10b TEP 10a & 10b: Install the Rt & Lt Connector Frames Confirm middle pulleys are facing inward Please Hand Tighten All Nuts & Bolts Until STEP 13 Front Hardware Part # Assembly Hardware...
  • Page 34 Product Assembly, XFT-V2 STEP 11a - DECISION POINT DECISION POINT 150 lb XFT-V2 - STEP 11a Weight Stack OPTIONAL 200 lb If you are installing the 150 lb Weight Weight Stack Stack, use the 7” tall Stack Spacers #72. 14 Plates 19 Plates Frame &...
  • Page 35 Product Assembly, XFT-V2 STEP 11b - 11d TEP 11b: Install Selector Rod 30 ft-lbs (+/- 3 lbs) Tighten to the CRITICAL: Align the selector holes on the weight plates forward, Recommended Torque toward the front of the machine, with the half moon opening facing Specs at this time.
  • Page 36 Product Assembly, XFT-V2 STEP 11e - 11g TEP 11e: Remove 1st all the pre-assembled hardware Then Then TEP 11f: Install the Guide Rod Holder Plate TEP 11g: Re-Install all the pre-assembled Hardware Please Hand Tighten All Nuts & Bolts Until STEP 13...

  • Page 37: Step 12 - Chin Up Bar

    Product Assembly, XFT-V2 STEP 12a - 12b TEP 12a: Remove 1st the pre-assembled hardware TEP 12b: Install the Chin Up Bar & Cushion for Double Pulley Block Then Recommended Tool ADJUSTABLE WRENCH Screw in Threaded Adjustable Stopper 50% into the Rt & Lt...

  • Page 38: Step 13 - "Torque Time

    Product Assembly, XFT-V2 STEP 13a - “Torque Time” TEP 13a: “Torque Time” on ALL Frame Nuts & Bolts from STEP 1 - STEP 10 NOTE: These recommended torque Example of being specs should be followed for correct overtightened not using the...
  • Page 39 Product Assembly, XFT-V2 STEP 13b - “Torque Time” TEP 13b: “Torque Time” on ALL Frame Nuts, Bolts & Inner Screws 8 ft-lbs 3 ft-lbs (+/- 0.5 lbs) (+/- 0.5 lbs) Tighten all 3/8”Recessed Bolts 8 ft-lbs (+/- 0.5 lbs) Tighten all 5/16” Inner Hex Screws &...

  • Page 40: Step 14 - Top Cable #62

    Product Assembly, XFT-V2 STEP 14 (Top Cable #62) - OVERVIEW OVERVIEW IMAGE for STEP 14 (Cable #62) ... Start Assembly on page 41 Pulleys P1 - P19 Pulleys are numbered GREEN circles for installation routing. Back NOTE: Actual color of Top Cable #62 is black.
  • Page 41 NOTE: The start of Cable #62 Routing on the #6-ASM can be the most challenging and critical for the XFT-V2. Take your time and confirm with the images above it is done correctly BEFORE going on to Pulley #7 at bottom of machine.
  • Page 42 Product Assembly, XFT-V2 STEP 14b - (Top Cable #62) TEP 14b: Route Top Cable #62 (from Pulley 7 to Pulley 12) & Install Pulley Block Frame Parts Part # Assembly Parts List Pulley Block, Double, Closed Flat End w/ XFT-V2-035-ASM...
  • Page 43 Product Assembly, XFT-V2 STEP 14c - (Top Cable #62) TEP 14c: Route Top Cable #62 (from Pulley 13 to Pulley 19) & Install Pulley Blocks Back Recommended Tool ADJUSTABLE WRENCH Screw in Threaded Rod 50% into the Top Plate Tighten the Jam Nut at this time.
  • Page 44 Product Assembly, XFT-V2 STEP 14d - (Top Cable #62) TEP 14d: Route Top Cable #62 (from Pulley 19 to # 6-ASM) & Install Cable End Split Bolt w/ hardware Back Recommended Tool ADJUSTABLE WRENCH Screw in Threaded Cable Bolt 50% into #6-ASM Tighten the Jam Nut at this time.
  • Page 45 Product Assembly, XFT-V2 ….. STEP 15 (Low Cable #61, Right Side) - OVERVIEW OVERVIEW IMAGE for STEP 15 (Low Cable #61) ... Start Assembly on page 46 Pulleys P20 - P28 Pulleys are numbered GREEN circles for installation routing. Back NOTE: Actual color of Top Cable #62 is black.

  • Page 46: Step 15 - Low Cable #61 (Right Side)

    Assembly Hardware Frame & Cable Parts XFT-V2-133 Nut, 1/2" - BLK Part # Assembly Parts List XFT-V2-143 Washer, Spring, 1/2" - BLK XFT-V2-061 Cable, Low, 326.5" (8,292mm) L Bolt, Hex Head, Split (for Cable Ends), 1/2" x 1-3/4" XFT-V2-161 L - BLK...
  • Page 47 Product Assembly, XFT-V2 STEP 15c (Low Cable #61 - Right Side) TEP 15c: Route Low Cable #61 (from Pulley 25 to Pulley 28), Install Cable Stopper & Handle NOTE: Route the cable under the Cable Retainer Metal Bars on the Top Connector Frame Cable &...
  • Page 48 Product Assembly, XFT-V2 …… STEP 16 (Low Cable #61, Left Side) - OVERVIEW OVERVIEW IMAGE for STEP 16 (Low Cable #61) ... Start Assembly on page 49 Pulleys P29 - P37 Pulleys are numbered GREEN circles for installation routing. Back NOTE: Actual color of Top Cable #62 is black.

  • Page 49: Step 16 - Low Cable #61 (Left Side)

    Assembly Hardware Frame & Cable Parts XFT-V2-133 Nut, 1/2" - BLK Part # Assembly Parts List XFT-V2-143 Washer, Spring, 1/2" - BLK XFT-V2-061 Cable, Low, 326.5" (8,292mm) L Bolt, Hex Head, Split (for Cable Ends), 1/2" x 1-3/4" XFT-V2-161 L - BLK...
  • Page 50 Product Assembly, XFT-V2 STEP 16c (Low Cable #61 - Left Side) TEP 16c: Route Low Cable #61 (from Pulley 34 to Pulley 37), Install Cable Stopper & Handle NOTE: Route the cable under the Cable Retainer Metal Bars on the Top Connector Frame 34-ASM Cable &...
  • Page 51 Product Assembly, XFT-V2 … STEP 17a - Final Assembly Lube Guide Rods STEP 17a : Lube both Guide Rods for the Weight Stack (26) with 100% pure Silicone Lube or Teflon PTFE Grease. ONLY apply a light layer with a clean rag.

  • Page 52: Step 17B: Adjust The Cables For Correct Tension

    Product Assembly, XFT-V2 … STEP 17b - Adjust the Cables for Correct Tension TEP 17b: Adjust the Cables for Correct Tension The Cables should be tightened to the point just before the Top Plate lifts off the stack. See below for Major Adjustments or Fine Adjustment for correct cable adjustments.
  • Page 53 Product Assembly, XFT-V2 STEP 18 - Weight Stack Stickers Installation...
  • Page 54 Product Assembly, XFT-V2 STEP 19a - 19b TEP 19a: Remove 1st the pre-assembled hardware TEP 19b: Install the Rt & Lt Weight Stack Covers Frame Parts Part # Assembly Parts List XFT-V2-044L Weight Stack Cover, Left, w/ one Arrow Label...
  • Page 55 Product Assembly, XFT-V2 STEP 20 5 ft-lbs TEP 20: Install the Top XFT Panel (+/- 0.5 lbs) 5 ft-lbs (+/- 0.5 lbs) Please Tighten these Bolts to the Torque Specs Frame Parts Part # Assembly Parts List XFT-V2-028-ASM Panel - Assembly...

  • Page 56: Step 19 - Step 21

    Recommended Torque Specs Frame Parts Part # Assembly Parts List XFT-V2-024-ASM Press Bar with Grid Pattern, φ32mm ID x φ40mm OD x 847mm L - Assembly XFT-V2-032 Lateral Guide Rod , φ25mm x 1100mm L XFT-V2-039 Rubber Cushion, Trapezoidal, φ24.5mm x φ45mm x φ61mm x30mm L XFT-V2-040 Rubber Cushion, Cylindrical, φ24.5mm ID x φ48mm OD x 20mm L...

  • Page 57: Step 22 - Accessories

    Product Assembly, Product Assembly, XFT-V2 STEP 22 TEP 22: Install Accessories 87 & 88 Back Part # Assembly Parts List XFT-V2-066 Accessory, Leg Strap XFT-V2-067 Accessory, Long Strap XFT-V2-081-ASM Accessory, Short Bar - Assembly XFT-V2-082-ASM Accessory, Long Bar - Assembly...

  • Page 58: Step 23 - Final Assembly Clean Up & Polish

    Product Assembly, XFT-V2 STEP 23 - Final Assembly Clean Up & Polish STEP 23a: Remove all Assembly Stickers, i.e. Part Numbers & Right / Left Circles ● Easy to remove with fingernail or plastic scraper ● If adhesive residue is on frame: ○...
  • Page 59 Product Assembly, XFT-V2 OPTIONS OPTIONS : Installing the XFT-Bracket, go directly to www.bodycraft.com/XFT-Bracket-qr.html...
  • Page 60 Product Assembly, Routine Schedule, XFT-V2...
  • Page 61 Product Assembly, Strength Cable Wear Indicators, XFT-V2...
  • Page 62 XFT-V2 Strength Training System 131 135 116 35 XFT-V2_EV v1.2a...
  • Page 63 XFT-V2 Strength Training System 84 131 XFT-V2_EV v1.2a...
  • Page 64 XFT-V2 Strength Training System XFT-V2_EV v1.2a...
  • Page 65 XFT-V2 Strength Training System XFT-V2_EV v1.2a...

  • Page 66: Detailed Parts List & Images

    Detailed Parts List & Images, XFT-V2 1 of 5 Part # Detailed Parts List XFT-V2-001 Frame, Bottom, Right XFT-V2-002 Frame, Bottom, Left XFT-V2-003 Frame, Connector, Bottom XFT-V2-004 Frame, Connector, Top XFT-V2-005 Frame, Sliding XFT-V2-006 Frame, Adjuster XFT-V2-007 Connecting Plate for Sliding Frame...
  • Page 67 Detailed Parts List & Images, XFT-V2 2 of 5 Part # Detailed Parts List XFT-V2-037 Elastic Band XFT-V2-038 Cap for Elastic Band Rubber Cushion, Trapezoidal, φ24.5mm x φ45mm x XFT-V2-039 φ61mm x30mm L Rubber Cushion, Cylindrical, φ24.5mm ID x φ48mm...
  • Page 68 Detailed Parts List XFT-V2-112 Bolt, Button Head w/ Hex Recessed, 5/16" x 3/4" L - BLK XFT-V2-116 Bolt, Hex Head, 3/8" x 2" L - BLK XFT-V2-113 Bolt, Hex Head, 1/2" x 1" L - BLK XFT-V2-117 Bolt, Hex Head, 3/8" x 2-1/8" L - BLK XFT-V2-114 Bolt, Hex Head, 3/8"...
  • Page 69 Detailed Parts List & Images, XFT-V2 4 of 5 Part # Detailed Parts List XFT-V2-120 Bolt, Hex Head, 3/8" x 3-1/8" L - BLK XFT-V2-121 Bolt, Hex Head, 1/2" x 3-1/4" L - BLK XFT-V2-122 Bolt, Hex Head, 5/16" x 1-3/4" L - BLK...
  • Page 70 Detailed Parts List & Images, XFT-V2 5 of 5 Part # Detailed Parts List XFT-V2-159 Foot Pad, Rubber XFT-V2-160 Rubber Pad, Rectangle Bolt, Hex Head, Split (for Cable Ends), 1/2" x XFT-V2-161 1-3/4" L - BLK XFT-V2-162 Washer, Thin, φ12 x φ16 Bolt, Socket Cap Head.
  • Page 71 Service Request Required Information BEFORE Initiating a Service Case The following information is needed to help expedite troubleshooting and to ensure the correct part(s) are sent if needed for a repair: What product / model # do you have? Unit serial number? Installed by a dealer or direct sale? Date of installation? Date of service issue?
  • Page 72 The information you provide will never be distributed to any other individuals or agencies for any purpose. If you prefer to mail your warranty card, have the owner of the product complete the information below and return it to BODYCRAFT within 30 days from the date of equipment installation.

  • Page 73: Product Warranty

    If the item exhibits such a defect, BODYCRAFT will, at its option, repair or replace it without cost for parts. Shipping and handling charges may apply. (BODYCRAFT may require return of the part(s) or photographic evidence of the damaged part(s) prior to replacement.) Serial number is required.
