Technical Manual & Parts Lists
1392D
Model
Revision 5.3 Updated July 15, 2016
Atlanta Attachment Company
362 Industrial Park Drive
Lawrenceville, GA 30046
770-963-7369 • www.atlatt.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1392D and is the answer not in the manual?

Questions and answers

Related Manuals for Atlanta Attachment Company 1392D

Summary of Contents for Atlanta Attachment Company 1392D

  • Page 1 1392D Model Revision 5.3 Updated July 15, 2016 Technical Manual & Parts Lists Atlanta Attachment Company 362 Industrial Park Drive Lawrenceville, GA 30046 770-963-7369 • www.atlatt.com...
  • Page 3 Attachment Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or disclosure of these materials.

  • Page 4: Table Of Contents

    Technical Manual & Parts Lists Contents Important Safety Instruction ........................1 Liability ..............................2 Safety Equipment on the Machines ......................3 Protective Eyewear ............................. 4 Important Notices............................5 Maintenance ..............................7 Repair ................................8 A Word to the End User..........................9 Safety Precautions ............................
  • Page 5 Definitions..............................20 Power Off ..............................21 Main Run Screen............................21 Machine Speed ............................22 Miscellaneous Information ........................23 Presser Foot adjustment procedure for 1392D..................24 Foot Height ............................... 25 Pattern Selection ............................26 Size Adjustments ............................27 Pattern List ..............................28 Pattern (Full View) ...........................
  • Page 6 Technical Manual & Parts Lists 1389740 Isolator Base Assembly......................73 1392193 Operator Platform Assembly ..................... 74 1392195 Thread Stand Frame Assembly ....................76 1386740 Rear Feed Roll Drv. Assembly ....................78 1392415 Lubrication Assembly ........................ 79 1392505 Remote Electrical Panel ......................80 1392744 Limit Switch Assembly......................
  • Page 7 Technical Manual & Parts Lists 1393999 Left Needle and Presser Foot Drive Assembly ................ 118 1389815 Main Drive Shaft Assembly..................... 120 1392070 Roll Servo Drive Assembly ..................... 121 1392071 Carriage Servo Drive Assembly ....................122 1392082 Needle Bar Drive Assembly ....................123 1392125 Rear Thread Tension Assembly ....................

  • Page 8: Important Safety Instruction

    Mandatory Information All persons operating and/or working on the 1392D Golden Eagle Quilter, HD should read and understand all parts of the Safety Instructions. This applies, in particular, for persons who only operate and/or work on the unit occasionally (e.g. for maintenance and repair). Persons who have difficulty reading must receive particularly thorough instruction.

  • Page 9: Liability

    Technical Manual & Parts Lists Liability The machine should only be operated when in perfect working order, with due regard for safety and the potential dangers, as well as in accordance with the Instruction Material. Faults and malfunctions capable of impairing safety should be remedied immediately. We cannot accept any liability for personal injury or property damage due to operator errors or non-compliance with the safety instructions contained in this booklet.

  • Page 10: Safety Equipment On The Machines

    Technical Manual & Parts Lists A Word to the Operator The greatest danger inherent in our machines: is that of fingers, hands or loose clothing being drawn into a machine by live, coasting or rotating tools or assemblies or of being cut by sharp tools or burned by hot elements. LWAYS BE CONSCIOUS OF THESE DANGERS Safety Equipment on the Machines All machines are delivered with safety equipment, which shall not be removed or...

  • Page 11: Protective Eyewear

    Technical Manual & Parts Lists Protective Eyewear Protective eyewear that has been tested by the local authorities should be worn whenever there is a possibility of loose or flying objects or particles such as when cleaning the machine with compressed air. Tools Always count the number of tools in your possession before starting work on the machine.

  • Page 12: Important Notices

    Technical Manual & Parts Lists Important Notices Reporting and Fighting Fires Read the instructions posted in the factory with regard to reporting fires and the emergency exits. Make sure you know exactly where the fire extinguishers and sprinkler systems are located and how they are operated.
  • Page 13 Technical Manual & Parts Lists - Kinetic energy - Note that some motors or spindles, for example, may continue to run or coast run on after being switched off. - Potential energy - Individual assemblies may need to be secured if necessary for repair work. Delivery of the Machine/Packaging Note any markings on the packaging, such as weights, lifting points and special information.

  • Page 14: Maintenance

    Technical Manual & Parts Lists Protect against influences from the surroundings: no structure-borne vibrations, no grinding dust, or chemical vapors. Protect against unauthorized access. Ensure that the machine and accessories are set up in a stable position. Ensure easy access for operation and maintenance (Instruction Manual and layout diagram); also verify that the floor is strong enough to carry the weight of the machine.

  • Page 15: Repair

    Technical Manual & Parts Lists Repair Replacement Parts We cannot accept any liability whatsoever for damage due to the use of parts made by other manufacturers or due to unqualified repair or modification of the machine. Repair, Electrical The power supply must be switched off (master switch off) and secured so that it cannot be switched on again inadvertently before starting any work on live parts.

  • Page 16: A Word To The End User

    Technical Manual & Parts Lists A Word to the End User The end user has sole responsibility to enforce the use of safety procedures and guards on the machine. Any other safety devices or procedures due to local regulations should be should be retrofitted in accordance to these regulations and/or the EC Directive on the safety of machines.

  • Page 17: Setup Specifications

    Technical Manual & Parts Lists Setup Specifications 2” Stroke (Gauge) 1. NEEDLE BAR DRIVE LEVER (SHOULDER TO SHAFT C/L) ..........35 MM (“A”) 2. NEEDLE BAR PITMAN ROD… (18.1") ................. 460MM…..…... 3. NEEDLE BAR TRAVEL (2.00") ....................51 MM………. 4. PRESSER FOOT PITTMAN ROD (22.2") ................565MM………. 5.

  • Page 18: Power Requirements

    Technical Manual & Parts Lists Power Requirements Volts 208-240 VDC Amps 40 Amps / 3 Phase Air Pressure 90 PSI Physical Specifications Overall Dimensions: 15’ X 25’ Weight: 25000 lbs. Recommended Needle: SN794FR-180 Stitch Length: 4-8 SPI Pressure Gauge Settings Main Pressure Regulator: 70 PSI Pressure Roller Regulator:...

  • Page 19: Computer Connections

    Technical Manual & Parts Lists Computer Connections The 1392D control panel may require the unpacking and setup of the computer. The following pictures show front and rear connections for hooking up the control system computer. PLEASE NOTE: DO NOT REMOVE THE TWO GREEN USB SECURITY DONGLES FROM THE COMPUTER.

  • Page 20: Quilter Setup & Training

    Technical Manual & Parts Lists Quilter Setup & Training Adjusting the Hand-Wheel  Tighten hand-wheel bolt  Move hand-wheel to Zero degrees  Clamp Main Shaft, To Prevent Movement Adjusting the Eccentrics  Move presser foot eccentric to the highest position ...

  • Page 21: Fine Tuning Eccentric Top Center

    Technical Manual & Parts Lists Fine tuning Eccentric Top Center  To check turn hand-wheel between 345° and 15° . The dial indicator needs to point at the same number at 345° and 15°  Change eccentric position  Check the top center by moving hand wheel between 345°...

  • Page 22: Adjusting Cams For Presser-Foot

    Technical Manual & Parts Lists Adjusting cams for presser- foot.  Turn the hand-wheel to 0°  Push needle bar clamps down then tighten the bolts  Bring all the cams down so they hit the cam-follower then tighten the bolts ...

  • Page 23: Tighten Needle Lever On Shaft

    Technical Manual & Parts Lists Tighten needle lever on shaft.  Tighten the 2 needle lever on the shaft. (6 bolts every lever) Set lowest needle position 1.  If not already so, put the 3mm spacer under the presser-foot. ...

  • Page 24: Set Lowest Needle Position 3

    Technical Manual & Parts Lists Set lowest needle position 3.  Use the presser-foot adjustment to set the right needle height.  Check the needle height after foot- lift adjustment. Set lowest needle position 4.  When the needle height is 28mm under the throat-plate tighten bolts of the link between needle-bar and shaft.

  • Page 25: Lock Down The Presser-Foot Height

    Technical Manual & Parts Lists Lock down the presser-foot height.  Use bolt to extent presser-foot bar  Press the presser-foot down on the 3mm spacers  Lift up clamp on presser-foot bar so the cam-followers or op against the cams ...

  • Page 26: Lock Down The Presser-Foot Height

    Technical Manual & Parts Lists Lock down the presser-foot height.  Use bolt to extent presser-foot  Press the presser-foot down on the 3mm spacers  Lift up clamp on presser-foot bar so the cam-followers or op against the cams ...

  • Page 27: Operation

    Technical Manual & Parts Lists Operation Definitions Machine Axis -The machine has three Servo motors. One for each Axis of movement. X-Axis is the left and right movement of the carriage. Y-Axis is the Roller movement or front to back. Z-Axis is the Needle up and down movement.

  • Page 28: Power Off

    Technical Manual & Parts Lists Power Off The E-Z Quilter software accesses the hard drive of the PC during operation. It is highly recommended to close the software before turning the Main power off to the machine which also turns off the power to the PC.

  • Page 29: Machine Speed

    Technical Manual & Parts Lists Machine Speed The Machine Speed display shows the Set RPM, Actual RPM, and various ways to adjust the Set RPM. Set RPM is the RPM the machine will run once it accelerates to full speed. Actual RPM is the RPM the machine is currently running.

  • Page 30: Miscellaneous Information

    Technical Manual & Parts Lists Miscellaneous Information The Miscellaneous Information display shows current Yardage Information, Type of run mode, Foot Height, and Current Status. 1. Yardage Information: The Yardage Counter displays the current thru-put yards since the last time the Reset button was clicked. Yards per Run Minute displays current thru-put yards per minute.

  • Page 31: Presser Foot Adjustment Procedure For 1392D

    Here is a step by step on how to adjust the presser foot on your Quilter. You can adjust the presser foot height easily without disturbing any other timing adjustments. Presser Foot adjustment procedure for 1392D - Using the touch screen or pendant, place the quilter at 180 degrees.

  • Page 32: Foot Height

    Technical Manual & Parts Lists Foot Height Foot Height is defined as the distance between the bottom of the presser foot to the top of the needle plate. This distance is physically set on the machine with the use of a manual crank. Sensors mounted to the mechanism tell the controller the current height of the foot.

  • Page 33: Pattern Selection

    Technical Manual & Parts Lists Pattern Selection The Pattern Selection area displays the currently selected pattern, Needle Array Information, and Stitch Information. The heading at the top of the frame displays the path and filename of the current pattern. Clicking the Change Pattern button brings up the Pattern List screen to allow you to view and/or select a different pattern.

  • Page 34: Size Adjustments

    Technical Manual & Parts Lists Size Adjustments When the Change Adjustment button on the Main Run Screen is clicked the Size adjustment screen is activated. 1. Width (X Axis) - Clicking the Arrow buttons increases or decreases the percentage in which the pattern will be stretched in that axis.

  • Page 35: Pattern List

    Technical Manual & Parts Lists Pattern List The Pattern List Screen displays all the patterns in a particular directory or folder. Patterns may be viewed but not loaded while the machine is running. In order to see more patterns in the selected directory use the vertical slide bar to the right of the graphics display area.

  • Page 36: Pattern (Full View)

    Technical Manual & Parts Lists Pattern (Full View) The Pattern (Full View) Screen displays a larger more detailed view of the selected pattern. Clicking anywhere on the screen will return you to the previous screen.

  • Page 37: Needle Array

    Technical Manual & Parts Lists Needle Array The Needle Array Screen displays the actual needle arrangement necessary to achieve the selected pattern. It only shows 24 Out of the 97 needles in each row which is enough to display a recurring pattern.

  • Page 38: How-To Guide For Threading The 1392

    Technical Manual & Parts Lists How-To Guide for Threading the 1392 From Thread Stand: 1. Take the thread behind the rod, through the eyelet, through the thread tensioner, through another eyelet, then inside the slotted thread break detector and pull down towards the needles. From Thread Stand Behind...
  • Page 39 Technical Manual & Parts Lists 2. Route the thread under the farthest rod, under the second rod, under the butterfly tube, through the guides, then over another butterfly tube and then down through the guides and towards the needles. Under the farthest Under the second There is another tube not shown before the eyelets that the thread also goes under.
  • Page 40 Technical Manual & Parts Lists 3. Route the thread from the rod down to the eyelets below.
  • Page 41 Technical Manual & Parts Lists 4. Thread the needles. The front needles are threaded straight down from the eyelets. The rear needles are threaded by routing the thread under the middle bar and over the rear bar and down to the needles. The middle needles are threaded similar to the rear needles but the thread only goes over the middle bar then down to the needles.

  • Page 42: Looper Thread Routing

    Technical Manual & Parts Lists Looper Thread Routing: 1. Run the thread through the eyelet and thread tensioner. Then take the thread over the first bar. Over this bar after threading tensioner From looper thread stand...
  • Page 43 Technical Manual & Parts Lists 2. Route the thread over the first thread rod, under the second thread rod, then through the thread eyelets. Under this rod Over these three rods...
  • Page 44 Technical Manual & Parts Lists 3. From the back looking at the loopers, route thread through the last set of eyelets and under the bar with the exception of the closest looper. Run thread straight from eyelet to looper. Looper Notice the thread routes under a rod before going up to looper for second...
  • Page 45 Technical Manual & Parts Lists 4. Once at the looper, guide the thread through the back of the looper and bring it around the side then through the front of the looper.

  • Page 46: Run History

    Technical Manual & Parts Lists Run History The Run History displays information, including a time stamp, concerning the operation of the machine. As shown above, this information consists of general information and/or errors. All the information displayed in this area is also written to a Log File which can be viewed on the Utilities Screen on page Clicking a particular line will display a message box containing more information concerning the selected line.

  • Page 47: Command Buttons

    Technical Manual & Parts Lists Command Buttons The Command Buttons displayed along the bottom of the Main Run Screen provide user control of the machine and are as follows: 1. Reset / Servos On 2. Input / Output 3. Utilities 4.
  • Page 48 Technical Manual & Parts Lists The Input/Output Screen allows you to see the current state of the Inputs and Outputs. It also allows you to activate/deactivate the Outputs. NOTE: This screen is primarily used to test the Inputs and Outputs. If you manually change the state of an Input it will not have an effect on the machine.
  • Page 49 Technical Manual & Parts Lists The Manual Operations Screen allows you to move all three axes manually and independently. NOTE: When moving the axes independently the synchronous relationship between them is lost. Therefore, when you exit this screen the machine will automatically Home-Out. 1.
  • Page 50 Technical Manual & Parts Lists X-Y Axis Jog The Arrow buttons pointing left and right move the X-Axis (Carriage) in the Left and Right directions. The Arrows buttons pointing up and down move the Y-Axis (Roller) in the Forward (Up) and Reverse (Down) directions.
  • Page 51 Technical Manual & Parts Lists Z Axis Jog The Reverse and Forward buttons move the Z-Axis (Needle) in the Reverse and Forward directions by the angular increment displayed above. Maximum reverse movement is 45 degrees. The Reverse Jog and Forward Jog buttons move the Z-Axis (Needle) in the Forward and Reverse directions and will continue to move until the respective button is released.

  • Page 52: Pendant Operations

    Technical Manual & Parts Lists Pendant Operations NOTE: For safety reasons, if the front door is open, the hand held pendant is disabled. The Pendant Operations Screen duplicates the functionality of the physical Pendant attached to the machine. There are two ways to make this screen appear. One is to click the Command Button on the Main Run Screen.
  • Page 53 Technical Manual & Parts Lists As you turn the selector the functions of the buttons change. See Table below Selector Red Button Green Button Function Auto Pause Restart Start/Pauses machine Needle Up Pause Execute Moves machine to the Needle Up position Position 1 Pause Execute...

  • Page 54: Utilities

    Technical Manual & Parts Lists Utilities As its name implies the Utilities Screen have several functions. 1. Log Files (See “Log Files” on page 48.) 2. Copy Pattern Files (See “Copy Pattern Files” on page 49.) 3. Serial Communication Status - Monitors communication between the PC and the Servo Controller.

  • Page 55: Log Files

    Technical Manual & Parts Lists Log Files By default the Log File displayed is the file for the current day. Note the filename of the Log File is 060218.txt, this represents 02/18/06 or February 18th, 2006. 06 is the year, 02 is the month, and 18 is the day.

  • Page 56: Copy Pattern Files

    Technical Manual & Parts Lists Copy Pattern Files If new patterns are created on a different computer they have to be copied to the PC running the quilter. Since there are six separate files associated with each pattern this Copy function was developed to facilitate the process.

  • Page 57: System Information

    Technical Manual & Parts Lists System Information System Information shows Company Information and Revision History. Clicking the System Information button displays configuration and hardware settings for the PC. Note: In order to get to the Settings screen and various other functions an increased security level is required.

  • Page 58: Security

    Technical Manual & Parts Lists Security Security levels from lowest to highest are as follows: 1. Operator 2. Supervisor 3. Mechanic 4. Head Mechanic Operator is the default level. There is no code for this level. When the machine is turned on it is always at this level.

  • Page 59: Settings

    Technical Manual & Parts Lists Settings The Settings screen allows you to make adjustments to various aspects of how the machine functions. NOTE: A security level of Mechanic or higher is necessary to access this screen. The following pages provide more detailed information for each setting.
  • Page 60 Technical Manual & Parts Lists For the settings that have a check box a check in the box means the statement is true. For example, a check next to Air Sensor Enabled means that it is enabled and if air pressure drops below a certain point while the machine is running an error message box will be displayed.
  • Page 61 Technical Manual & Parts Lists Needle Tail Length When running a Sew & Jump pattern and the first repeat is finished the machine must move to the next pattern repeat. During this move a Needle Tail must be created in order to start sewing the next repeat properly.
  • Page 62 Technical Manual & Parts Lists NOTE: If Slow Speed is set to a value higher that Fast Speed then Slow Speed is automatically changed to equal the Fast Speed. Therefore, Slow Speed can never exceed Fast Speed. Limits: Minimum - 0 Maximum - 10 Default - 5 Unit of Measure - RPM Thread Break Enable Delay When the machine is not running the Thread Break eyes are dark as in an actual Thread Break condition.
  • Page 63 Technical Manual & Parts Lists Foot Height Medium Limit The maximum RPM allowed with the foot in the Medium position. Limits: Minimum - 0 Maximum - 1275 Default - 500 Unit of Measure - RPM Panel Cutter Error Delay The amount of time from when the Panel Cutter sensor is covered till an error is displayed. Limits: Minimum - 0 Maximum - 60...

  • Page 64: Efficiency Statistics

    Technical Manual & Parts Lists Efficiency Statistics Efficiency Statistics are calculated based on the amount of time the machine is in Run Mode (sewing) divided by the amount of time the machine is turned on. Time Display changes the format the On and Run times are displayed in. The Last Reset box displays the last time the Reset button was pressed resetting the On and Run Times to 0 (zero).

  • Page 65: Assembly Drawings & Parts Lists

    Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or...

  • Page 66: 11392D Quilter, Golden Eagle, Hd

    Technical Manual & Parts Lists 11392D Quilter, Golden Eagle, HD AAC Drawing Number 9000928 Rev 5 PART# DESCRIPTION NO. QTY PART# DESCRIPTION 5-035 COLLAR 1389288 COVER,PANEL,BENT,R 1388222 LINEAR SLIDE,FT,35MM 1389353 GUARD,MOTOR ASM 1388227 LINEAR SLIDE,RR,35MM 1389384 LEFT GUARD ASSY 1388673 DRIVE, 12 IN LEADSCREW 1389697 TRANSFER CARRIAGE ASSY...

  • Page 67: 1389234 Panel Eye Cutter Assembly

    Technical Manual & Parts Lists 1389234 Panel Eye Cutter Assembly AAC Drawing Number 1389234 Rev 1 QTY PART # DESCRIPTION 1389231 BRKT,UPPER,PC OK EYE 1389232 BRKT,LOWER,PC OK EYE 1389233 PLATE,NUT,M5@2X20MM 1975-412A PLATE,NUT,4-40,.95CTC FFRK44T-4 CABLE,EYE,12',NO END FFRK44T-6 CABLE,EYE,19',NO END FFSM312LVQ EYE,ELECTRIC,10-30VDC 12 in MMT9945 TAPE,REFLECTIVE,2"...

  • Page 68: 1389353 Motor Guard Assembly

    Technical Manual & Parts Lists 1389353 Motor Guard Assembly AAC Drawing Number 1389353 Rev 3 QTY PART # DESCRIPTION Page 128 1389183 REGULATOR ASSY Page 1389355 WELDMENT,GUARD 1389361 PANEL,TOP,MOTOR GUARD 1389362 PANEL, BACK MOTOR GUARD 1392404 PANEL, SIDE MOTOR GUARD 1392551 LEXAN FOR 1392404 1392631...

  • Page 69: 1389384 Left Guard Assembly

    Technical Manual & Parts Lists 1389384 Left Guard Assembly AAC Drawing Number 1389384 Rev 2 PART # DESCRIPTION QTY PART # DESCRIPTION 1337-4217 PIANO HINGE 2W OPEN NNH4-40 #4-40 HEX NUT 1389278 WELDMENT,GUARD,LEFT 14 SSFCM4X12 M4-0.7X12 FLAT ALLEN 1389289 PANEL,BENT,L SSFCM4X16 M4-0.7 X 16 FLAT ALLEN 1389349...

  • Page 70: 1389533 Front End Assembly

    Technical Manual & Parts Lists 1389533 Front End Assembly AAC Drawing Number 1389533 Rev 1 QTY PART # DESCRIPTION 1388560 FRONT GUARD ASSY,1392B Page 88 Page Page 90 1392087 TRAY ASSEMBLY, FRONT Page Page 92 1392306 ROLLER LIFT ASSEMBLY Page Page 94 1392448 TENSION ROLLER ASSEMBLY...

  • Page 71: 1389534 Bridge Assembly

    Technical Manual & Parts Lists 1389534 Bridge Assembly AAC Drawing Number 1389534 Rev 3 NO QTY PART # DESCRIPTION NO QTY PART # DESCRIPTION 1-006C TOP BRIDGE BEAM 1393864 FOOT ADJUSTMENT ASSY 1-008 ROD END HOUSING 1393867 P.FOOT SHAFT LEVER 1-009A PIVOT SHAFT, THREADED PIN 1393978...
  • Page 72 Technical Manual & Parts Lists...

  • Page 73: 1389566 Throat Plate Assembly

    Technical Manual & Parts Lists 1389566 Throat Plate Assembly AAC Drawing Number 1389566 Rev 7 NO QTY PART # DESCRIPTION NO QTY PART # DESCRIPTION 1-017 ROD END, PRESSER FOOT 3-036 BLOCK,BEARING 1-028 LOOPER DRIVE PITMAN ROD 4-013A ROD EXTENSION,KNIFE CYL 1-029 SHAFT,LOOPER,20MM 4-014A...

  • Page 74: 1389556 Base Assembly W/ Motors

    Technical Manual & Parts Lists 1389556 Base Assembly w/ Motors AAC Drawing Number 1389556 Rev 2 QTY PART # DESCRIPTION 1-001 BASE, QUILTER 1-002 LEFT BASE 1-003 RIGHT, BASE FOOT 1-007 MT,BEARING,ECCENTRIC 1388673 DRIVE, 12 IN LEADSCREW 1389033 BRKT,STRAIN RELIEF Page 120 1389815 MAIN DRIVE SHAFT ASM,D...

  • Page 75: 1389238 Transfer Carriage Rail

    Technical Manual & Parts Lists 1389238 Transfer Carriage Rail AAC Drawing Number 1389238 Rev 1 PART# DESCRIPTION 1389235 BRKT,SLIDE SUPPORT 1389237 SHAFT,SLIDE 1389239 SPACER, BEARING 1392013 BLOCK,SLIDE 1392016 WELDMENT,ROLLER SUPPORT BBSMK30GUU BEARING,LIN,FLG,30MM MM132-2X2 END CAP, 2x2 10-14GA SSSCM12X60 SCREW, M12 X 50 SSSCM6X16 M6X16 SOC CAP SCREW SSSCM6X35...
  • Page 76 Technical Manual & Parts Lists...

  • Page 77: 1389697 Transfer Carriage Assembly

    Technical Manual & Parts Lists 1389697 Transfer Carriage Assembly AAC Drawing Number 1389697 Rev 5 PART# DESCRIPTION 1388799 ROLLER,CHAIN TENSIONER 1389047 GUARD,BELT,BOTTOM 1389053 CLIP, GUARD MTG 1389238 TRANSFER CARRIAGE RAIL 1389447 BRACE WELDMENT,CARRIAGE 1389502 BRACE,RH 1389503 BRACE,LH 1389523 GUARD,BELT,BOTTOM 1389574 BAR,CHAIN TENSIONER 1389575 TORQUE LIMIT ASSY,50A17...
  • Page 78 Technical Manual & Parts Lists...

  • Page 79: 1392185 Rear Closure Assembly

    Technical Manual & Parts Lists 1392185 Rear Closure Assembly AAC Drawing Number 1392185 Rev 18 QTY PART # DESCRIPTION 1388150 CLIP,DOOR TRACK,1392 1388189 LATCH, SLIDING DOOR, 1392 1388675 WASHER,REAR CLOSURE 1389207 CUSHION,RUBBER,2 OD X 1/4 1389208 SPACER,LIGHT MTG 1389213 SPACER, .09 THK 1392180 REAR CLOSURE WELDMENT 1392186...

  • Page 80: 1389740 Isolator Base Assembly

    Technical Manual & Parts Lists 1389740 Isolator Base Assembly AAC Drawing Number 1389740 Rev 1 QTY PART # DESCRIPTION 1389739 BASE, ISOLATOR MMCE235 VIBATION ISOLATOR,SPRING NNH5/8-11 NUT,HEX,5/8-11 SSHC41064 5/8-11 X 1 HEX CAP SCREW SSHC41256F 5/8-11X4 HEX CAP FULL THD WWFS1/2 WASHER, FLAT, 1/2...

  • Page 81: 1392193 Operator Platform Assembly

    Technical Manual & Parts Lists 1392193 Operator Platform Assembly AAC Drawing Number 1392193 Rev 3 QTY PART # DESCRIPTION 5-016 ROLLER, PLATFORM 5-018 STEP, WELDMENT,PLATFORM 5-019 PLATFORM, OPERATOR, ASM BBUCFA205 BEARING, FLANGE UCFA NNHM10X1.5 NUT,HEX,M10X1.5 SSHCM10X35 SCREW,HEX CAP M10X35 SSSCM10X25 10M X 25MM, SOC CAP WWFM10 WASHER, FLAT, M10 I.D.
  • Page 82 Technical Manual & Parts Lists...

  • Page 83: 1392195 Thread Stand Frame Assembly

    Technical Manual & Parts Lists 1392195 Thread Stand Frame Assembly AAC Drawing Number 1392195 Rev 15 PART# DESCRIPTION NO. QTY PART# DESCRIPTION 5-001-2-L STAND,THREAD,FRAME LT 1392783 SUPPORT, WELDMENT 5-001-2-R STAND,THREAD,FRAME RT 1392825 FRAME, THREAD STAND 5-001-3B STAND, THREAD, FRAME 1392856 CROSS BAR WELDMENT 5-001-5 STAND, THREAD, FRAME...
  • Page 84 Technical Manual & Parts Lists...

  • Page 85: 1386740 Rear Feed Roll Drv. Assembly

    Technical Manual & Parts Lists 1386740 Rear Feed Roll Drv. Assembly AAC Drawing Number 1386740 Rev 0 NO QTY PART # DESCRIPTION 3-024A SPACER,LOWER REAR ROLL 3-027 BAR,ROLL ADJUSTMENT 3-031 SCREW,ROLL ADJUSTMENT 5-020-1 COLLAR, SHAFT,NARROW 6-039 SPANNER NUT, M30 X 1.5 1386729 REAR PULL ROLL BRG ASM 1386730...

  • Page 86: 1392415 Lubrication Assembly

    Technical Manual & Parts Lists 1392415 Lubrication Assembly AAC Drawing Number 1392415 Rev 7 QTY PART # DESCRIPTION AAQME-4-8U QUICK MALE ELBOW,1/4X1/8 AAQME-M4-M6 QUICK ELBOW CONNECTOR AAQUT-5-5 UNION TEE 5/32 AAQUY-5-5 QUICK UNION Y, 5/32 250 FT AATP4X2MW TUBING,NYLON,5/32OD MM78034PL INJECTOR,GREEN.015CC MM78035PL INJECTOR,YELLOW.025CC...

  • Page 87: 1392505 Remote Electrical Panel

    Technical Manual & Parts Lists 1392505 Remote Electrical Panel AAC Drawing Number 1392505 Rev 3 PART# DESCRIPTION NO. QTY PART# DESCRIPTION *AR 1392-WD2 DIAGRAM,WIRING,PANEL *AR FF209-503 TERMBLK,WAGO (11-20) 1392506 PANEL,BACK,ELECTRICAL *AR FF209-504 TERMBLK,WAGO (21-30) 1392507 COVER,PANEL FF280-319 TERMBLK,WAGO,SENSOR,DIN 1392508 DIN RAIL,35MM,12" LG FF280-402 JUMPERS 1392689...

  • Page 88: 1392744 Limit Switch Assembly

    Technical Manual & Parts Lists 1392744 Limit Switch Assembly AAC Drawing Number 1392744 Rev 2 PART# DESCRIPTION 1392497 BRACKET,LIMIT SWITCH FFGLLA01A1B SWITCH, LIMIT, ROLLER ARM FFM4518 STRAIN RELIEF,LIQ TIGHT SSSCM4X30 SCREW,SOC CAP,M4-0.7X30 SSSCM5X16 SCREW,SOC CAP,M5-0.8 X 16 WWFM4.3 WASHER, FLAT, M4 WWFM5 WASHER, FLAT, M5 I.D.

  • Page 89: 1392898 Y Axis Drive Idler Assembly

    Technical Manual & Parts Lists 1392898 Y Axis Drive Idler Assembly AAC Drawing Number 1392898 Rev 4 QTY PART # DESCRIPTION 1392501 IDLER, BEARING ASSEMBLY 1393968 DRIVE, IDLER, WELDMENT NNJM8 NUT,JAM,M8,ZINC PLATED SSSCM8X25 SCREW,SOC CAP,M8X25 SSSCM10X25 10M X 25MM, SOC CAP WWF3/8 WASHER,FLAT,3/8 OR 10MM WWLM10...

  • Page 90: Aae1392 6 Station Solenoid Assembly

    Technical Manual & Parts Lists AAE1392 6 Station Solenoid Assembly AAC Drawing Number 192121B Rev 2 QTY PART # DESCRIPTION KQR07-09 Reducing Fitting SY3140-5LZ Solenoid SX3000-53-1A Left Cap End SX3000-52-1A Right Cap End SX3000-51-15A Block SX3000-50-1A-N7 Block Assy. 5.38 VZ1000-11-1-9 Din Rail AN203-KM8 Port Silencer...

  • Page 91: 1393854 Filter Regulator Lockout Assembly

    Technical Manual & Parts Lists 1393854 Filter Regulator Lockout Assembly AAC Drawing Number 1393854 Rev 1 PART# DESCRIPTION 32003033 BRKT,REGULATOR,DUAL AA198-5110 FILTER/REGULATOR/LOCKOUT AAQME-4-4 ELBOW, MALE,1/4X1/4NPT AAQME-4-8 ELBOW,QUICK MALE,1/4X1/8 AAV125B PILOT VALVE MM4554K11 PLUG, 1/8" PIPE NNK1/4-20 NUT,HEX,KEP,1/4-20,W/LOCK NNK6-32 KEP NUT, 6-32 SSPS80080 #6-32 X 3/8 LG PAN HD SSSC01048...
  • Page 92 Technical Manual & Parts Lists...

  • Page 93: 1392367 Backplane Assembly, Back Side

    Technical Manual & Parts Lists 1392367 Backplane Assembly, Back Side AAC Drawing Number 1392367 Rev 5 NO QTY PART DESCRIPTION 1392657 SURGE SUPPRESSOR ASSY 1392658 CABLE ASSY,TRANS PRI 1392659 CABLE ASSY,E-STOP RCPT 1392661 CABLE ASSY,CLOSER RCPT 1392662 CABLE ASSY,SPIRAL RCPT 1392685 PANEL, FRONT BACKPLANE EECA491024...
  • Page 94 Technical Manual & Parts Lists...

  • Page 95: 1388560 Front Guard Assembly

    Technical Manual & Parts Lists 1388560 Front Guard Assembly AAC Drawing Number 1388560 Rev 0 NO. QTY PART # DESCRIPTION NO. QTY PART # DESCRIPTION 1337-4217 HI NGE,PI ANO,S/S, 2W, .06THK. MM1897A24 HANDLE,DOOR,PULL,OVAL,5/8 1388106 PLATE,FRONT COVER MM3471T23 CLAMP,ROPE,WI RE,3/16", STEEL 1388561 BRACKET, RI GHT GUARD LI FT MM4554K12 PLUG, 1/4"...
  • Page 96 Technical Manual & Parts Lists...

  • Page 97: 1392087 Front Tray Assembly

    Technical Manual & Parts Lists 1392087 Front Tray Assembly AAC Drawing Number 1392087 Rev 7 QTY PART # DESCRIPTION 1387004 BRACKET, SENSOR MOUNT 1387005 BRACKET, TICKING SENSOR 1389424 COVER, SENSOR BRACKET 1389427 BRKT,RH 1389432 BRKT,LH 1392040 MATERIAL TRAY ASSEMBLY 1392084 MATERIAL END, LEFT 1392085 MATERIAL END, RIGHT...

  • Page 98: 1393940 Regulator Valve Assembly

    Technical Manual & Parts Lists 1393940 Regulator Valve Assembly AAC Drawing Number 1393940 Rev 1 QTY PART # DESCRIPTION 1393939 PLATE,VALVE/REG MTG AAQME-4-4 ELBOW, MALE,1/4X1/4NPT AAVH202-N02 VALVE,HAND,2 POSITION...

  • Page 99: 1392306 Roller Lift Assembly

    Technical Manual & Parts Lists 1392306 Roller Lift Assembly AAC Drawing Number 1392306 Rev 3 QTY PART # DESCRIPTION 1389085 ROLLER LIFT ASSEMBLY, LT 1392095 ROLLER LIFT ASSEMBLY 1393895 COLLAR, END PLAY 3-005 ROLLER...
  • Page 100 Technical Manual & Parts Lists...

  • Page 101: 1392448 Tension Roller Assembly

    Technical Manual & Parts Lists 1392448 Tension Roller Assembly AAC Drawing Number 1392448 Rev 6 PART # DESCRIPTION PART # DESCRIPTION 1345119 TUBE,SPACER,ROLLER MM2315T528 WHEEL, PHENOLIC 1392877 SHAFT, TENSION ROLLER MM50B17M STEEL SPROCKET,17T,5/8P 1392878 ROLLER, TICK TENSION NNH3/8-16 NUT,HEX,3/8-16 1392881 SUPPORT, TENSION ROLLER NNJ5/16-24 NUT,JAM,5/16-24...

  • Page 102: 1392580 Bag Closing Mount Assembly

    Technical Manual & Parts Lists 1392580 Bag Closing Mount Assembly AAC Drawing Number 1392580 Rev 9 QTY PART # DESCRIPTION 1389066 WLDMT,TICK TRAY SUPPORT 1389970 STOP BLOCK,30MM RAIL 1392168 SUPPORT, BAR, BAG CLOSER 1392600 LIMITER 1392601 TRACK TRAY 1392605 END STOP-GUARD 1392638 BRACKET Page 134...

  • Page 103: 1392897 Pleat Prevention Assembly

    Technical Manual & Parts Lists 1392897 Pleat Prevention Assembly AAC Drawing Number 1392897 Rev 0 QTY PART # DESCRIPTION Page 135 1392151 B POLE ASSEMBLY Page 1392155 MOUNT, MOTOR 1392645 GUARD,MOTOR 1392693 MOTOR ASSY,SPIRAL ROLLER 1961-369 PULLEY, CLUTCH, 20T, 3/8 GG285L050 BELT, 3/8P, 76T, 1/2W SSSCM5X16...

  • Page 104: 1392978 Front Feed Assembly

    Technical Manual & Parts Lists 1392978 Front Feed Assembly AAC Drawing Number 1392978 Rev 5 PART PART NO QTY DESCRIPTION NO QTY DESCRIPTION 1389433 SPACER,3/4X1.5X.38ID 1392937 FRONT FEED ROLLER SUB-ASY 1392102 CHAIN, INSIDE, 24.375 L 1392938 LEFT SPROCKET IDLER ASY 1392144 CHAIN, OUTSIDE, 81.875 L 2-057...

  • Page 105: 1392935 Front Left Roller Sub-Assembly

    Technical Manual & Parts Lists 1392935 Front Left Roller Sub-Assembly AAC Drawing Number 1392935 Rev 7 NO. QTY PART # DESCRIPTION NO. QTY PART # DESCRIPTION 1392018 KEY, 8 MM X 25 MM SSAS024128 3/8 X 2 X 5/16-18 SHLD, BOLT 1392278 COLLAR, CLUTCH BEARING SSSCM10X25...

  • Page 106: 1392936 Front Right Roller Sub-Assembly

    Technical Manual & Parts Lists 1392936 Front Right Roller Sub-Assembly AAC Drawing Number 1392936 Rev 5 NO. QTY PART # DESCRIPTION NO. QTY PART # DESCRIPTION 1392883 SPACER, FLANGE BEARING SSAS024128 3/8 X 2 X 5/16-18 SHLD, BOLT 1392886 MOUNT, CYLINDER BASE SSSCM10X35 CAP SCREW 10MM X 55MM 1392889...

  • Page 107: 1392937 Front Feed Roller Sub-Assembly

    Technical Manual & Parts Lists 1392937 Front Feed Roller Sub-Assembly AAC Drawing Number 1392937 Rev 1 QTY PART # DESCRIPTION 1392018 KEY, 8 MM X 25 MM 1392869 SUPPORT LINK, BEARING 1392870 SUPPORT LINK, BEARING 1392871 STEEL SPROCKET,17T,5/8P 1392872 ROLLER,DRIVEN,FRONT BBUCFL205 BEARING, FLANGE UCFL WWFM12...

  • Page 108: 1392938 Left Sprocket Idler Assembly

    Technical Manual & Parts Lists 1392938 Left Sprocket Idler Assembly AAC Drawing Number 1392938 Rev 5 PART # DESCRIPTION 1388773 IDLER SPROCKET ASSEMBLY 1392820 PLATE,ADAPTOR,BEARING 1392853 SHAFT MOUNT, M20X2.5 1392867 SHAFT MOUNT, M20X2.5 CCCL16F COLLAR,1" CLAMP TYPE MMN2 TIGHTENER SHAFT,1"DIA SSSCM12X25 SCREW , M12 X 25 SSSCM12X30 SCREW , SOC CAP, M12 X 30 SSSCM12X35 SCREW , M12 X 35...

  • Page 109: 1393922 Tensioner Assembly

    Technical Manual & Parts Lists 1393922 Tensioner Assembly AAC Drawing Number 1393922 Rev 3 NO QTY PART # DESCRIPTION 1389188 SPACER,3/4 X 3 X 3-1/2 1389189 SHAFT,PIVOT,TENSION BARS 1389469 KNOB,THREADED,M8 1389522 SPACER,3/4 X 3 X 1-3/4 1389617 ROD,STOP,TENSION BARS 1393927 ARM,PIVOT 1393928 PLATE,TENSION BAR MTG...

  • Page 110: 1389023 Center Insert Mount Bearing

    Technical Manual & Parts Lists 1389023 Center Insert Mount Bearing AAC Drawing Number 1389023 Rev 2 QTY PART # DESCRIPTION 1393993 RETAINER, CARTRIDGE BRG 1393995 MOUNT, INSERT BRG, CENTER AAF3/16 CLAMP, BLACK PLASTIC BBER208TMC BEARING,INSERT,SKWEZLOC SSBCM5X16 M5-0.8 X 16 BUTTON CAP SSSCM5X10 M5-0.8 X 10 SOC CAP WWLM5...

  • Page 111: 1389509 Presser Feet And Needle Bars

    Technical Manual & Parts Lists 1389509 Presser Feet and Needle Bars AAC Drawing Number 1389509 Rev 1 QTY PART # DESCRIPTION 1389031 EYELET,NEEDLE THREAD,19M 1393860 NEEDLE CLAMP, RT OUTSIDE 1393861 NEEDLE CLAMP, R.MIDDLE 1393900 NEEDLE CLAMP,L. MIDDLE 1393901 NEEDLE CLAMP,LEFT 1393902 PLATE,WASHER 1393921...

  • Page 112: 1392124 Needle Thread Mount Assembly

    Technical Manual & Parts Lists 1392124 Needle Thread Mount Assembly AAC Drawing Number 1392124 Rev 11 NO QTY PART # DESCRIPTION 1388903 PLATE,NESION RELEASE, TOP 1389274 DUAL THD BK DETECTOR ASM 1389279 BRACKET, THREAD ROD 1389460 PLATE,TENSION RELEASE 1392291 GUIDE, THREAD TENSION ASM 1392359 TUBE, THREAD GUIDE (1-046) 1392668...

  • Page 113: 1393864 Foot Adjustment Assembly

    Technical Manual & Parts Lists 1393864 Foot Adjustment Assembly AAC Drawing Number 1393864 Rev 6 QTY PART # DESCRIPTION 1389003 BAR,EYELET 1389004 BLOCK,BEARING,SHORT 1389014 BAR,EYELET,SHORT,LEFT 1389015 BAR,EYELET,SHORT,RIGHT Page 107 1389199 BEARING,RIGHT HAND Page Page 108 1389200 BEARING LEFT HAND Page 1389524 CLAMP COLLAR,M20,W/SHLDR 1392019...

  • Page 114: 1389199 Right Hand Bearing

    Technical Manual & Parts Lists 1389199 Right Hand Bearing AAC Drawing Number 1389199 Rev 1 QTY PART # DESCRIPTION 1392815 BLOCK,BEARING BBGE20ES2RS BEARING,SPHERICAL PLAIN,2 BBGER205-25 BEARING,BALL,25MMB,CLAMP SSBCM5X8 M5 X 8MM BUT HEAD WWFM5 WASHER, FLAT, M5 I.D.

  • Page 115: 1389200 Left Hand Bearing

    Technical Manual & Parts Lists 1389200 Left Hand Bearing AAC Drawing Number 1389200 Rev 0 QTY PART # DESCRIPTION 1392815 BLOCK,BEARING BBGE20ES2RS BEARING,SPHERICAL PLAIN,2 BBGER205-25 BEARING,BALL,25MMB,CLAMP SSBCM5X8 SCREW,BUTTON CAP WWFM5 WASHER, FLAT, M5 I.D.

  • Page 116: 1393986 Tie-Rod Assembly

    Technical Manual & Parts Lists 1393986 Tie-Rod Assembly AAC Drawing Number 1393986 Rev 1 QTY PART # DESCRIPTION 1392719 TIE ROD WELDMENT,NDL 1393984 NUT,TIE-ROD, RH THREAD 1393985 NUT,TIE-ROD, LH THREAD SSSSM6X10 M6 SET SCREW, 10MM L...

  • Page 117: 1393994 Lh Insert Mount Bearing Assembly

    Technical Manual & Parts Lists 1393994 LH Insert Mount Bearing Assembly AAC Drawing Number 1393994 Rev 2 QTY PART # DESCRIPTION 1393992 MOUNT, INSERT BEARING 1393993 RETAINER, CARTRIDGE BRG AAF3/16 CLAMP, BLACK PLASTIC BBER208TMC BEARING,INSERT,SKWEZLOC SSBCM5X12S SCREW,BUTTON CAP,S/S SSSCM5X10 SCREW,SOC CAP,M5-0.8 X 10 WWLM5 M5 LOCK WASHER...

  • Page 118: 1388673 12In Leadscrew Drive

    Technical Manual & Parts Lists 1388673 12in Leadscrew Drive AAC Drawing Number 1388673 Rev 5 PART# DESCRIPTION NO. QTY PART# DESCRIPTION 1-033 PULLEY, TIMING, 40T 1389298 BEARING THRUST NUT 4-086 LEAD SCREW,1392C 1389299 PUSH ROD,61MM DIA 4-087 COUPLING, WORM GEAR 1389301 BRACKET, BELLOW, 4.25 ID 4-088...

  • Page 119: 1389495 Retainer Drive Assembly

    Technical Manual & Parts Lists 1389495 Retainer Drive Assembly AAC Drawing Number 1389495 Rev 6 NO QTY PART # DESCRIPTION NO QTY PART # DESCRIPTION 1-093 ECCENTRI C, RETAI NER DRI VE 1392641 BLOCK, RETAI NER 3-020 SHAFT, TAKE-UP, PULLEY 1392991 U-JOI NT, RETAI NER, ASM 3-021A PULLEY, GEAR, 40MM WI DE...

  • Page 120: 1389383 Oldham Offset Coupling

    Technical Manual & Parts Lists 1389383 Oldham Offset Coupling AAC Drawing Number 1389383 Rev 0 QTY PART # DESCRIPTION 1389402 COUPLING HALF 1389403 SPIDER FOR COUPLING SSSSM8X10 M8X10 SOC SET SCRW...

  • Page 121: 1392991 U-Joint, Retainer Assembly

    Technical Manual & Parts Lists 1392991 U-Joint, Retainer Assembly AAC Drawing Number 1392991 Rev 1 QTY PART # DESCRIPTION 1392990 U-JOINT MOD UJCJ6489K BOOT, UNIVERSAL JOINT EE6X750 TIE WRAP - Small. SSSCM6X12 M6X12 SOC CAP SCREW...
  • Page 122 Technical Manual & Parts Lists...

  • Page 123: 1393998 Right Needle And Presser Foot Drive Assembly

    Technical Manual & Parts Lists 1393998 Right Needle and Presser Foot Drive Assembly AAC Drawing Number 1393998 Rev 11 NO QTY PART # DESCRIPTION **1389016B GUI DE, SPRI NG, PRESSER 1389539 NEEDLE BAR 1389640 DRI VE PI N, NEEDLE BAR 1393870 RETAI NER, LI NEAR 1393908...
  • Page 124 Technical Manual & Parts Lists...

  • Page 125: 1393999 Left Needle And Presser Foot Drive Assembly

    Technical Manual & Parts Lists 1393999 Left Needle and Presser Foot Drive Assembly AAC Drawing Number 1393999 Rev 11 PART # DESCRIPTION **1389016B GUIDE, SPRING, PRESSER FT 1389539 NEEDLE BAR CONNECTOR 1389640 DRIVE PIN, NEEDLE BAR 1393870 RETAINER, LINEAR BEARING 1393908 LINK,NEEDLE BAR DRIVE 1393973...
  • Page 126 Technical Manual & Parts Lists...

  • Page 127: 1389815 Main Drive Shaft Assembly

    Technical Manual & Parts Lists 1389815 Main Drive Shaft Assembly AAC Drawing Number 1389815 Rev 2 PART# DESCRIPTION NO. QTY PART# DESCRIPTION 1-010A SHAFT SUPPORT, BEARING 1388774 KEY,8MM X 10MM X 34MM 1-012A MAIN SHAFT COUPLING 1392509 PULLEY, GEAR, 38MM WIDE 1-017 ROD END, PRESSER FOOT 1392548...

  • Page 128: 1392070 Roll Servo Drive Assembly

    Technical Manual & Parts Lists 1392070 Roll Servo Drive Assembly AAC Drawing Number 1392070 Rev 1 QTY PART # DESCRIPTION 1392809 PULLEY, GEAR, 38MM WIDE C302N0410MT20 GEARBOX, CONC. HELICAL SGMPH15AAE41D MOTOR, SERVO, 1.5KW...

  • Page 129: 1392071 Carriage Servo Drive Assembly

    Technical Manual & Parts Lists 1392071 Carriage Servo Drive Assembly AAC Drawing Number 1392071 Rev 0 QTY PART # DESCRIPTION 1-034 PULLEY, TIMING, 18T 2-033-M MOUNT, MOTOR 2-046 BRACKET, MOTOR 6-010A SPACER, MOTOR MOUNT SGMGH30ACA61 MOTOR, SERVO 3.0KW...

  • Page 130: 1392082 Needle Bar Drive Assembly

    Technical Manual & Parts Lists 1392082 Needle Bar Drive Assembly AAC Drawing Number 1392082 Rev 4 QTY PART # DESCRIPTION 1389827 PULLEY, GEAR, L 38MM WIDE 1392261 SPACER, MOTOR, BASE 1392499 MOUNT, MOTOR, BOTTOM 1392654 MOUNT, MOTOR, BASE 1392741 WASHER,PULLEY SGMGH30ACA61 MOTOR, SERVO 3.0KW SSSCM12X30...

  • Page 131: 1392125 Rear Thread Tension Assembly

    Technical Manual & Parts Lists 1392125 Rear Thread Tension Assembly AAC Drawing Number 1392125 Rev 11 PART# DESCRIPTION NO. QTY PART# DESCRIPTION 5-047C-M MOUNT, MOD. REAR THRD AACSDA20X10B COMPACT,CYLINDER,20MM 5-059 PLATE,TENSION RELEASE AAQME-4-10 ELBOW,QUICK MALE 1389271 THREAD BREAK DETECTOR FFRK44T-4 CABLE,EYE,12',NO END 1389455 PLATE,TENSION RELEASE...

  • Page 132: 1392196 Take-Up Looper Assembly

    Technical Manual & Parts Lists 1392196 Take-up Looper Assembly AAC Drawing Number 1392196 Rev 3 PART# DESCRIPTION 2-081 DRIVE ARM, REAR BTRFLY 4-051 GUIDE, THREAD ROD 4-052 SHAFT, REAR TAKE-UP 4-053 ROD, REAR TAKE-UP 4-083 TAKE-UP, THREAD ROCKER 4-084A GUIDES, THREAD 5-033 SHAFT, RODEND,REAR BTRFLY 1392304...

  • Page 133: 1389575 Torque Limit Assembly

    Technical Manual & Parts Lists 1389575 Torque Limit Assembly AAC Drawing Number 1389575 Rev 1 QTY PART # DESCRIPTION 1389569 HUB,MODIFIED,22MM B BB250AX_540 BUSHING,.54L,FOR TORQUE L MM250AG517 SPROCKET,TORQUE LIMITER...

  • Page 134: 1392230 Guard Assembly

    Technical Manual & Parts Lists 1392230 Guard Assembly AAC Drawing Number 1392230 Rev 1 QTY PART # DESCRIPTION 1392466 GUARD, BASE FIXTURE,S 1392561 GUARD,BASE ASSM,L 1392562 GUARD, CLOSURE,L 1392564 GUARD, CLOSURE,S SSSCM5X10 SCREW,SOC CAP,M5-0.8 X 10 WWFM5 WASHER, FLAT, M5 I.D. WWLM5 M5 LOCK WASHER...

  • Page 135: 1389183 Regulator Assembly

    Technical Manual & Parts Lists 1389183 Regulator Assembly AAC Drawing Number 1389183 Rev 1 QTY PART # DESCRIPTION 1389182 PLATE,REGULATOR MTG 31103701 BRKT,PRESSURE GAUGE AA198-5031 0-160PSI AIR GAGE 1/8NPT AA198-5032 0-60PSI AIR GAGE 1/8NPT AA198-RP3 REGULATOR,PRECISION AIR AAF10289 T-FITTING 1/4" NPT AAQMC-5-8 QU.
  • Page 136 Technical Manual & Parts Lists...

  • Page 137: 1392366 Front Side Backplane Assembly

    Technical Manual & Parts Lists 1392366 Front Side Backplane Assembly AAC Drawing Number 1392366 Rev 5 QTY PART # DESCRIPTION 1392515 REGEN RESISTOR ASSY 1392663 CABLE ASSY,MP2300 I/O 1392664 CABLE ASSY,QUILTER I/O 1392665 CABLE ASSY,FLUOR LIGHT 1392684 PANEL,FRONT BACKPLANE 1392688 CABLE ASSY,CARR LIMIT 1392691 CABLE ASSY,SSR...

  • Page 138: 1392545 Material Tension Rack

    Technical Manual & Parts Lists 1392545 Material Tension Rack AAC Drawing Number 1392545 Rev 7 QTY PART # DESCRIPTION 1389408 ROD SUPPORT/BRAKE ASSY 1389410 BLOCK,BRAKE,BOTTOM 1392453 LEG WELDMT,MATL RACK 1392542 PLATE,CAP,FRICTION BRAKE, 1392543 BLOCK,DELRIN,S 1393802 3/8-24 X 2 HEX HEAD FULL THD 1393803 NUT, WING, 3/8-24 MM331...

  • Page 139: 1392972 Lh Small Tension Clamp Assembly

    Technical Manual & Parts Lists 1392972 LH Small Tension Clamp Assembly AAC Drawing Number 1392972 Rev 8 NO QTY PART # DESCRIPTION 1389408 ROD SUPPORT/BRAKE ASSY 1389410 BLOCK,BRAKE,BOTTOM 1392542 PLATE,CAP,FRICTION BRAKE, 1392543 BLOCK,DELRIN,S 1392964 MATERIAL BRKT 1393802 3/8-24 X 2 HEX HEAD FULL 1393803 NUT, WING, 3/8-24 MM331...

  • Page 140: 1392973 Rh Small Tension Clamp Assembly

    Technical Manual & Parts Lists 1392973 RH Small Tension Clamp Assembly AAC Drawing Number 1392973 Rev 8 QTY PART # DESCRIPTION 1389408 ROD SUPPORT/BRAKE ASSY 1389410 BLOCK,BRAKE,BOTTOM 1392542 PLATE,CAP,FRICTION BRAKE, 1392543 BLOCK,DELRIN,S 1392966 MATERIAL BRKT 1393802 3/8-24 X 2 HEX HEAD FULL THD 1393803 NUT, WING, 3/8-24 MM331...

  • Page 141: 1392959 Closer Assembly

    Technical Manual & Parts Lists 1392959 Closer Assembly AAC Drawing Number 1392959 Rev 5 NO QTY PART # DESCRIPTION NO QTY PART # DESCRIPTION 1386744 FOOT LEFT LEVER,BAG SEW SSFCM6X10 M6 X 20 FLAT ALLEN 1388177 POST, THREAD STAND,BC1 SSSCM5X12 M5 X 12 SOC CAP SC 1389228 LATCH, BAG CLOSER...

  • Page 142: 1392151 B Pole Assembly

    Technical Manual & Parts Lists 1392151 B Pole Assembly AAC Drawing Number 1392151 Rev 1 QTY PART # DESCRIPTION 1392110 ROLL,SPIRAL FLIGHTED 1392150 MOUNTING BLK, BEARING 1392156 PULLEY, CLUTCH, 20T, 25mm BBNAP205-25 BEARING, PILLOWBLOCK...

  • Page 143: 1389274 Dual Thread Break Detector Assembly

    Technical Manual & Parts Lists 1389274 Dual Thread Break Detector Assembly AAC Drawing Number 1389274 Rev 3 NO QTY PART # DESCRIPTION 50 1386421 THREAD BREAK DETECT MOD 1388717 BRACKET,SENSOR,NEW STYLE 1389275 PLATE, DUAL THREAD STOP 42 1392325 STAND-OFF, RAI L 1392326 BAR,SENSOR MTG,MI DDLE 1392902...
  • Page 144 Technical Manual & Parts Lists...

  • Page 145: 1393875 Footlift Adjusting Knob Assembly

    Technical Manual & Parts Lists 1393875 Footlift Adjusting Knob Assembly AAC Drawing Number 1393875 Rev 0 QTY PART # DESCRIPTION 1331725 PLATE,WASHER,.266@.75 1389713 5MM X 5MM X 25MM KEY 1392004 PLATE,NUT,M6 1392373 INDICATOR, FOOT HEIGHT 1392482 SHAFT,ADJUSTING 1392484 PLATE,GEAR MTG 1392486 PLATE,WORM MTG 1392487...

  • Page 146: 1392291 Thread Tension Guide Assembly

    Technical Manual & Parts Lists 1392291 Thread Tension Guide Assembly AAC Drawing Number 1392291 Rev 7 NO QTY PART # DESCRIPTION *107 1389915 WASHER, THREAD TENS. OPEN 1392290 GUIDE, THREAD GUIDE 107 1392308 SPACER, THREAD TENSION 107 1392987 PIN, TENSION OPENER,LONG 107 SCT1392 TENSION ASSY,1392...

  • Page 147: 1392304 Bearing Butterfly Assembly

    Technical Manual & Parts Lists 1392304 Bearing Butterfly Assembly AAC Drawing Number 1392304 Rev 0 QTY PART # DESCRIPTION 1392221 GUIDE, LOOPER THREAD(4-082A-2) 1392491 MOUNT, ROLLER BEARING BB60042RS BEARING,BALL,20 ID,42 OD SSSCM5X16 SCREW,SOC CAP,M5-0.8 X 16 WWLM5 M5 LOCK WASHER...

  • Page 148: 1392846 Butterfly Drive Assembly

    Technical Manual & Parts Lists 1392846 Butterfly Drive Assembly AAC Drawing Number 1392846 Rev 2 QTY PART # DESCRIPTION 1389010 CRANK,FRONT BUTTERFLY 1392835 CRANK,FRONT BUTTERFLY 1392836 LINK,BUTTERFLY DRIVE BBAS1226 WASHER,THRUST,12MM ID BBNA4901A2RSR BEARING,NEEDLE,12MM ID MM1105K71 GREASE FITTING, M6X1 MM5909K71 WASHER,THRUST,10MM ID SSASM12M25 SCREW,ALLEN SHOULDER SSSCM8X30...

  • Page 149: 1389024 Large Eccentric Assembly

    Technical Manual & Parts Lists 1389024 Large Eccentric Assembly AAC Drawing Number 1389024 Rev 3 NO QTY PART # DESCRIPTION 2-060 NEEDLE BAR ECCENTRICS 2-061 NDL BAR ECCENTRIC PLATE 2-062M ECCENTRIC INSERT,LARGE BB60162RS BEARING, RADIAL, SEALED MMN1302475 RING,RET,BLVD,INT,4.75" SSSSM16X20 M16X2X20 SET SCREW...

  • Page 150: 1389025 Small Eccentric Assembly

    Technical Manual & Parts Lists 1389025 Small Eccentric Assembly AAC Drawing Number 1389025 Rev 4 NO QTY PART # DESCRIPTION 2-063A ECCENTRIC, LINKAGE 2-064BM ECCENTRIC INSERT,SMALL 2-065 CAP, LOOPER ECENTRIC BB60132RS BEARING, RADIAL,SEALED MMN1302375 RING,RET,BLVD,INT,3.75" SSSCM5X12 M5 X 12 SOC CAP SC SSSCM12X20 SCREW, M12 X 20...

  • Page 151: 1388222 Front Linear Slide, 35Mm

    Technical Manual & Parts Lists 1388222 Front Linear Slide, 35MM AAC Drawing Number 1388222 Rev 1 QTY PART # DESCRIPTION 1388221 BRKT,SLIDE SUPPORT,35MM 1388223 SHAFT,SLIDE,35MM 1388224 SPACER, BEARING,35MMX1" 1388225 SPACER, BEARING,35MMX1/4" 4-001A BLOCK,SLIDE,35MM SHAFT BBSMK35GUU BEARING,LIN,FLG,35MM SSSCM6X20 SCREW, SOCKET CAP SSSCM6X40 SCREW, SOCKET CAP, M6X40...

  • Page 152: 1388227 Right Linear Slide, 35Mm

    Technical Manual & Parts Lists 1388227 Right Linear Slide, 35MM AAC Drawing Number 1388227 Rev 1 QTY PART # DESCRIPTION 1388221 BRKT,SLIDE SUPPORT,35MM 1388223 SHAFT,SLIDE,35MM 1388224 SPACER, BEARING,35MMX1" 1388225 SPACER, BEARING,35MMX1/4" 4-001A BLOCK,SLIDE,35MM SHAFT BBSMK35GUU BEARING,LIN,FLG,35MM SSSCM6X20 SCREW, SOCKET CAP SSSCM6X40 SCREW, SOCKET CAP, M6X40...
  • Page 153 Technical Manual & Parts Lists...

  • Page 154: 1392364 Control Cabinet Assembly

    Technical Manual & Parts Lists 1392364 CONTROL CABINET ASSEMBLY AAC Drawing Number 1392364 Rev18 NO QTY PART # DESCRIPTION NO QTY PART # DESCRIPTION AR 1392-WD1 WD,BACK PANEL 1* EEB2E10A CABLE,POWER,10M,SERVO AR 1392-WD2 WD,QUILTER PANEL 1* EEB51CE05A CABLE,POWER,5M,SERVO 4080-4215A CABLE,3 PIN FM MOLEX 1* EEJEPMCW6022 TERMINATION,BLOCK 1* 51175B...
  • Page 155 Technical Manual & Parts Lists...

  • Page 156: 1392C-Pd Pneumatic Diagram

    Technical Manual & Parts Lists 1392C-PD Pneumatic Diagram 125487B...

  • Page 157: 1392-Wd1 Cabinet Wiring Diagram

    Technical Manual & Parts Lists 1392-WD1 Cabinet Wiring Diagram 125349A...

  • Page 158: 1392-Wd2 Quilter Panel Wiring Diagram

    Technical Manual & Parts Lists 1392-WD2 Quilter Panel Wiring Diagram 125370A...
  • Page 159 Technical Manual & Parts Lists...
  • Page 160 Atlanta Attachment Company (AAC) Statement of Warranty Manufactured Products Atlanta Attachment Company warrants manufactured products to be free from defects in material and workmanship for a period of eight hundred (800) hours of operation or one hundred (100) days whichever comes first. Atlanta Attachment Company warrants all electrical components of the Serial Bus System to be free from defects in material or workmanship for a period of thirty six (36) months.
  • Page 161 Declaración de Garantía Productos Manufacturados Atlanta Attachment Company garantiza que los productos de fabricación son libres de defectos de material y de mano de obra durante un período de ochocientos (800) horas de operación o cien (100) días, cual llegue primero.
  • Page 162 Atlanta Attachment Company 362 Industrial Park Drive Lawrenceville, GA 30046 770-963-7369 www.atlatt.com Printed in the USA...

Table of Contents
