ShareLink Pro 2000 • Setup Guide (Continued)

Operation Using a Mobile Device

The ShareLink Pro 2000 App can be downloaded from the Google Play
iOS devices). This app allows you to present photos, documents, web pages, device screenshots, and the device camera (see
instructions below). The ShareLink Pro 2000 also supports iOS screen mirroring.
Using the ShareLink Pro App
Connecting to a ShareLink Pro Receiver
Once the ShareLink Pro app is installed on the device, follow these steps to connect to the ShareLink Pro 2000 receiver:
1. Ensure that the ShareLink Pro 2000 is powered on and connected to the network.
2. Connect your mobile device to an external WAP that is on the same network as the ShareLink Pro 2000 receiver. Ensure that
the WAP and the ShareLink Pro 2000 are wired to the same network.
3. Open the ShareLink Pro 2000 app and select the desired receiver from the list. Verify the receiver hostname and IP address
on the standby screen (see
Figure 8. ShareLink Pro App - Receiver Selection
4. When prompted, enter the login code shown on the standby screen (see
When connection is established, the app shows the Share screen (see figure 8 below).
Presenting Content
Use the Share screen to present content. Select the
1 1
2 2
3 3
4 4
Figure 9. Share Screen (Mobile App)
figure 5,
and , on page 3).
1 2
button to see the options below:
5 5
store (for Android devices) or the App Store
TM
NOTE:
To refresh the list, drag down and
release the list. If the unit is not listed,
select the New Connection button
and enter the hostname or IP address as
instructed on the app screen.
figure 5, ).
3
HDMI — Click this button to share the connected HDMI
1
source as a window.
Share with Camera — Click this button to share an
2
image taken by the device camera.
NOTE:
For iOS devices, a Share Website option
is also available to share the device web browser.
3
Share Image or Video — Click this button to browse to
a specific video or image file on your device. Select the
video or image file to present it on the display.
4
Mirror Screen — Click this button to automatically
mirror your device screen on the display device. Select
Stop Presenting to stop the presentation.
NOTE:
For iOS devices, follow the on-screen
instructions for mirroring the device screen.
5 Leave — Click this button and select Leave Session
to exit the presentation session.
(for
®
5
