Installation, Operation and Maintenance APP 11 - 13 / APP S 11 - 13
4.4 APP / APP S11-13
Pump size
Code number APP
Code number APP S
Code number APP ATEX 3)
cm³/rev.
Geometric displace-
ment
in³/rev.
Pressure
barg
Max. outlet 1)
pressure continuous
psig
barg
Min. outlet 1) pressure
psig
barg
Inlet pressure
continuous
psig
barg
Max. inlet pressure.
peak
psig
Speed
Min. speed
rpm
continuous
Max. speed
rpm
continuous
Typical ow - Flow curves available in item 5
1000 rpm at max.
m³/h
pressure
1500 rpm at max.
m³/h
pressure
1200 rpm at max.
gpm
pressure
Technical speci cations
°C
Media 2) temperature
°F
°C
Ambient tempera-
ture
°F
kg
Weight (dry)
lb
Sound pressure level 4) dB(A)
m²
Footprint with IEC
motor 5)
foot²
Typical motor size
Max. speed at max.
kW
pressure
1200 rpm at max.
HP
pressure
Nm
Torque at max. outlet
pressure
lbf-ft
1)
For lower and higher pressure, please contact Danfoss.
Dependent on the NaCI concentration - see chapter 8.
2)
3) Category 2, Zone 1 or Category 3, Zone 2.
A-weighted sound pressure level at 1 m from the pump unit
4)
surfaces (reference box) acc. to EN ISO 20361 section 6.2. The noise
measurements are performed acc. to EN ISO 3744:2010 on a
motor-pump unit at max. pressure and speed.
5) Max. area covered with recommended motor con guration
(excl. of space to service pump)
APP 11/1200 APP 11/1500
180B3212 180B3211
180B3226 180B3225
180B3222 180B3221
166.4 137.4
10.15 8.38
83
1200 1015
10
145 145
2 - 5 2 - 5
29 - 72.5 29 - 72.5
10
145 145
700 700
1200 1500
9.22 7.50
11.25
48.71 39.61
2 - 50 2 - 50
35.6 - 122 35.6 - 122
0 - 50 0 - 50
32 - 122 32 - 122
78
172 172
85
0.48 0.48
5.17 5.17
30.0
40.0
229 166
169 123
APP 13/1200 APP 13/1500
180B3214 180B3213
180B3228 180B3227
180B3224 180B3223
197.5
12.05
70 83
1200
10 10
145
2 - 5
29 - 72.5
10 10
145
700
1200
11.07
58.51
2 - 50
35.6 - 122
0 - 50
32 - 122
78 78
172
85 85
0.54
5.81
50.0
274
202
