HEADSIGHT
HEADSIGHT
INSTALLATION & OPERATION MANUAL
CASE-IH
CASE-IH
MODELS
MODELS
14xx, 16xx, 21xx, 25xx
14xx, 16xx, 21xx, 25xx
09010202g
HEADSIGHT.COM | 574.546.5022
® ®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CASE-IH 14 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Headsight CASE-IH 14 Series

  • Page 1 HEADSIGHT HEADSIGHT ® ® INSTALLATION & OPERATION MANUAL CASE-IH CASE-IH MODELS MODELS 14xx, 16xx, 21xx, 25xx 14xx, 16xx, 21xx, 25xx 09010202g HEADSIGHT.COM | 574.546.5022...
  • Page 3 This icon designates an important instruction. Suggestions If you have any suggestions to improve this manual please call 574-546-5022 or email info@headsight.com. Disclaimers HEADSIGHT, HORIZON, PINPOINT, FORESIGHT, FEATHERSIGHT, TRUESENSE, TERRAHAWK, INSIGHT, the Headsight logo, the Horizon logo, and Terrahawk logo are trademarks of Headsight Harvesting Solutions.
  • Page 4: Table Of Contents

    Table of Contents Safety Information������������������������������������������������������������������������� Safety Stop ������������������������������������������������������������������������������������� Installation�������������������������������������������������������������������������������� Installation Overview ��������������������������������������������������������������������������� Insight Box Mounting and Main Harness Wiring ������������������������������������������������02 ® Lights���������������������������������������������������������������������������������� ConnectingSensors����������������������������������������������������������������������� Insight Power Wire �����������������������������������������������������������������������������03 Feathersight Pressure Sensor Option Installation �����������������������������������������������04 ® Setup & Calibration � ������������������������������������������������������������������������ Setup Insight ������������������������������������������������������������������������������05 ®...
  • Page 5 Troubleshooting—Sensors and Harnesses ��������������������������������������������������������� Troubleshooting by Symptom ������������������������������������������������������������������� InsightStatusLightDiagnostics(Statusnotgreen)������������������������������������������� GeneralInsightProblem������������������������������������������������������������������� AHHCDiagnostics ����������������������������������������������������������������������� LateralTiltDiagnostics � ������������������������������������������������������������������� Schematics �������������������������������������������������������������������������������� Insight Harness - Typical ������������������������������������������������������������������������ Parts�������������������������������������������������������������������������������������� Insight & Harnesses �����������������������������������������������������������������������������26 Statement of Limited Warranty �������������������������������������������������������������...
  • Page 6: Safety Information

    Safety Information Safety Stop Before working on combine or under header always: 1. Perform all combine and header manufacturer safety precautions for servicing header. 2. Insert stop to prevent movement of header. 3. Set combine parking brake. 4. Turn off combine and remove key from ignition. 5.
  • Page 7: Installation

    Installation Complete the installation portion of the header manual before continuing. Installation Overview To install a Headsight system, follow the steps below in order. 1. Install the Header components. • See the header model specific Installation Manual 2. Install the Combine components.
  • Page 8: Insight ® Box Mounting And Main Harness Wiring

    • For AGCO heads - Connect Y to header Connecting Sensors 1. Connect sensor wiring to main Headsight harness. • Sensor location as viewed from operator’s seat Left Left Center Center Right Center Right 2 Sensor 3 Sensor...
  • Page 9: Insight Power Wire

    • Press the pin on the red wire of the Headsight power wire into pin D of the 5 pin plug until you hear a click • Insert the pin on the black wire into pin E of the 5 pin plug 4.
  • Page 10: Feathersight ® Pressure Sensor Option Installation

    Feathersight Pressure Sensor Option Installation ® Feathersight is an optional module to improve the performance of grain ® systems. It uses both height sensors and the feeder house pressure sensor to allow seamless control from off ground to on ground harvesting. 1.
  • Page 11: Setup & Calibration

    Setup & Calibration Setup Insight ® These steps must be performed the first time the Insight box is powered up and each time it is reset. They do not need to be redone each time the Insight box is calibrated. See 09010001 Insight Users Manual for information about how to use the Insight box.
  • Page 12: Calibrate Insight

    Calibrate Insight When you initialize Insight, you will be led directly to this calibration routine. If you wish to recalibrate at any time - select “>>Perform Calibration” on the Insight main menu. For the best header control always make sure the header f/a angle is set correctly.
  • Page 13: Combine Calibration (21-25Xx Only)

    Combine Calibration (21-25xx only) A full combine calibration must be completed if a component of the header control system is changed on the combine. See combine operators manual for details or Advanced Info>>Full Call section of this manual. 1. Start Combine (CYCLE KEY off/on if already running). 2.
  • Page 14: Settings

    Settings Insight Settings See the 09010001 Insight Users Manual/Setup for information on settings available in Insight. • 2 or 4 Sensor Tilt • Tilt Sensitivity • Tilt Balance • Foresight or Feathersight options Combine Settings Properly setting the combine is essential to having responsive header control. You should become very familiar with the steps in this section.
  • Page 15: Controls:Cih21-25Xx

    Controls: CIH 21-25xx 1. Header control mode selector switch. • M: Manual Mode – Operator controls header height - No Auto mode • RTC: Return to Cut Mode – Automatically returns to preset height based on feeder house position sensor •...
  • Page 16: Controls:Cih14-16Xx

    Controls: CIH 14-16xx 1. Height position knob. • Turning right increases (Turning left decreases) header height setting in automatic height control mode 2. Height sensitivity knob. • Turning right increases (Turning left decreases) header height sensitivity • Increase sensitivity to increase height control performance •...
  • Page 17: Operation

    1. Be sure you have the initial settings entered and have calibrated Insight. 2. Operate the Headsight system exactly like you would use your combine OEM height control system. 3. Fine tune all combine speed and sensitivity adjustments for best performance.
  • Page 18: Advanced Information

    Advanced Information Theory of Operation A review of the following points will help the service technician to understand the complete system, which will help diagnose specific problems. 1. Each sensor returns a variable voltage depending on header height. • High header height = high voltage (approximately 4 volts) •...
  • Page 19: Full Cal For 21-25Xx Series Combines

    Full Cal for 21-25xx Series Combines 1. Perform calibration over a ditch; feeder house MUST be fully lowered to stops during this procedure. 2. Start engine while holding both “Engine” and “Speed” buttons. • Screen will display “Hdr” 3. Release “Engine” and “Speed” buttons. •...
  • Page 20: Common Combine Errors

    Common Combine Errors Calibration Error - 2xxx Series Combines If the combines corner post displays “Hdr-S1”, header light illuminates or header does not pause while raising in calibration mode perform the following calibration steps. Header does not pause during calibration or Header pauses before the sensors leave the ground.
  • Page 21: ErrorCodeDisplaysJustAfterCalibrationPause

    Error code displays just after calibration pause Description: • Will not calibrate with bad feeder house potentiometer • Will function if already calibrated • Test by switching to RTC - Operate the machine and verify that you can dial the full range of the feeder house stroke with the height knob - this will verify feeder house position sensor Solution:...
  • Page 22: Diagnostics

    Diagnostics Before working on combine or under header always: 1. Perform all combine and header manufacturer safety precautions for servicing header. 2. Insert stop to prevent movement of header. 3. Set combine parking brake. 4. Turn off combine and remove key from ignition. 5.
  • Page 23: DetailedDiagnostics

    Typically 3 . 0 V- 3 . 8 V =3.02V • 3 . 0 V = Max. sensitivity (knob fully CW) • 3 . 8 V = Min. sensitivity (knob fully CCW) • If the value exceeds 4 . 0 V, call Headsight for instructions...
  • Page 24: Troubleshooting-Sensors And Harnesses

    All of the above are correct Harness & combine connections pass test. If you have a Headsight Sensor tester, Verify sensor is connected to extension If sensor cannot be adjusted to achieve use it to test the sensor. For all other:...
  • Page 25: Troubleshooting By Symptom

    Insight box isolate problem – screen will regain contrast when faulty sensor is disconnected. (Reversed polarity to hall-effect sensors may cause this symptom) Correct short in wiring Insight will need reset after correction of wiring short Insight box failure Contact Headsight...
  • Page 26: AhhcDiagnostics

    V on Y (red wire), ground on pin (black wire) Insight harness failure Test/repair Insight wiring Insight box failure Contact Headsight Symptom Problem Solution AHHC Diagnostics No automatic operation height or tilt Wiring is not connected properly Check wiring from sensor to combine...
  • Page 27 Symptom Problem Solution AHHC Diagnostics Header is too jumpy Combine is improperly set See - Setting section of this manual Reduce Auto Drop Rate Decrease sensitivity Insight or combine needs to be re- See Calibration section of this manual calibrated Discharged accumulator Test accumulator as described in combine owner’s manual, replace or...
  • Page 28 Out of Range Combine limits travel to % of calibrated range Special software needed Contact Headsight regarding optional products Foresight and/or Feathersight Header dives to ground and recovers Lower Rate set too High See Combine Specific Settings entering crop...
  • Page 29: LateralTiltDiagnostics

    Symptom Problem Solution Lateral Tilt Diagnostics Height works but not Tilt Increase Tilt Sensitivity. Adjust tilt sensitivity & gain settings also Tilt does not follow the ground when Adjust Field Tracker switch, see Cannot rock head back and forth with head is lowered Common Combine Errors>>Field Tracker balance knob when lowered...
  • Page 30: Schematics

    Schematics The Insight Harness schematic is the main harnesses used for all applications in this manual. A number of variations are available. The following schematics are provided for troubleshooting and installation purposes only. Unauthorized uses, such as using them to replicate harnesses for resale, are strictly prohibited under copyright law.
  • Page 31: Insight Harness - Typical

    Insight Harness - Typical...
  • Page 32: Insight & Harnesses

    Parts Insight & Harnesses ITEM QTY. PART NUMBER DESCRIPTION INSIGHT Insight Control Box QB3-IH23-xx Insight Harness QB5-IH23-xx Insight Harness QJ5-IH23-xx Insight Harness PFI-CIH-P Power Wire *All parts vary for each application, please call for more information...
  • Page 33: Statement Of Limited Warranty

    Headsight is for the sole purpose of identifying such goods and shall not create an express warranty that the goods shall conform to such description.
  • Page 34 574.546.5022 • 574.546.5760 4845 3B Rd • Bremen, IN 46506 info@headsight.com www.headsight.com...
