  • Page 1 COMBINE AHC COMBINE AHC INSTALLATION & OPERATION MANUAL JD 9X00, 9X10 JD 9X00, 9X10 w/o D.A.M. D.A.M. 09010103e HEADSIGHT.COM | 574.546.5022...
  • Page 3 This icon designates an important instruction. Suggestions If you have any suggestions to improve this manual please call 574-546-5022 or email info@headsight.com. Disclaimers HEADSIGHT, HORIZON, PINPOINT, FORESIGHT, FEATHERSIGHT, TRUESENSE, TERRAHAWK, INSIGHT, the Headsight logo, the Horizon logo, and Terrahawk logo are trademarks of Headsight Harvesting Solutions.
  • Page 4: Table Of Contents

    Table of Contents Installation�������������������������������������������������������������������������������� Required Equipment ���������������������������������������������������������������������������� Control Unit �����������������������������������������������������������������������������������02 Main Harness ����������������������������������������������������������������������������������02 Header Harness ���������������������������������������������������������������������������������05 ForConversions�������������������������������������������������������������������������� ForHeadsightSensors��������������������������������������������������������������������� Calibration�������������������������������������������������������������������������������� Sensor Calibration ������������������������������������������������������������������������������06 Settings ����������������������������������������������������������������������������������� Harvester Settings ������������������������������������������������������������������������������08 Control Unit Layout ���������������������������������������������������������������������������� Operation ��������������������������������������������������������������������������������� Enabling Height Control ������������������������������������������������������������������������ Adjusting Header Height �����������������������������������������������������������������������...
  • Page 5: Installation

    Installation Before working on combine or under header always: 1. Perform all combine and header manufacturer safety precautions for servicing header. 2. Insert stop to prevent movement of header. 3. Set combine parking brake. 4. Turn off combine and remove key from ignition. 5.
  • Page 6: Control Unit

    Control Unit 1. Connect the two mounting brackets together with two ¼” x ½” bolts and nuts. 2. Remove the two 5/16” head screws from under the outer lower edge of the armrest console. 3. Attach the enclosed armrest bracket to the armrest with the bolts removed in step 2.
  • Page 7 3. From the right side of the combine, pull the Y811 connection across under the cab and through the loop that holds up the JD main harness until the Y in the Headsight® harness is just about to start under the left side of the cab as shown.
  • Page 8 Module • Disconnect the OEM plug from the Logic Module, and connect it to Y 822 on the Headsight® main harness • Plug Y 821 into the Logic Module 14. If the combine has lateral tilt, disconnect the original 4 pin Weather Pack plugs and connect Y823 &...
  • Page 9: Header Harness

    The 31 pin header connector mates to OEM headers set up for JD 9x50 combines. A “single point” version is also available. Mate the header plug to either existing JD header connector, or to the Headsight® Header harness supplied with the Header Kit. For installation instructions, see the Header Installation Guide.
  • Page 10: Calibration

    Set the MODE switch to HGT 3. For Headsight sensors, adjust them to 4.0V against the stops. Make sure the stops are adjusted correctly, so sensors all hang at the same angle first.. Or follow the steps below for “all sensors”.
  • Page 11 • If the Auto [Cal] light does not just turn on at the lowest point: • Loosen the nuts or screws which hold the HIGHER sensor (the hall effect sensor or potentiometer, not the entire sensor assembly) • Twist the sensor to a new position; stop when the Auto [Cal] light turns on •...
  • Page 12: Settings

    Settings Harvester Settings Properly setting the machine is essential to having responsive header control. You should become very familiar with the steps in this section. Always perform the combine ground calibration before adjusting settings. Set each sensitivity setting by increasing till header bouncing occurs then decreasing till header becomes stable. •...
  • Page 13 Hydraulic Accumulator 1. Close the accumulator valve all the way. 2. Open the accumulator valve 1 full turn from the closed position. • Opening the accumulator to far will give a sloppy response • Not opening the accumulator far enough will give a jerky response...
  • Page 14: Control Unit Layout

    Control Unit Layout 1. Head Height knob: • Adjusts Head Height; MODE must be set to HGT or HGT & TILT 2. Height Sensitivity knob: • Adjusts Height Sensitivity, MODE must be set to HGT or HGT & TILT 3. Tilt Sensitivity knob: •...
  • Page 15: Operation

    The OEM switches should be left OFF. Turn OFF the MODE switch any time you do not want the header to auto lower or raise. 1. Turn MODE switch on Headsight control unit to HGT or HGT & TILT. 2. Engage Header clutch.
  • Page 16: Adjusting Header Height

    2. Find and mark the minimum acceptable height as noted below; do not operate below this point. Because the Headsight™ control unit is designed to work with many OEM sensors, it may be possible for the operator to choose a height that is too low for operation –...
  • Page 17: Advanced Information

    Low header height = low voltage (approximately 1 volt) • Sensor may not exceed 4 .. 5 V, or be less than 0 . 5 V 2. When using Headsight sensors, each sensor has 3 wires. Others similar. • black or Lt Blue = ground •...
  • Page 18 Height Operation Head Height • The control unit compares the sensor closest to the ground to the desired height chosen with the height knob • If any sensor has a lower voltage (is nearer the ground) than the height setpoint voltage, the box energizes the raise output •...
  • Page 19: Changing Tilt Orifices

    Changing Tilt Orifices The purpose of changing the orifices is to decrease/increase the maximum speed that the Contour-Master can tilt. The factory configuration will be satisfactory for most conditions. However, wide headers may need to adjust the orifices. Only change orifices if the system cannot be set properly by using the sensitivity adjustment on the contour-master card.
  • Page 20: Wiring

    Wiring Main Harness Y 886 Y 823 Y 824 Y 821 Y 811 Y 221 Y 822 Y 825 Y 826 Y 204 Connector Description Connects to Y204 31 pin Deutsch Header Y221 16 pin Amp Combine Y811 16 pin Amp Controller Y821 16 pin Amp...
  • Page 21: Diagnostics

    Diagnostics Before working on combine or under header always: 1. Perform all combine and header manufacturer safety precautions for servicing header. 2. Insert stop to prevent movement of header. 3. Set combine parking brake. 4. Turn off combine and remove key from ignition. 5.
  • Page 22: Troubleshooting-Sensors & Harnesses

    All of the above are correct Harness & combine connections pass test. If you have a Headsight Sensor tester, Verify sensor is connected to extension If sensor cannot be adjusted to achieve use it to test the sensor. For all other:...
  • Page 23: Troubleshooting By Symptom

    LED on control unit If not, reverse Orange and Blue wires in indicates) & Y Headsight system defective Repair or replace Control Unit Header rocks back and forth, or is too Tilt Sensitivity improperly adjusted Adjust Tilt sensitivity...
  • Page 24 Solenoid connections not properly See Installation and check to ensure wired wiring has been run properly Headsight system defective Replace or repair Headsight system See raise/lower diagnostics to test No automatic operation - height Feeder switch not on Turn on Harvest switch.
  • Page 25 V: Repair wire on combine properly V: check/replace Headsight wiring or controller Headsight control unit defective Repair or replace Headsight control unit Head will not Lower Wiring not connected See Installation, Settings sections of manual Head raises all the way to top...
  • Page 26 Manual raise switch does not disengage Test wiring from OEM Manual raise Repair as needed auto height wire to control unit (Yellow wire in Headsight harness) Should be V when raise switch is pressed Control unit defective Repair or replace control unit...
  • Page 27 OEM wiring defective Test Manual Raise operation auto height Press header raise (Raise LED does not come on) Defective Headsight harness Test wiring to controller for continuity Defective control unit Replace Controller Manual Lower switch does not engage OEM wiring defective...
  • Page 28: Schematics

    Schematics The Insight Harness schematic is the main harnesses used for all applications in this manual, each uses one of the following valve harnesses depending on your steering device. The following schematics are provided for troubleshooting and installation purposes only. Unauthorized uses, such as using them to replicate harnesses for resale, are strictly prohibited under copyright law.
  • Page 29: Main Harness

    Main Harness...
  • Page 30: Parts

    Parts Controller and Harnesses ITEM QTY. PART NUMBER DESCRIPTION HT9114 Control Unit HT9112 Top Mounting Bracket for (1) HT9110 Lower Mounting Bracket for (1) HT9121 Main Harness...
  • Page 31: Statement Of Limited Warranty

    Headsight is for the sole purpose of identifying such goods and shall not create an express warranty that the goods shall conform to such description.
  • Page 32 574.546.5022 • 574.546.5760 4845 3B Rd • Bremen, IN 46506 info@headsight.com www.headsight.com...
