- Page 1 GRAIN GRAIN INSTALLATION MANUAL HONEYBEE SP HONEYBEE SP NEW HOLLAND NEW HOLLAND 92C, 94C 92C, 94C 09032303c HEADSIGHT.COM | 574.546.5022...
- Page 3 This icon designates an important instruction. Suggestions If you have any suggestions to improve this manual please call 574-546-5022 or email info@headsight.com. Disclaimers HEADSIGHT, HORIZON, PINPOINT, FORESIGHT, FEATHERSIGHT, TRUESENSE, TERRAHAWK, INSIGHT, the Headsight logo, the Horizon logo, and Terrahawk logo are trademarks of Headsight, Inc.
-
Page 4: Table Of Contents
Table of Contents Installation�������������������������������������������������������������������������������� Terrace Sensors (if equipped)02 Standard Undermount Sensors04 Routing Wiring 06 ExtensionHarnessLengthTable������������������������������������������������������������ RemovingWiresforTightAccess����������������������������������������������������������� RoutingWiring-TerraceSensor������������������������������������������������������������� RoutingWiring-StandardSensors����������������������������������������������������������� Install Sensor Wands and Tether Cables 09 Install Insight or Horizon Mounting Bracket 09 Sensor Adjustment ������������������������������������������������������������������������� Standard Sensor IncreasingorDecreasingVoltage � ����������������������������������������������������������� AdjustingDownPressure ������������������������������������������������������������������... -
Page 5: Installation
Installation Before working on combine or under header always: 1. Perform all combine and header manufacturer safety precautions for servicing header. 2. Insert stop to prevent movement of header. 3. Turn off combine and remove key from ignition. 4. Set combine parking brake. 5. -
Page 6: Terrace Sensors
Terrace Sensors (if equipped) 1. Line up holes of sensor and mounting bracket with spring installed short leg up and long leg back in mounting bracket. SHORT • Use HT 7138 bracket LONG 2. Insert pin and secure with retaining ring clip. 3. - Page 7 6. Remove standard crop divider tip. 7. Using provided hardware, bolt the HT641 large round bar bracket in place of the crop divider • Install bar with the front end bent downward 8. Bolt the terrace sensor/bracket assembly to the end of the rod. 9.
-
Page 8: Standard Undermount
Standard Undermount Sensors 1. Determine sensor mounting location. 2. Mount outer sensors first, mounting out as far as possible (if not equipped with terrace option). • Mount all inner sensors as evenly spaced as possible across the head • To avoid clearance issues you may need to pre- assemble sensor and mounting brackets 3. - Page 9 5. Mount inner sensor/bracket assemblies to brackets as shown. • Make sure the draper belt will not hit the sensor bracket • For headers 40 ft or wider it may be necessary to drill holes and mount the brackets directly to the skid plate behind the cutter bar to keep the sensors spaced evenly...
-
Page 10: Routing Wiring
Routing Wiring 1. Select appropriate wiring from chart below and mark blue connector with sensor position. Properly routing the wiring is the most critical part of the installation process. Please take time to ensure that you have allowed sufficient slack for motion as well as sufficient clearance from moving header parts or crop flow. -
Page 11: RoutingWiring-TerraceSensor
Routing Wiring-Terrace Sensor 1. Attach PFB10 (10’) extension wire to terrace sensor. 2. Zip tie the blue connector to the top of the square bracket. • Place the zip tie just behind the square bracket so it is protected from crop •... -
Page 12: RoutingWiring-StandardSensors
Routing Wiring-Standard Sensors 1. Install protective conduit on wiring coming from sensor. 2. To aid installing conduit on sensor wiring without damaging wire insulation, tape a wrench big enough to open conduit wider then wiring harness. 3. Insert box end of wrench into conduit using as a guide to slide conduit over wiring. -
Page 13: Install Sensor Wands And Tether Cables 09
Install Sensor Wands and Tether Cables 1. Use hardware provided and fasten wand to sensor. • Install long wands on all terrace sensors using M 8 x 25 flange bolts. • If terrace sensors are not used install long wands on outer standard sensors with M 8 x 30 hex bolts •... -
Page 14: Sensor Adjustment
Sensor Adjustment Standard Sensor Insert header stop to prevent movement. Increasing or Decreasing Voltage 1. Remove sensor cover. 2. Loosen sensor mounting screws A. 3. Twist sensor to new position. • Twisting sensor clockwise (viewed from the end of the sensor) will increase voltage. •... -
Page 15: Terrace Sensor
Terrace Sensor Insert header stop to prevent movement. Increasing or Decreasing Voltage 1. Loosen the screws indicated A. 2. Turn sensor to new location. 3. Tighten screws A. Adjusting Voltage Swing 1. Loosen jam nut B. 2. Turn bolt to adjust. •... -
Page 16: Parts
Parts Mounting Brackets and Harness ITEM QTY. PART NUMBER DESCRIPTION HT641 Bar, Terrace B641 Mounting Hardware Bracket, Terrace HT7138 B7103 Mounting Hardware HT865 Bracket, Standard B865 Mounting Hardware B3110 Mounting Bracket Kit PFBxx (xx=length) Extension Harness (10,17,23,33,38) HT892 Conduit B892 Hardware Kit... -
Page 17: Terrace Sensor
Terrace Sensor... -
Page 18: Standard (Undermount) Sensor 14
Standard (Undermount) Sensor DATE... -
Page 19: Statement Of Limited Warranty
• Headsight, Inc. reserves the right to either inspect the product at the original retail purchaser’s location or require it to be returned to Headsight, Inc. for inspection. - Page 20 574.546.5022 • 574.546.5760 4845 3B Rd • Bremen, IN 46506 info@headsight.com www.headsight.com...
