INSTALLATION MANUAL
OXBO
OXBO
09020601d
HEADSIGHT.COM | 574.546.5022

Advertisement

Table of Contents
loading

Summary of Contents for Headsight CORN OXBO

  • Page 1 CORN CORN INSTALLATION MANUAL OXBO OXBO 09020601d HEADSIGHT.COM | 574.546.5022...
  • Page 3 This icon designates an important instruction. Suggestions If you have any suggestions to improve this manual please call 574-546-5022 or email info@headsight.com. Disclaimers HEADSIGHT, HORIZON, PINPOINT, FORESIGHT, FEATHERSIGHT, TRUESENSE, TERRAHAWK, INSIGHT, the Headsight logo, the Horizon logo, and Terrahawk logo are trademarks of Headsight, Inc.
  • Page 4: Table Of Contents

    Table of Contents Installation�������������������������������������������������������������������������������� Mounting Sensors �������������������������������������������������������������������������������02 AllRows �������������������������������������������������������������������������������� Sensor Wiring ����������������������������������������������������������������������������������03 HarnessLengthTable��������������������������������������������������������������������� RemovingWiresforTightAccess����������������������������������������������������������� RoutingWiring�������������������������������������������������������������������������� Install Horizon or Insight Controller�������������������������������������������������������������06 Install Light Wiring (Optional) ������������������������������������������������������������������06 Sensor Adjustment ������������������������������������������������������������������������� Changing Swing ���������������������������������������������������������������������������������07 Increasing or Decreasing Voltage ����������������������������������������������������������������07 Sensor Extensions �������������������������������������������������������������������������������08 Parts�������������������������������������������������������������������������������������� Mounting Bracket and Harness ������������������������������������������������������������������09 Sensor Parts ������������������������������������������������������������������������������������...
  • Page 5: Installation

    Installation Before working on combine or under header always: 1. Perform all combine and header manufacturer safety precautions for servicing header. 2. Insert stop to prevent movement of header. 3. Turn off combine and remove key from ignition. 4. Set combine parking brake. 5.
  • Page 6: Mounting Sensors

    Mounting Sensors All Rows 1. Choose the rows to which you will mount the sensors and remove them from the header. 2. Mark the bottom of the snout as shown – leave metal skid in place. • 3 ” wide x 9 ” long •...
  • Page 7: Sensor Wiring

    Sensor Wiring Properly routing the wiring is the most critical part of the installation process. Please take time to ensure that you have allowed sufficient slack for motion as well as sufficient clearance from moving header parts or crop flow. Harness Length Table 1.
  • Page 8: RoutingWiring

    Routing Wiring 1. Drill holes to route wiring in locations indicated for each snout which will receive a sensor. • These snouts were removed to install sensors 2. Lay out wiring to appropriate snout. • Wiring will run from the sensor to the rear of the header near the harvester’s feederhouse connection •...
  • Page 9 6. Fasten with cable clamps near snout hinge points. • Lift snout to see full range of motion • Leave enough slack to prevent tension on the wiring in both the raised and lowered positions 7. Route wiring to rear of header. •...
  • Page 10: Install Horizon Or Insight Controller

    4. Connect Headsight Brown (Stubble) to stubble light lamp wire (if equipped). See the Headsight combine manual for more details about how to install the remaining wiring harness or control box and then connect each individual sensor.
  • Page 11: Sensor Adjustment

    Sensor Adjustment Insert header stop to prevent movement. Changing Swing 1. Loosen the bolt A holding downstop. 2. Slide the downstop to new position in slotted hole. • Raising downstop will increase voltage swing and allow higher maximum cutting height •...
  • Page 12: Sensor Extensions

    Sensor Extensions Headsight recommends using the lowest setting that allows you to run as high as you desire. Increasing the length of the extension will reduce header control sensitivity. 1. Remove flange lock nut then remove arm and spring. 2. Install extension to sensor assembly with previously removed spring and flange locknut.
  • Page 13: Parts

    THIRD ANGLE SHEET PROJECTION HEADSIGHT INC. THE INFORMATION CONTAINED ON THIS DRAWING IS PROPRIETARY TO TOLERANCE HEADSIGHT, INC. ANY UNAUTHORIZED USE OF SUCH CONTENTS IS STRICTLY PROHIBITED. = ± .030 BRACKET CORN SENSOR OXBO x.xx = ± .010 x.xxx = ± .005...
  • Page 14: Sensor Parts

    Sensor Parts...
  • Page 15: Statement Of Limited Warranty

    • Headsight, Inc. reserves the right to either inspect the product at the original retail purchaser’s location or require it to be returned to Headsight, Inc. for inspection.
  • Page 16 574.546.5022 • 574.546.5760 4845 3B Rd • Bremen, IN 46506 info@headsight.com www.headsight.com...
