ACCESSORIES
Accessory attachments (Continued)
CAUTION: DO NOT detach the connector cover
when an optional equipment is not in use. Otherwise
the terminals of the multi-connector may be shorted
by a metal object, or become rusty by water
intrusion. This could damage the transceiver.

D Connector cover (Portable)

To detach:
1. Remove the screw. (z)
2. Detach the connector cover, and then connect an
optional equipment. (x)
To attach:
1. Attach the connector cover over the multi-
connector. (q)
2. Tighten the screw. (w)
z
1-5
x
Multi-
connector
w
q
Connector
cover
