Kwikset SmartCode 916 Installation And User Manual page 3

6
Add the lock to your smart home system
A
Initiate the process to add
the lock to your system at
your smart home controller.
Refer to your smart home
system instructions for
more information.
7
Add user codes (30 max)
It is recommended that you
A
add and delete all user codes Make sure the door is
through your smart home
open. Press the Program
control system. If your system
button once.
does not allow this, codes may
be added directly to the lock as
shown here.
Programming Timeout
During programming, if the
screen is not pressed for 20
seconds, the system will time
out (indicated by three beeps
and the "X" pattern flashing
three times), and you will need to
restart the procedure.
E
What digits and sounds did the lock produce?
Mastercode
For enhanced security,
a mastercode may
be used when adding
and deleting user
codes. For more
information about the
mastercode, download
the Programming and
Troubleshooting Guide
on the SmartCode 916
Touchscreen page at
www.kwikset.com.
*Beeping sound will only be heard if switch #3 (on the lock interior) is in the on positon. See "Switches and Status LED Colors" on page 4.
8 Test the lock (review normal operation)
Confirm that the code(s) added in previous step can unlock the door.
Activating the Screen
Option 1 Option 2
Touch screen with Touch lower left
palm or back of area of screen
hand until digits (where checkmark
illuminate. is located) until
digits illuminate.
9
Re-key the lock (if needed) and install the battery cover
A
Re-key the lock (if needed).
a
K
IMPORTANT:
Remove battery
pack before
re-keying.
B
When prompted by your smart home system to add the
lock, press button "A" on the lock interior one time. The
red LED will illuminate when the lock enters Add Mode.
button "A"
Please allow time for the controller to add the lock.
B
Press checkmark
symbol once.
Checkmark symbol with one beep
Programming was successful.
Locking the Door
1. Activate the screen.
Option 3
2. Press Lock symbol.
Touch screen
Note: If no user codes are
with three or
programmed, the door cannot
more fingers until
be locked via touchscreen.
digits illuminate.
b
Re-key the lock
to work with your
existing key. See
the supplied
SmartKey Re-key
H
instructions for
more information.
C
D
C
Enter user code. A total
of 30 user codes may
be programmed.
Each user code must be a
unique code between 4 and
8 digits, depending on your
smart home system.
or
1x
Make sure the user code is not a duplicate and that it is between
Make sure the lock has room for an additional code. If all user code
Unlocking the Door
1. Activate the screen.
2. If SecureScreen™ is enabled, touch
the random digits that appear.
3. Enter user code.
If you press the wrong digit while entering
a user code, you can press the Lock symbol
once to clear the digits entered previously and
immediately restart the code entry process.
B
c
K
Reinstall
battery
pack.
3 / 4
If successful, re-name the lock in your system
(if applicable).
If unsuccessful, follow your system's instructions to
remove the lock from the controller and any other
network, then press button "A" on the lock one time.
Perform steps 6A-6C again.
If still unsuccessful, consult the Programming and
Troubleshooting Guide on the SmartCode 916 page
at www.kwikset.com.
D
Press lock symbol once.
"X" pattern with three beeps
3x
Programming was unsuccessful.
4 and 8 digits during your next attempt.
positions are filled, delete a code to make room for this one.
SecureScreen™
SecureScreen is an added-security feature
that displays random digits before you enter
a user code to unlock the door. This feature
ensures that there are fingerprints on all
digits so that codes cannot be identified by
examining the touchscreen for finger prints.
Install the battery cover.
a
b
M
If desired, this feature
can be disabled by
turning switch #4 to
the off position. See
"Switches" on page 4.
actual
size
V
V (3x)
