Kwikset SMARTCODE 916 Installation And User Manual

69786-001
Rev 01
ZigBee
Installation and User Guide
Required tools
Ruler Phillips head screwdriver
Additional Tools (depending on application)
Hammer Wood block
1
Begin with your smart home app
If you will be using a smart home app with your lock, download the app and set
up your controller or hub before proceeding further with lock installation.
2
Prepare the door and check dimensions
Make sure your door is compatible. If you have a standard deadbolt mounted
A
separately from the handle below it, your door is compatible.
Compatible
Measure to confirm that the hole in the door
C
is either 2-1/8" (54 mm) or 1-1/2" (38 mm).
Note: Additional door
preparation may be
2-1/8"
required for doors with
54 mm
1-1/2" (38 mm) holes.
Consult the deadbolt
or
drilling instructions at
1-1/2" kwikset.com/doorprep
38 mm
3
Install the latch and strike
A
Is the door edge chiseled?
YES
or
chiseled
Use latch "A". If the
latch bolt is not already
extended, extend the
latch bolt as shown.
A
Kwikset
Technical Support
1-866-863-6584
www.kwikset.com
Not Compatible Not Compatible
Rim Mortise
Lock Lock
Measure to confirm that the backset is
D
either 2-3/8" or 2-3/4" (60 or 70 mm).
b a
2-3/8" or 2-3/4"
60 or 70 mm
actual
size
N
Hold the latch in front of the door hole, with the latch
B
face flush against the door edge.
NO
not
chiseled
Use latch "B" (not
included). If the latch
bolt is not already
extended, extend the
latch bolt as shown.
B
C
Is the D-shaped hole centered in the door hole?
D-shaped hole
No adjustment is required.
Proceed to next step.
Parts in the box
Latch
A
B
"B" is not included. If needed,
please contact Kwikset to order
a drive-in latch for your lock.
Strike Keys
E
C
Adapter Mounting
Ring Plate
D G
Not Compatible
Integrated
Interior
Measure to confirm that the hole
E
in the door edge is 1" (25 mm).
c k
s e
t
P
A
B
YES NO
or
D-shaped hole
Rotate latch face as
shown to extend latch.
A
B
1 / 4
Exterior Touchscreen*
Interior Assembly*
Traditional Contemporary
M or M
Fasteners
L
03809
K
Batteries SmartKey
Tool
48654
H
W
If drilling a new door, use the supplied template and the complete
door drilling instructions available at kwikset.com/doorprep
Remove your existing
B
deadbolt from your door.
Measure to confirm the door is between
F
1-3/8" and 2" (35 mm and 51 mm) thick.
1"
25 mm
Q
D
Which latch are you installing?
Latch "A"
A
N or P
(x2)
Install strike on the door frame.
E
Make sure the hole in the door frame is drilled a
minimum of 1" (25 mm) deep.
Longer screws
install closest to
the door jamb.
S (x2)
* Installation is the same
regardless of model shown
Traditional Contemporary
or
F
F
46780
Q
N
S
P
49191 64109
T
U V
1-3/8" –2"
35 – 51 mm
S
Latch "B"
or
B
wood
block
C
Q (x2)
door frame
