Specifications:

Power supply
Power consumption
Fuse rating
LED power
Modes
DMX channels
PAN range
Tilt range
Beam angle
Connections
Dimensions
Weight
Troubleshooting:
No power (mains)
No light output
Unresponsive to DMX
Overheating/Cutting out
www.avsl.com
60-89
90-119
120-149
150-179
180-209
210-239
240-255
Auto speed 0-255
0-249
Reset
250-255
110-240Vac, 50/60Hz (IEC)
100W
F3A
100W COB LED
Auto, sound, master/slave, DMX512
9 or 13CH
540°
200°
2°
Power in (IEC), DMX in/out (3pin XLR)
200 x 200 x 300mm
3.6kg
Check mains voltage is correct and outlet is switched on
Check IEC lead and fuse (if fuse continually blows, refer to
your dealer)
Check control panel mode settings
Check DMX settings from controller (dimmer levels, blackout
etc.)
Check that unit is in DMX mode and ensure the A on the DMX
address flashes to confirm it's receiving a DMX signal
Check DMX controller is not set to black out
Check DMX controller is on correct fixture/page
Check master dimmer value
Check correct DMX address is set
Check DMX connection and leads
Ensure adequate ventilation and unit is not too close to a heat
source
Auto 2
Auto 3
Auto 4
Sound 1
Sound 2
Sound 3
Sound 4
Speed from slow to fast
No effect
Reset after 3 seconds
