Control panel

1
1 Function knob
The oven's various functions are suitable for
different cooking modes. After selecting the
required function, set the cooking temperature
using the temperature knob.
2 Temperature knob
This knob allows you to select the cooking
temperature. Turn the knob clockwise to the
required value, between the minimum and
maximum setting.
3 Hob burner knobs
For lighting and adjusting the hob burners. Press
and turn the knobs anti-clockwise to
order to light the relative burners. Turn the knobs
to the zone between the maximum
minimum setting to adjust the flame. Return
the knobs to the position to turn off the
burners.
4 Programmer clock
For displaying the current time, setting
programmed cooking operations and the
minute minder timer.
5 Indicator light
The indicator light comes on to indicate that the
oven is heating up. It turns off as soon as it
reaches the set temperature. It flashes regularly
to indicate that the temperature set inside the
oven is kept constant.

Other parts

Shelves
The appliance features shelves to position trays
and racks at different heights. The insertion
heights are indicated from the bottom upwards
(see General description).
Cooling fan
The fan cools the oven and comes into
operation during cooking. The fan causes a
steady outflow of air that exits from the rear of
91477B263/A
2 5 3
in
and
4
the appliance and which may continue for a
brief period of time even after the appliance has
been turned off.
Do not obstruct ventilation openings
and heat dispersal slots.
Interior lighting
The appliance's interior lighting comes on:
• When the door is opened.
• When any function is selected, apart from
the function.
When the door is open, it is not possible
to turn off the interior lighting.

Accessories

• Not all accessories are available on some
models.
• The accessories intended to come into
contact with food are made of materials that
comply with the provisions of current
legislation.
• Original supplied and optional accessories
can be requested to Authorised Assistance
Centres. Use only original accessories
supplied by the manufacturer.
Trivet
Useful when using small cookware.
3
DESCRIPTION - 11
