DESCRIPTION

General description

1 Hob

2 Control panel

3 Oven light
Control panel
1 Temperature knob
This knob allows you to select the cooking
temperature. Turn the knob clockwise to the
required value, between the minimum and
maximum setting.
2 Indicator light
The indicator light comes on to indicate that the
oven is heating up. It turns off as soon as it
reaches the set temperature. It flashes regularly
to indicate that the temperature set inside the
oven is kept constant.
3 Function knob
The oven's various functions are suitable for
different cooking modes. After selecting the
required function, set the cooking temperature
using the temperature knob.
38 - DESCRIPTION
4 Seal
5 Door
6 Fan
7 Pizza stone (on some models only)
Frame shelf
Hob
AUX = Auxiliary Burner
SR = Semi-rapid Burner
UR-3c = Ultra-Rapid Burner
4 Minute minder knob
This knob allows you to select manual cooking
or the minute minder with automatic oven shut-
off at the end of cooking. To set the cooking
time, turn the knob clockwise until it reaches the
required position and then set the required
cooking function. The numbers indicate the
minutes. Adjustment is progressive, so the time
can also be set to any intermediate value
between the numbers indicated.
5 Hob burner knobs
For lighting and adjusting the hob burners. Press
and turn the knobs anti-clockwise to
order to light the relative burners. Turn the knobs
to the zone between the maximum
minimum setting to adjust the flame. Return
the knobs to the
in
and
position to turn off the
