- Page 1 6000 Series iBOX-6000 Series User Manual Version 1.0 Published June 2022 User Manual...
- Page 2 In no event shall ASRock Industrial, its directors, officers, employees, or agents be liable for any indirect, special, incidental, or consequential damages (including damages for loss of...
- Page 3 Replaceable batteries CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. *15G062470000AK* DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS P/N: 15G062470000AK V1.0 Button Battery Safety Notice Button Battery Safety Notice WARNING • INGESTION HAZARD: This product contains a button cell or coin battery.
- Page 4 HDMI Licensing LLC in the United States and other countries. Contact Information If you need to contact ASRock Industrial or want to know more about ASRock Industrial, you’re welcome to visit ASRock Industrial’s website at https://www.asrockind.com; or you may contact your dealer for further information.
-
Page 5: Table Of Contents
Contents Chapter 1 Introduction Package Contents Product Specifications Block Diagram Chapter 2 Product Overview Front View Rear View Inside View Chapter 3 Hardware Installation How to Remove the Bottom Case How to Install the WiFi Module How to Install the M.2 SSD How to Install the 2.5-inch Hard Drive How to Install the Memory Modules (DDR4) How to Install the VESA Bracket (Optional) - Page 6 Installation of ROM Socket Expansion Slots (M.2 Slots) Chapter 5 UEFI Setup Utility Introduction 5.1.1 UEFI Menu Bar 5.1.2 Navigation Keys Main Screen Advanced Screen 5.3.1 CPU Configuration 5.3.2 Chipset Configuration 5.3.3 Storage Configuration 5.3.4 Super IO Configuration 5.3.5 ACPI Configuration 5.3.6 USB Configuration 5.3.7 Trusted Computing Hardware Health Event Monitoring Screen...
-
Page 7: Chapter 1 Introduction
Because the hardware specifications might be updated, the content of this documentation will be subject to change without notice. 1.1 Package Contents • 1 x iBOX-6000 Series • 1 x 19V/65W Power Adapter • 1 x Wall Mount Kit & Screw Package •... -
Page 8: Product Specifications
1.2 Product Specifications Processor System Intel ElkHart Lake SoC Processors ® iBOX-J6412 (J6412, QC, Max Speed up to 2.6GHz, 10W) Chipset AMI SPI 256 Mbit BIOS Memory Technology Dual Channel DDR4 3200 MHz Capacity 32GB (16 GB per DIMM) Socket 2 x 260-pin SO-DIMM Graphics Controller... - Page 9 iBOX 6000 Series Internal Connector Infineon SLB9670VQ2.0 Watchdog Timer Output From Super I/O to drag RESETCON# Interval 256 Segments, 0, 1, 2, ...255sec Power Requirements Input PWR 1 x 19V/65W Power Adapter Power On AT/ATX Supported - AT : Directly PWR on as power input ready - ATX : Press button to PWR on after power input ready Environment Operating Temp...
-
Page 10: Block Diagram
1.3 Block Diagram NUC-J6412 Re-Timer HDMI DDR4 SO-DIMM 3200 DDI0 DDR4 - CH0 IT66318FN DDR4 SO-DIMM 3200 DDR4 - CH1 Intel DP++ DDI1 RJ45 PCIe#5(L7) RTL8111H Asmedia GLAN Type-C ASM1543 U3(L0) Asmedia RJ45 Type-C ASM1543 U3(L1) PCIe#3(L5) RTL8111H GLAN Elkhart Lake SoC Front U3/U2 M.2 KEY-E U3x1(L2)/U2x1... -
Page 11: Chapter 2 Product Overview
iBOX 6000 Series Chapter 2 Product Overview This chapter provides diagrams showing the location of important components of the iBOX 6000 Series. 2.1 Front View Description Power Button Audio(Mic-in, Line-out) USB 3.2 Gen2 (Type C) USB 3.2 Gen2 (Type C) USB 3.2 Gen2 (Type A) -
Page 12: Rear View
2.2 Rear View Description Kensington Lock DC-IN USB 3.2 Gen2 (Type A) HDMI RJ-45 (1G LAN) USB 2.0 (Type A) DisplayPort *There are two LEDs on the LAN port. Please refer to the table below for the LAN port LED indications. ACT/LINK LED SPEED LED LAN Port... -
Page 13: Inside View
iBOX 6000 Series 2.3 Inside View Description WiFi Module M.2 Slot SATA 3.0 Connector SO-DIMM Slot SO-DIMM memory, hard drive and mSATA SSD are not included with this system. -
Page 14: Chapter 3 Hardware Installation
Chapter 3 Hardware Installation This chapter helps you install or remove important components. 3.1 How to Remove the Bottom Case 1. Remove the four screws on the bottom case. 2. Then lift up and remove the bottom panel. -
Page 15: How To Install The Wifi Module
iBOX 6000 Series 3.2 How to Install the WiFi Module 1. Locate the WiFi Module slot on the motherboard. 2. Carefully insert the WiFi Module into the slot. 3. Tighten the screw to secure the WiFi Module to the motherboard. -
Page 16: How To Install The M.2 Ssd
3.3 How to Install the M.2 SSD 1. Locate the M.2 slot on the motherboard. 2. Carefully insert the M.2 SSD into the slot. 3. Tighten the screw to secure the M.2 SSD to the motherboard. -
Page 17: How To Install The 2.5-Inch Hard Drive
iBOX 6000 Series 3.4 How to Install the 2.5-inch Hard Drive 1. Remove the four screws on the bottom case. Then lift up and remove the bottom panel. 2. Attach the HDD cage to the bottom panel and secure it with screws. Then connect the SATA Data and Power Cable to the HDD. - Page 18 3. Connect the SATA Cable to the connector on the motherboard.. 4. Then reinstall the bottom panel.
-
Page 19: How To Install The Memory Modules (Ddr4)
iBOX 6000 Series 3.5 How to Install the Memory Modules (DDR4) 1. The iBOX 6000 Series requires DDR4 SO-DIMM. 2. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR4 SO-DIMM pairs. The SO-DIMM only fits in one correct orientation. -
Page 20: How To Install The Vesa Bracket (Optional)
3.6 How to Install the VESA Bracket (Optional) 1. Attach the two screws to the base of the iBOX 6000 Series. 2. Attach the VESA Bracket to the rear of a compatible display using the four screws. *Choose mounting holes depending on the mounting hole pattern of your LCD screen (75 mm ×... - Page 21 iBOX 6000 Series 3. Mount the iBOX 6000 Series by sliding it into place.
-
Page 22: How To Install The Wall Mounting Brackets
3.7 How to Install the Wall Mounting Brackets 1. Remove four rubber foots on the base of the iBOX 6000 Series. 2. Attach the wall mounting brackets to the base of the iBOX 6000 Series and secure them with screws. . - Page 23 iBOX 6000 Series Dimension of the iBOX 6000 Series with Wall Mounting Brackets Installed 165mm 151mm 80mm 106mm...
-
Page 24: How To Install The Din Rail Mounting Bracket (Optional)
3.8 How to Install the Din Rail Mounting Bracket (Optional) Attach the Din Rail Bracket to the base of the iBOX 6000 Series and secure it with screws. Din Rail Bracket is not provided by default. Please purchase it seperately if needed. -
Page 25: Positions Of The Ibox 6000 Series
iBOX 6000 Series 3.9 Positions of the iBOX 6000 Series The iBOX 6000 Series can be placed in vertical or horizontal position. Horizontal Position Vertical Position VESA-mounted 1. VESA bracket is not provided by default. Please purchase it seperately if needed. 2. -
Page 26: Chapter 4 Motherboard
Chapter 4 Motherboard 4.1 Motherboard Layout Top View: 1 : M.2 Key-M Socket (M2_M1) 2 : M.2 Key-E Socket (M2_E1) 3 : Clear CMOS Header (CLRMOS1) 4 : Front Panel Audio Header (HD_AUDIO1) 5 : USB 2.0 Connector (USB2_6_7) 6 : COM Port Header (RS232/422/485) 7 : SATA3 Port (SATA3_1) 8 : SIO_AT1 9 : System Panel Header (PANEL1) - Page 27 iBOX 6000 Series Bottom View: 10 : Power Button (PWR_BTN1) 11 : Fan Connector (FAN1) 12 : Battery Connector (BAT1) 13 : ESPI Connector (ESPI)
-
Page 28: Jumpers Setup
4.2 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on pins, the jumper is “Short”. If no jumper cap is placed on pins, the jumper is “Open”. The illustration shows a 3-pin jumper whose pin1 and pin2 are “Short”... -
Page 29: Onboard Headers And Connectors
iBOX 6000 Series 4.3 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage of the motherboard! SATA3 Port This Serial ATA3 (SATA3) connector supports SATA data (SATA3_1: see p.20, No. 7) cables for internal storage devices. The current SATA3 interface allows up to 6.0 Gb/s data transfer rate. - Page 30 System Panel Header This header accommodates several system front panel (9-pin PANEL1) HDLED+ PLED+ functions. HDLED- (see p.20, No. 9) PLED- PWRBTN# RESET# DUMMY Connect the power switch, reset switch and system status indicator on the chassis to this header according to the pin assignments below. Note the positive and negative pins before connecting the cables. PWRBTN (Power Switch): Connect to the power switch on the chassis front panel. You may configure the way to turn off your system using the power switch.
- Page 31 iBOX 6000 Series Back Side: Power Button (PWR_BTN1) (see p.21, No. 10) Fan Connector +12V (FAN1) (see p.21, No. 11) FAN_SPEED FAN_SPEED_CONTROL Battery Connector (BAT1) (see p.21, No. 12) ESPI Connector (ESPI1) (see p.21, No. 13)
-
Page 32: Installation Of Rom Socket
4.4 Installation of ROM Socket * Do not apply force to the actuator cover after ic inserted. * Do not apply force to actuator cover when it is opening over 120 degree, Otherwise, the actuator cover may be broken. * The yellow dot (Pin1) on the ROM must be installed at pin1 position of the socket. * Make sure the white dot on the ROM is installed outwards of the socket. -
Page 33: Expansion Slots (M.2 Slots)
iBOX 6000 Series 4.5 Expansion Slots (M.2 Slots) There are 2 M.2 slots on this motherboard. M.2 for SSD: 1 x M.2 (KEY M, 2242/2260/2280) with PCIe x1 and SATA3 for SSD. * M.2 Key M 2280(Supported by bracket) M.2 for Wi-Fi: 1 x M.2 (Key E, 2230) with PCIe x1 and USB 2.0 for Wireless. M.2 Key-M Socket (M2_M1) M.2 Key-E Socket (M2_E1) Signal Name... -
Page 34: Chapter 5 Uefi Setup Utility
Chapter 5 UEFI Setup Utility 5.1 Introduction This section explains how to use the UEFI SETUP UTILITY to configure your system. The UEFI chip on the motherboard stores the UEFI SETUP UTILITY. You may run the UEFI SETUP UTILITY when you start up the computer. Please press <F2> or <Del> during the Power-On-Self-Test (POST) to enter the UEFI SETUP UTILITY, otherwise, POST will continue with its test routines. -
Page 35: Navigation Keys
iBOX 6000 Series 5.1.2 Navigation Keys Please check the following table for the function description of each navigation key. Navigation Key(s) Function Description Moves cursor left or right to select Screens Moves cursor up or down to select items + / - To change option for the selected items <Enter> To bring up the selected screen <F1> To display the General Help Screen <F7> Discard changes <F9> To load optimal default values for all the settings <F10> To save changes and exit the UEFI SETUP UTILITY <F12>... -
Page 36: Advanced Screen
5.3 Advanced Screen In this section, you may set the configurations for the following items: CPU Configu- ration, Chipset Configuration, Storage Configuration, Super IO Configuration, ACPI Configuration, USB Configuration and Trusted Computing. Setting wrong values in this section may cause the system to malfunction. Instant Flash Instant Flash is a UEFI flash utility embedded in Flash ROM. This conve- nient UEFI update tool allows you to update system UEFI without entering ® operating systems first like MS-DOS or Windows . Just launch this tool and save the new UEFI file to your USB flash drive, floppy disk or hard drive, then you can update your UEFI only in a few clicks without prepar- ing an additional floppy diskette or other complicated flash utility. Please be noted that the USB flash drive or hard drive must use FAT32/16/12 file... -
Page 37: Cpu Configuration
iBOX 6000 Series 5.3.1 CPU Configuration Active Processor Cores Select the number of cores to enable in each processor package. CPU C States Support Enable CPU C States Support for power saving. It is recommended to keep C3, C6 and C7 all enabled for better power saving. Intel Virtualization Technology When this option is set to [Enabled], a VMM (Virtual Machine Architecture) can utilize the additional hardware capabilities provided by Vanderpool Technology. This option will be hidden if the installed CPU does not support Intel Virtualization Technology. - Page 38 CPU Thermal Throttling You may select [Enabled] to enable CPU internal thermal control mechanism to keep the CPU from overheating.
-
Page 39: Chipset Configuration
iBOX 6000 Series 5.3.2 Chipset Configuration VT-d ® ® Use this to enable or disable Intel VT-d technology (Intel Virtualization Technology for Directed I/O). The default value of this feature is [Enabled]. Share Memory Configure the size of memory that is allocated to the integrated graphics processor when the system boots up. Render Standby Power down the render unit when the GPU is idle for lower power con- sumption. -
Page 40: Storage Configuration
5.3.3 Storage Configuration SATA Controller(s) Use this item to enable or disable the SATA Controller feature. SATA Mode Selection Use this to select SATA mode. The default value is [AHCI Mode]. AHCI (Advanced Host Controller Interface) supports NCQ and other new features that will improve SATA disk perfor- mance but IDE mode does not have these advantages. -
Page 41: Super Io Configuration
iBOX 6000 Series 5.3.4 Super IO Configuration COM1 This allows you to enable or disable the COM1 feature. Type Select Use this to select COM1 port type: [RS232], [RS422] or [RS485]. WDT Timeout Reset Use this to set the Watch Dog Timer. -
Page 42: Acpi Configuration
5.3.5 ACPI Configuration Suspend to RAM Use this item to select whether to auto-detect or disable the Suspend-to- RAM feature. Select [Auto] will enable this feature if the OS supports it. Onboard LAN Power On Use this item to enable or disable onboard LAN to turn on the system from the power-soft-off mode. -
Page 43: Usb Configuration
iBOX 6000 Series 5.3.6 USB Configuration USB Power Control Use this item to control USB power. -
Page 44: Trusted Computing
5.3.7 Trusted Computing Security Device Support Enable or disable BIOS support for security device. -
Page 45: Hardware Health Event Monitoring Screen
iBOX 6000 Series 5.4 Hardware Health Event Monitoring Screen In this section, it allows you to monitor the status of the hardware on your system, including the parameters of the CPU temperature, motherboard temperature, CPU fan speed, chassis fan speed, and the critical voltage. FAN1 Setting This allows you to set FAN1’s speed. Configuration options: [Full On],[Automatic Mode] or [System Auto]. The default value is [System Auto]. -
Page 46: Security Screen
5.5 Security Screen In this section, you may set, change or clear the supervisor/user password for the system. Supervisor Password Set or change the password for the administrator account. Only the ad- ministrator has authority to change the settings in the UEFI Setup Utility. Leave it blank and press enter to remove the password. User Password Set or change the password for the user account. Users are unable to change the settings in the UEFI Setup Utility. Leave it blank and press en-... -
Page 47: Boot Screen
iBOX 6000 Series 5.6 Boot Screen In this section, it will display the available devices on your system for you to config- ure the boot settings and the boot priority. Boot From Onboard LAN Use this item to enable or disable the Boot From Onboard LAN feature. Setup Prompt Timeout This shows the number of seconds to wait for setup activation key. 65535(0XFFFF) means indefinite waiting. -
Page 48: Exit Screen
5.7 Exit Screen Save Changes and Exit When you select this option, it will pop-out the following message, “Save configuration changes and exit setup?” Select [OK] to save the changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When you select this option, it will pop-out the following message, “Discard changes and exit setup?” Select [OK] to exit the UEFI SETUP UTILITY without saving any changes. Discard Changes When you select this option, it will pop-out the following message, “Discard changes?” Select [OK] to discard all changes. Load UEFI Defaults Load UEFI default values for all the setup questions. -
Page 49: Chapter 6 Software Support
iBOX 6000 Series Chapter 6 Software Support 6.1 Install Operating System ® ® This motherboard supports various Microsoft Windows operating systems: 10 64-bit. Because motherboard settings and hardware options vary, use the setup procedures in this chapter for general reference only. Refer your OS documentation for more information.
