Thank you for purchasing the industrial HMI touch panel series of M2I corporation.
Please read this manual carefully to know installing, wiring, operating this equipment for safe use of this
product.
M
I Corporation
2
11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea,
Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr
Industrial HMI Touch Panel
TOPRC Series Hardware Manual
M
I Corporation
2
TOPRC Series
User Manual
1 / 18
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for M2I TOPRC Series
Summary of Contents for M2I TOPRC Series
- Page 1 Industrial HMI Touch Panel TOPRC Series User Manual Thank you for purchasing the industrial HMI touch panel series of M2I corporation. Please read this manual carefully to know installing, wiring, operating this equipment for safe use of this product. I Corporation...
-
Page 2: Table Of Contents
3.6 Antenna Information ............................... 7 3.7 Environment Specifications ............................7 3.8 Structure Specifications ..............................7 Chapter 4 Parts Identification and Functions ..........................7 4.1 TOPRC Series ..................................7 Chapter 5 Interface ....................................10 5.1 Serial Interface ................................. 10 5.2 Ethernet Interface ................................11 5.3 USB Interface .................................. -
Page 3: Chapter 1 Safety Precautions
TOPRC Series Hardware Manual Chapter 1 Safety Precautions ■ Before using the product To use the product safely and effectively, please read the contents of this manual thoroughly before use. Please keep to the safety precaution, for it is to prevent accidents and potential danger from occurring. Safety precaution is classified into ‘Warning’... - Page 4 TOPRC Series Hardware Manual ■ Wiring Precautions Be sure the wiring is done correctly by checking the product’s rated voltage and the terminal layout. Incorrect wiring could result in fire, damage or malfunctions. Tighten the terminal screw with the specified torque. If the screws of terminal are loose, it could result in short circuit, fire, malfunctions.
-
Page 5: Chapter 2 Overview
TOPRC Series Hardware Manual Chapter 2 Overview 2.1 Introduction of Products This industrial HMI touch panel is an industrial control device required in industrial field. It is a device based on RS-232C and RS-422/485, Ethernet which is used for the basic purpose of communication with another device(PLC). -
Page 6: Chapter 3 General Specifications
TOPRC Series Hardware Manual Chapter 3 General Specifications 3.1 Power Specifications Rated voltage DC 24V, Class2 Input Voltage Range DC 20~28V TOPRC1200WD Power Consumption TOPRC1500WD 40W or less TOPRC1900WD Voltage endurance DC 24V, within 10㎳ Insulation Resistance 500V DC, 10㏁... -
Page 7: Antenna Information
TOPRC Series Hardware Manual 20/40 MHz Spectrum Band 300Mbps@Max Transmit Speed 2.4G: +6.38dBm (Including Antenna gain), Maximum Power 5G: +15.02dBm (Including Antenna gain) Operation Area 20M or more (*flat-ground communication) Security (*AP Setting) WEP(64/128), WPA-PSK+(TKIP, AES), WPA2-PSK+(TKIP, AES) *AES Recommend 3.6 Antenna Information... - Page 8 TOPRC Series Hardware Manual 4.1.1 External Dimension Model A(mm) B(mm) C(mm) D(mm) TOPRC1200WD 321.4 252.4 67.5 TOPRC1500WD 406.4 286.4 67.5 TOPRC1900WD 477.4 328.4 67.5 4.1.2 Front Part Names and Specifications Title Description ① TFT 16M Color LCD ② Touch Panel Capacitive Touch ③...
- Page 9 TOPRC Series Hardware Manual 4.1.3 Rear Part Names and Specifications Title Form Description ① Rubber Gasket Shock absorbing and IP specifying silicon gasket ② LED Indicator 3개 Power, Operation, Communication status display ③ SD Card Cover Plastic Cover SD Card, Reset switch, Mode switch, CR2032 battery ④...
-
Page 10: Chapter 5 Interface
TOPRC Series Hardware Manual Chapter 5 Interface In order to communicate with an external device, it is necessary to connect the two devices by referring to the following 5.1 Serial Interface 5.1.1 RS-232C Item Description Protocol Full Duplex Synch. Asynchronous... -
Page 11: Ethernet Interface
TOPRC Series Hardware Manual 5.1.4 COM2 Connector pin number and Signal name Type Pin No. Signal Direction Description Input RS-422/485 Receive Data(+) RDA(RD+) Input RS-232C Receive Data RD(RxD) SD(TxD) Output RS-232C Send Data 9Pin Female RDB(RD-) Input RS-422/485 Receive Data(-) -
Page 12: Usb Interface
USB 2.0 Communication Method Interrupt/Bulk/Isochronous Transfer Speed Max 480Mb/s Supportive OS Windows 98SE/2000/XP/VISTA/7/10(32/64bit) M2I manufacturer's cable is recommended (3M), and 1.5M or less Cable Length when purchased separately Connector Type Mini USB B, Female Connecting Method Front, USB OTG connector Chapter 6 Installation 6.1 Installation Requirements... -
Page 13: Install Procedure
TOPRC Series Hardware Manual -10 ~ 50°C, 10~80% -10 ~ 50°C, 10~80% 6.2 Install Procedure Please follow as below explanation to install the product. 6.2.1 Panel Cut-out Make a panel cut which product is mounted and insert the product to the panel form the front side. -
Page 14: Front Usb
TOPRC Series Hardware Manual (2) Screw the unit into the panel cut with a screwdriver. If the clamping screw below is over-tightened, the touch sensor may stop working or malfunction. Tighten to 0.4N.m screwdriver torque. * Caution: IP performance cannot be secured if the clamp is not tightened with a tightening force of 0.4N.m. -
Page 15: Chapter 7 Wiring
TOPRC Series Hardware Manual Chapter 7 Wiring 7.1 Power Cable Wiring (1) The Power cable should have the following specification. Power Cable Specification 0.75~2.5mm (18~12AWG) F.G Cable Specification (14AWG) Conductor type Simple or Stranded wire (use copper conductor only) Bolt torque ≥... -
Page 16: Ground Wiring
TOPRC Series Hardware Manual 7.2 Ground wiring (1) The product has enough anti-noise measure, so except that there are many noises. Specially, the ground is not needed. When doing ground, please refer to the followings. (2) The ground should be the exclusive ground. -
Page 17: Periodic Check Points
Check the touch pad there is no damage, scratch or pollution by eye. 8.3 Problems with the Device a. If there is a problem during operation, stop using it and contact the A/S department of M2I Corporation, which is indicated on the product label. -
Page 18: Chapter 9 Products And Warning Label Location
2024.05 www.m2i.co.kr - Please read related contents in this manual when you use M2I product, and operate the product staying safe with appropriate handling. - This manual should be stored in secured and appointed place so that it can be read in any needs.
