Thank you for purchasing the industrial HMI touch panel series of M2I corporation.
Please read this manual carefully to know installing, wiring, operating this equipment for safe use of
this product.
M2I Corporation
M2I Bldg, 35-11, Jeonpa-ro 24beon-gil, Manan-gu, Anyang-si, Gyeonggi-do, 430-857, Korea. Tel :+82-70-465-3366,Fax:+82-31-465-3355 www.m2i.co.kr
M2I Corporation Industrial HMI Touch Panel HW Installation Manual
Industrial HMI Touch Panel
Chapter1. Safety Precautions
Chapter2. Overview
Chapter3. General Specifications
Chapter4. Part Names and General Specifications
Chapter5. Interface
Chapter6. Installation
Chapter7. Wiring
Chapter8. Maintenance
Chapter9. Warning Label
Chapter10. Products Label
M2I Corporation
TOPRW
HW Installation Manual
1 / 23
Advertisement
Table of Contents
Related Manuals for M2I TOPRW
Summary of Contents for M2I TOPRW
- Page 1 Industrial HMI Touch Panel TOPRW HW Installation Manual Thank you for purchasing the industrial HMI touch panel series of M2I corporation. Please read this manual carefully to know installing, wiring, operating this equipment for safe use of this product. Chapter1. Safety Precautions Chapter2.
-
Page 2: Table Of Contents
5.2. Ethernet Communication Specifications ..................16 5.2.1 Ethernet ..............................16 5.2.2 RJ-45 Pin Layout ............................. 16 5.3 USB Communication Specifications ....................17 M2I Corporation 2 / 23 M2I Bldg, 35-11, Jeonpa-ro 24beon-gil, Manan-gu, Anyang-si, Gyeonggi-do, 430-857, Korea. Tel :+82-70-465-3366,Fax:+82-31-465-3355 www.m2i.co.kr... - Page 3 8.3 Problems with the Device ........................21 8.4 System Recovery Settings Switch ....................... 22 Chapter 9. Products and Warning Label Location....................23 Chapter 10. Products Label ............................. 23 M2I Corporation 3 / 23 M2I Bldg, 35-11, Jeonpa-ro 24beon-gil, Manan-gu, Anyang-si, Gyeonggi-do, 430-857, Korea. Tel :+82-70-465-3366,Fax:+82-31-465-3355 www.m2i.co.kr...
-
Page 4: Chapter 1. Safety Precautions
The output signal or communication lines should be separated from the power line or high tension wire. They should be installed 100mm (3.94 Inch) or more from each other. M2I Corporation 4 / 23 M2I Bldg, 35-11, Jeonpa-ro 24beon-gil, Manan-gu, Anyang-si, Gyeonggi-do, 430-857, Korea. Tel :+82-70-465-3366,Fax:+82-31-465-3355 www.m2i.co.kr... -
Page 5: Wiring Precautions
All field-wiring connections to this unit shall be from Limited Voltage / Limited Current, below 24 Vdc isolated secondary source with an output fuse, or Class 2 M2I Corporation 5 / 23 M2I Bldg, 35-11, Jeonpa-ro 24beon-gil, Manan-gu, Anyang-si, Gyeonggi-do, 430-857, Korea. Tel :+82-70-465-3366,Fax:+82-31-465-3355 www.m2i.co.kr... -
Page 6: Chapter 2. Overview
Figure Quantity Process Module Manual Clamp Power Connector USB Memory USB Cable Accessories User Options (Sold separate) SD Card Front Protect Sheet M2I Corporation 6 / 23 M2I Bldg, 35-11, Jeonpa-ro 24beon-gil, Manan-gu, Anyang-si, Gyeonggi-do, 430-857, Korea. Tel :+82-70-465-3366,Fax:+82-31-465-3355 www.m2i.co.kr... -
Page 7: Explanation Of Model Name
V : VGA (640*480) D: DC 10 : 10.2” S : SVGA (800*600) X : XGA (1024*768) W: WQVGA (480*272) WVGA (800*480) M2I Corporation 7 / 23 M2I Bldg, 35-11, Jeonpa-ro 24beon-gil, Manan-gu, Anyang-si, Gyeonggi-do, 430-857, Korea. Tel :+82-70-465-3366,Fax:+82-31-465-3355 www.m2i.co.kr... -
Page 8: Chapter 3. General Specifications
Class 3(Under 100Ω ) Protection Classification Conform to IP65 3.4 Structure Specifications TOPRW05 TOPRW07 TOPRW10 Weight 0.72 Cooling System Natural Air Circulation Case Material PC(Flameless) M2I Corporation 8 / 23 M2I Bldg, 35-11, Jeonpa-ro 24beon-gil, Manan-gu, Anyang-si, Gyeonggi-do, 430-857, Korea. Tel :+82-70-465-3366,Fax:+82-31-465-3355 www.m2i.co.kr... -
Page 9: Chapter 4. Part Names And General Specifications
4.1 TOPRW0500WD 4.1.1 External Dimension Model F1(mm) F2(mm) S1 (mm) S2 (mm) R1(mm) R2(mm) TOPRW0500WD 41.8 35.8 4.1.2 Front Part Names and Specifications M2I Corporation 9 / 23 M2I Bldg, 35-11, Jeonpa-ro 24beon-gil, Manan-gu, Anyang-si, Gyeonggi-do, 430-857, Korea. Tel :+82-70-465-3366,Fax:+82-31-465-3355 www.m2i.co.kr... - Page 10 DIP Switch 2Digit Set Up System Switch ⑩ Reset Switch Tact Switch System Reset Switch ⑪ Diagnose Connector 2mm 4P Diagnose System (Manufacturer Only) M2I Corporation 10 / 23 M2I Bldg, 35-11, Jeonpa-ro 24beon-gil, Manan-gu, Anyang-si, Gyeonggi-do, 430-857, Korea. Tel :+82-70-465-3366,Fax:+82-31-465-3355 www.m2i.co.kr...
-
Page 11: Toprw0700Wd
4.2 TOPRW0700WD 4.2.1 External Dimension Model F1(mm) F2(mm) S1 (mm) S2 (mm) R1(mm) R2(mm) TOPRW0700WD 45.6 39.6 4.2.2 Front Part Names and Specifications M2I Corporation 11 / 23 M2I Bldg, 35-11, Jeonpa-ro 24beon-gil, Manan-gu, Anyang-si, Gyeonggi-do, 430-857, Korea. Tel :+82-70-465-3366,Fax:+82-31-465-3355 www.m2i.co.kr... - Page 12 DIP Switch 2Digit Set Up System Switch ⑩ Reset Switch Tact Switch System Reset Switch ⑪ Diagnose Connector 2mm 4P Diagnose System (Manufacturer Only) M2I Corporation 12 / 23 M2I Bldg, 35-11, Jeonpa-ro 24beon-gil, Manan-gu, Anyang-si, Gyeonggi-do, 430-857, Korea. Tel :+82-70-465-3366,Fax:+82-31-465-3355 www.m2i.co.kr...
-
Page 13: Toprw1000Wd
4.3 TOPRW1000WD 4.3.1 External Dimension Model F1(mm) F2(mm) S1 (mm) S2 (mm) R1(mm) R2(mm) TOPRW1000WD 64.7 58.7 4.3.2 Front Part Names and Specifications M2I Corporation 13 / 23 M2I Bldg, 35-11, Jeonpa-ro 24beon-gil, Manan-gu, Anyang-si, Gyeonggi-do, 430-857, Korea. Tel :+82-70-465-3366,Fax:+82-31-465-3355 www.m2i.co.kr... - Page 14 DIP Switch 2Digit Set Up System Switch ⑩ Reset Switch Tact Switch System Reset Switch ⑪ Diagnose Connector 2mm 4P Diagnose System (Manufacturer Only) M2I Corporation 14 / 23 M2I Bldg, 35-11, Jeonpa-ro 24beon-gil, Manan-gu, Anyang-si, Gyeonggi-do, 430-857, Korea. Tel :+82-70-465-3366,Fax:+82-31-465-3355 www.m2i.co.kr...
-
Page 15: Chapter 5. External Device Interface
VCC GND Power Ground Not Available *1 When need VCC for external equipment , use 7.VCC and 8.VCC GND that output is 0.2A. M2I Corporation 15 / 23 M2I Bldg, 35-11, Jeonpa-ro 24beon-gil, Manan-gu, Anyang-si, Gyeonggi-do, 430-857, Korea. Tel :+82-70-465-3366,Fax:+82-31-465-3355 www.m2i.co.kr... -
Page 16: Com2 Connector Pin No. And Signal Name
Do not use HUB, when it is connected directly, Cross Cable should be used. Ex) Cross Cable Wiring: In the above wiring diagram, TD+ and RD+ are changed, and TD- and RD- are exchanged. M2I Corporation 16 / 23 M2I Bldg, 35-11, Jeonpa-ro 24beon-gil, Manan-gu, Anyang-si, Gyeonggi-do, 430-857, Korea. Tel :+82-70-465-3366,Fax:+82-31-465-3355 www.m2i.co.kr... -
Page 17: Usb Communication Specifications
(3) Be sure that heat from surrounding equipment does not cause product to exceed its standard operating temperature (4) When you don’t see within 30°, you may not see clearly. M2I Corporation 17 / 23 M2I Bldg, 35-11, Jeonpa-ro 24beon-gil, Manan-gu, Anyang-si, Gyeonggi-do, 430-857, Korea. Tel :+82-70-465-3366,Fax:+82-31-465-3355 www.m2i.co.kr... -
Page 18: Installation Procedure
Make a panel cut which product is mounted and insert the product to the panel form the front side. The Size of Panel Cut Making the Panel Cut (Mounting Size) per each TOPRW Series as below Table, Before Installation. Model... -
Page 19: Chapter 7. Wiring
(2) The Power terminal should have the following specification Caution : The use of the Pin Terminal when installing the power supply and ground terminal is M2I Corporation 19 / 23 M2I Bldg, 35-11, Jeonpa-ro 24beon-gil, Manan-gu, Anyang-si, Gyeonggi-do, 430-857, Korea. Tel :+82-70-465-3366,Fax:+82-31-465-3355 www.m2i.co.kr... -
Page 20: Ground Wiring
Class 3 ground (4) Use the cable more than 4 mm . Put the point of the ground near product and shorten Ground line. M2I Corporation 20 / 23 M2I Bldg, 35-11, Jeonpa-ro 24beon-gil, Manan-gu, Anyang-si, Gyeonggi-do, 430-857, Korea. Tel :+82-70-465-3366,Fax:+82-31-465-3355 www.m2i.co.kr... -
Page 21: Chapter 8. Maintenance
Check the touch pad there is no damage, scratch or pollution by eye. 8.3 Problems with the Device a. If there is a problem during operation, stop using it and contact the A/S department of M2I Corporation, which is indicated on the product label. -
Page 22: System Recovery Settings Switch
"RECOVERY". c. When the recovery is completed, the buzzer sounds, then turn off the power and reset to "BOOT UP" state. M2I Corporation 22 / 23 M2I Bldg, 35-11, Jeonpa-ro 24beon-gil, Manan-gu, Anyang-si, Gyeonggi-do, 430-857, Korea. Tel :+82-70-465-3366,Fax:+82-31-465-3355 www.m2i.co.kr... -
Page 23: Chapter 9. Products And Warning Label Location
Inside Cell: Model Name MS920SE (Rechargeable lithium Battery/irreplaceable) Serial Number: Copyright: M2I corporation 2018.1 www.m2i.co.kr M2I Bldg, 35-11, Jeonpa-ro 24beon-gil, Manan-gu, Anyang-si, Gyeonggi-do, 430-857, Korea M2I Corporation 23 / 23 M2I Bldg, 35-11, Jeonpa-ro 24beon-gil, Manan-gu, Anyang-si, Gyeonggi-do, 430-857, Korea. Tel :+82-70-465-3366,Fax:+82-31-465-3355 www.m2i.co.kr...
