TOPRE Series Hardware Manual
M2I Corporation
Industrial HMI Touch Panel
TOPRE Series
Hardware Manual
Thank you for purchasing the industrial HMI touch panel series of M2I corporation.
Please read this manual carefully to know installing, wiring, operating this equipment for safe use of this
product.
M2I Corporation
1 / 20
11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for M2I TOPRE Series
Summary of Contents for M2I TOPRE Series
- Page 1 Industrial HMI Touch Panel TOPRE Series Hardware Manual Thank you for purchasing the industrial HMI touch panel series of M2I corporation. Please read this manual carefully to know installing, wiring, operating this equipment for safe use of this product. M2I Corporation 1 / 20 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr...
-
Page 2: Table Of Contents
8.3 Problems with the Device ............................18 Chapter 9. Products and Warning Label Location ..........................19 Chapter 10. Products Label ....................................20 M2I Corporation 2 / 20 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 3: Chapter 1. Safety Precautions
Tighten the terminal screw with the specified torque. If the screws of terminal are loose, It could result in short circuit, fire, malfunctions. FG Terminal must be used a dedicated ground. Not doing so could M2I Corporation 3 / 20 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... - Page 4 ■ All field-wiring connections to this unit shall be from Limited Voltage / Limited Current, below 24 Vdc isolated secondary source with an output fuse, or Class 2. M2I Corporation 4 / 20 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr...
-
Page 5: Chapter 2. Overview
Figure Quantity Process Module Manual Clamp Power Connector USB Memory USB Cable Accessories User Options (Sold separate) SD Card Front Protect Sheet M2I Corporation 5 / 20 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... - Page 6 S : SVGA (800*600) X : XGA (1024*768) W : WQVGA (480*272) WVGA (800*480) *Product Wide model resolution - TOPRE0400WD: WQVGA - TOPRE0700WD: WVGA M2I Corporation 6 / 20 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr...
-
Page 7: Chapter 3. General Specifications
Protection Classification Conform to IP65 3.4 Structure Specifications TOPRE0300QD TOPRE0400WD TOPRE0700WD Weight 0.28 0.28 0.62 Cooling System Natural Air Circulation Case Material PC(Flameless) M2I Corporation 7 / 20 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 8: Chapter 4. Part Names And General Specifications
4.1.1 External Dimension Model F1(mm) F2(mm) S1 (mm) S2 (mm) R1(mm) R2(mm) TOPRE0300QD 128.6 102.6 118.7 92.7 TOPRE0400WD 4.1.2 Front Part Names and Specifications M2I Corporation 8 / 20 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... - Page 9 TB 5mm 3P Power Supply of Main Unit(DC 24V) ⑧ Reset Switch Tact Switch System Reset Switch ⑨ Built-in cover Cover for manufacturer maintenance M2I Corporation 9 / 20 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr...
-
Page 10: Topre0700Wd
4.2.1 External Dimension Model F1(mm) F2(mm) S1 (mm) S2 (mm) R1(mm) R2(mm) TOPRE0700WD 206.5 136.5 36.7 194..3 124.3 4.2.2 Front Part Names and Specifications M2I Corporation 10 / 20 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... - Page 11 TB 5mm 3P Power Supply of Main Unit(DC 24V) ⑧ Reset Switch Tact Switch System Reset Switch ⑨ Built-in cover Cover for manufacturer maintenance M2I Corporation 11 / 20 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr...
-
Page 12: Chapter 5. External Device Interface
COM2: RS-422/485 Receive Data (-) Signal Ground SDA(SD+) Output COM2: RS-422/485 Send Data(-) VCC GND Power Ground SDB(SD-) Output COM2: RS-422/485 Receive Data (-) M2I Corporation 12 / 20 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 13: Pin Layout
EHCI/OHCI Specification Version 1.0, USB2.0/1.1 compatible Communication Method Control/Bulk Transfer Speed 480Mb/s Support Device USB Storage (FAT16/FAT32 File Format Available) Connector Type Type A(1ch) M2I Corporation 13 / 20 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 14: Usb Otg
(5) In order to minimize external mechanical hazards, please control the mechanical hazards of the surrounding environment. -10 ~ 50°C, 10~80% -10 ~ 50°C, 10~80% M2I Corporation 14 / 20 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 15: Installation Procedure
Make a panel cut which product is mounted and insert the product to the panel form the front side. The Size of Panel Cut Making the Panel Cut (Mounting Size) per each TOPRE Series as below Table, Before Installation. Model A (mm) -
Page 16: Chapter 7. Wiring
Pin Terminal as below may cause explosion due to spark due to abnormal cable loss. Therefore, please be sure to familiarize yourself with how to use Pin Terminal below. 1.8~2.0 22~18 12~14 3.3~3.8 2~2.5 M2I Corporation 16 / 20 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 17: Chapter 8. Maintenance
Is the operating humidity within the allowable range (10%~80%RH)? c. Is the Surrounding pollution no corrosive gas? (2) Power Is the input voltage within the change range (-15%~+10%)? M2I Corporation 17 / 20 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 18: Problems With The Device
Check the touch pad there is no damage, scratch or pollution by eye. 8.3 Problems with the Device a. If there is a problem during operation, stop using it and contact the A/S department of M2I Corporation, which is indicated on the product label. -
Page 19: Chapter 9. Products And Warning Label Location
TOPRE Series Hardware Manual 8.4.2 TOPRE0700WD Chapter 9. Products and Warning Label Location 1. TOPRE0300QD / TOPRE0400WD Product Label 2. TOPRE0700WD Product Label M2I Corporation 19 / 20 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 20: Chapter 10. Products Label
Power Specifications: TOPRE03/04/07…24Vdc, 12W KC Certificate No.: Inside Cell: Model Name MS920SE(Rechargeable lithium Battery/No need for replacement) Serial Number: Copyright: M2I corporation 2020.11 www.m2i.co.kr M2I Corporation 20 / 20 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr...
