TOPR Series (Process Module) Hardware Manual
M2I Corporation
Industrial HMI Touch Panel
TOPR Series (Process Module)
Hardware Manual
Thank you for purchasing the industrial HMI touch panel series of M2I corporation.
Please read this manual carefully to know installing, wiring, operating this equipment for safe use of this
product.
M2I Corporation
1 / 18
11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for M2I TOPR Series
Summary of Contents for M2I TOPR Series
- Page 1 Industrial HMI Touch Panel TOPR Series (Process Module) Hardware Manual Thank you for purchasing the industrial HMI touch panel series of M2I corporation. Please read this manual carefully to know installing, wiring, operating this equipment for safe use of this product.
-
Page 2: Table Of Contents
5.2 Ethernet Interface ............................13 5.3 USB Interface ............................... 14 5.4 WIFI Interface .............................. 14 Chapter 6. Installation ............................... 15 Chapter 7. Wiring ................................15 M2I Corporation 2 / 18 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... - Page 3 7.2 Ground wiring ............................. 16 Chapter 8. Maintenance ..............................17 Chapter 9. Products and Warning Label Location....................18 Chapter 10. Products Label ............................. 18 M2I Corporation 3 / 18 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr...
-
Page 4: Chapter 1. Safety Precautions
The output signal or communication lines should be separated from the power line or high tension wire. They should be installed 100mm (3.94 Inch) or more from each other. M2I Corporation 4 / 18 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 5: Wiring Precautions
■ All field-wiring connections to this unit shall be from Limited Voltage / Limited Current, below 24 Vdc isolated secondary source with an output fuse, or Class 2. M2I Corporation 5 / 18 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 6: Chapter 2. Overview
Item Figure Quantity Process Module Manual Power Connector USB Memory USB Cable Accessories (Sold separate) User Options SD Card Front Protect Sheet M2I Corporation 6 / 18 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 7: Explanation Of Model Name
20 : Premium V : VGA (640*480) 15 : 15” S : SVGA (800*600) X : XGA (1024*768) W: WQVGA (480*272) WVGA (800*480) M2I Corporation 7 / 18 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 8: Chapter 3. General Specifications
Protection Classification IP2X (Display Module : IP65) 3.4 Structure Specifications Dimension(㎜) 201.6X147.6X39.8 Weight(㎏) 0.8kg Cooling System Natural air circulation Case Material AL(Aluminium) M2I Corporation 8 / 18 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 9: Chapter 4. Parts Identification And Functions
TOPR Series (Process Module) Hardware Manual Chapter 4. Parts Identification and Functions 4.1 External Dimension 4.2 Front Part Names and Specifications M2I Corporation 9 / 18 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 10: Right Part Names And Specifications
TOPRP20 Supports NTSC, PAL, SECAM Connect to Extension Speaker ④ Audio Headphone Jack TOPRP20 Supports WAV 4.4 TOP Part Names and Specifications M2I Corporation 10 / 18 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 11: Bottom Part Names And Specifications
RS-232C/422/485 Serial Comm. with PLC (Switchable the Comm. Via Software) ③ COM2 Connector DSUB9 RS-232C/422/485 Serial Comm. with PLC (Switchable the Comm. Via Software) M2I Corporation 11 / 18 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 12: Chapter 5. Interface
SDB(SD-) Output RS-422/485 Send Data (-) *1 When need VCC for external equipment, use 7.VCC and 8.VCC Gnd that output is 0.2A M2I Corporation 12 / 18 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 13: Ethernet Interface
Green/White Blue Not Available in 10BaseT Blue/White Not Available in 10BaseT Green Brown/White Not Available in 10BaseT Brown Not Available in 10BaseT M2I Corporation 13 / 18 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 14: Usb Interface
64QAM , 16QAM , QPSK, BPSK CCK ,DQPSK , DBPSK Encryption WEP40/64, WEP104/128, AES , TKIP Antenna RP-SMA External Antenna Link configuration AD Hoc , Infrastructure Mode SoftAP, Client M2I Corporation 14 / 18 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 15: Chapter 6. Installation
Temperature rating of the field 65 ℃ Only installed conductors (2) The Power terminal should have the following specification 1.8~2.0 22~18 12~14 3.3~3.8 2~2.5 M2I Corporation 15 / 18 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 16: Ground Wiring
Is the operating temperature within the allowable range(-10°C~50°C)? b. Is the operating humidity within the allowable range(10%~80%RH)? c. Is the Surrounding pollution no corrosive gas? M2I Corporation 16 / 18 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 17: Chapter 8. Maintenance
Check the touch pad there is no damage, scratch or pollution by eye. 8.3 Problems with the Device a. If there is a problem during operation, stop using it and contact the A/S department of M2I Corporation, which is indicated on the product label. -
Page 18: Chapter 9. Products And Warning Label Location
Copyright: M2I corporation 2020.11 www.m2i.co.kr - When using M2I equipment, thoroughly read this datasheet and associated manuals introduced in this datasheet, also pay careful attention to safety and handle the module properly. - Store this datasheet in a safe place so that you can take it out read it whenever necessary.
