Industrial HMI Touch Panel Hardware Manual
M
I Corporation
2
Industrial HMI Touch Panel
TOPRT -Ex Series
Hardware Manual
Thank you for purchasing the industrial HMI touch panel series of M2I corporation.
Please read this manual carefully to know installing, wiring, operating this equipment for safe use of this
product.
M
I Corporation
1 / 23
2
11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea,
Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr
Advertisement
Table of Contents
Related Manuals for M2I TOPRT-Ex Series
Summary of Contents for M2I TOPRT-Ex Series
- Page 1 Industrial HMI Touch Panel TOPRT -Ex Series Hardware Manual Thank you for purchasing the industrial HMI touch panel series of M2I corporation. Please read this manual carefully to know installing, wiring, operating this equipment for safe use of this product.
-
Page 2: Table Of Contents
8.3 Problems with the Device ............................21 8.4 Setting System Recovery Mode ..........................21 Chapter 9 Product and Warning Label............................22 Chapter 10 Product Label ..................................23 I Corporation 2 / 23 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 3: Chapter 1 Safety Precautions
The output signal or communication lines should be separated from the power line or high tension wire. They should be installed 100mm (3.94 Inch) or more from each other. I Corporation 3 / 23 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... - Page 4 ■ All field-wiring connections to this unit shall be from Limited Voltage / Limited Current, below 20~28 Vdc isolated secondary source with an output fuse, or Class 2 secondary circuits. I Corporation 4 / 23 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr...
-
Page 5: Chapter 2 Overview
Power Connector and COM3 communication connector USB Cable Clamp Cable Tie USB Memory USB Cable Accessories User Option (Sold separate) SD Card Front Protect Sheet I Corporation 5 / 23 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 6: Explanation Of Model Name
Display Module TOPRT1210SD-Ex (TOPRP10D + TOPRD1220X) 15W or less TOPRT1230XD-Ex (TOPRP10D + TOPRD1230X) 18W or less TOPRT1240XD-Ex (TOPRP50D + TOPRD1230X) 18W or less I Corporation 6 / 23 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 7: Display Specifications
0 ~ 90(No dew) Atmosphere No corrosive gas Protection Classification Front IP54, Rear IP2X) 3.7 Structure Specifications Cooling System Natural air circulation Case Material AL(Aluminum) I Corporation 7 / 23 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 8: Chapter 4 Part Names And General Specifications
Industrial HMI Touch Panel Hardware Manual Chapter 4 Part Names and General Specifications 4.1 TOPRT1210SD-Ex 4.1.1 TOPRT1210SD-Ex External Dimension Product A(mm) B(mm) C(mm) D(mm) TOPRT1210SD-Ex 66.5 I Corporation 8 / 23 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 9: Toprt1230Xd-Ex / Toprt1240Xd-Ex
⑦ Touch Panel Analog resistive touch sensor Common ⑧ USB OTG Cover Front USB OTG cover hole Common 4.2 TOPRT1230XD-Ex / TOPRT1240XD-Ex I Corporation 9 / 23 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... - Page 10 Analog / Capacitive resistive touch sensor ⑧ USB Cover Front USB cover hole Common ⑨ USB OTG Program upload or download Common I Corporation 10 / 23 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr...
-
Page 11: Toprt12-Ex Series-Rear Part Names And Specifications
Cover open / close detection ⑤ Mode Switch DIP Switch 2P Set Up System Mode ⑥ Reset Switch Tact Switch System reset Switch I Corporation 11 / 23 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 12: Toprt12-Ex Series- Bottom Part Names And Specifications
Data Bit 7, 8 bit Data Type Parity Bit NONE, ODD, EVEN Parity Stop Bit 1, 2 bit Modular Jack DSUB 9Pin I Corporation 12 / 23 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 13: Ethernet Communication Specifications
TOPRT1230XD-Ex, TOPRT1240XD-Ex 10M / 100Mbps / 1Gbps Communication Method Base Band Switching Method AUTO MDIX Maximum Segment Length 100M (Hub between product) I Corporation 13 / 23 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 14: Usb Interface
Windows 98SE/2000/XP/VISTA/7/10(32/64bit) Cable Length 1.5m Connector Type Micro USB AB, Female Connection Method Through USB Connector on Front Side of Display Module I Corporation 14 / 23 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 15: Chapter 6 Installation
Insert Process Module to Guide of Rear of Display Module and Mount with Bolts included in Package. (Bolt Size: M4 X 8L, 0.2N.m) I Corporation 15 / 23 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 16: Installation Procedure
(1) The Size of Panel Cut (Mounting Place) Making the Panel Cut (Mounting Size) per each model as below Table, Before Installation. I Corporation 16 / 23 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... - Page 17 0.8N.m screwdriver torque. Caution: IP performance cannot be secured if the clamp is not tightened with a tightening force of 0.8N.m. I Corporation 17 / 23 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr...
-
Page 18: Front Usb
Conductor type Simple or Stranded wire Bolt torque ≥ 0.8N.m Conductor length Temperature rating of the field installed conductors 65℃ or under I Corporation 18 / 23 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 19: Ground Wiring
(3) When not doing the exclusive ground, do common ground like figure B. (4) Use the cable width more than 2mm . Put the point of the ground near product and shorten Ground line. I Corporation 19 / 23 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 20: Cable Clamp Installation
(3) Tighten cable clamp and USB cable with the cable tie sufficiently and check that the USB connector is not pulled out by external force. I Corporation 20 / 23 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 21: Chapter 8 Maintenance
Check the touch pad there is no damage, scratch or pollution by eye. 8.3 Problems with the Device a. If there is a problem during operation, stop using it and contact the A/S department of M2I, which is indicated on the product label. -
Page 22: Chapter 9 Product And Warning Label
Industrial HMI Touch Panel Hardware Manual Chapter 9 Product and Warning Label I Corporation 22 / 23 11-35, Simin-daero 327beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do 14055, Korea, Tel: +82-70-465-3366, Fax: +82-31-465-3355, www.m2i.co.kr... -
Page 23: Chapter 10 Product Label
Protections * Model Name: **Power: - TOPRT1210SD-Ex: - TOPRT1230XD-Ex: - TOPRT1240XD-Ex: *** These can be different depends on each model. Before model selection, make sure the details to M2I. Copyright: M I corporation 2023.09 www.m2i.co.kr Document No: TOPRT-D0008 Rev.0 - When using M2I equipment, thoroughly read this datasheet and associated manuals introduced in this datasheet, also pay careful attention to safety and handle the module properly.
