2. Open the top cover of the PEX2PCI4 Expansion Box by removing the screws.
There are four PCI slots in the Expansion Box. Find an unused slot, remove the "blank" PCI
card bracket that was pre-installed from the factory.
Insert the PCI card(s) you wish to install, into the available PCI slots, then replace the top
cover of the Expansion Box.
3. Connect the DVI-like* connector on the EC2PCI ExpressCard Host
Adapter Card to the DVI-like port on the rear panel of the PEX2PCI4
Expansion Box.
4. Connect the AC Power Adapter to the power port (situated to the left
of the DVI-like input) on the rear panel of the PEX2PCI4 main unit.
5. Turn on the Expansion Box power using the power switch next to the
Expansion Cable, then power on the PC system
6. Connect the remaining end of the EC2PCI ExpressCard Host Adapter
Card into the unused ExpressCard expansion slot of the host
computer, then power on the host computer.
