Removable 2.5" SATA HDD Backup System
SAT2510U3REM
SAT2510U3S
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 10/03/2013
*actual product may vary from photos
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for StarTech.com SAT2510U3S
Summary of Contents for StarTech.com SAT2510U3S
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 10/03/2013...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
-
Page 3: Table Of Contents
Packaging Contents ..........................1 System Requirements ..........................1 Installation ....................2 Installing a Hard Drive into SAT2510U3S ..................2 Installing the Drive Bay into the Computer ..................3 Connecting the Removable Drive Enclosure – Internal ............. 5 Using SAT2510U3S Externally ....................... 5 Using the Storage Device ..............5... -
Page 4: Introduction
Introduction The SAT2510U3REM/SAT2510U3S Removable 2.5” SATA HDD Backup System/Mobile Rack for 3.5”/5.25” Front Bay turns a 2.5” SATA HDD/SSD drive into a removable hard drive that can also be used externally as a normal USB 3.0 enclosure. The 2.5” SATA removable hard drive bay can be mounted into any computer’s 3.5”... -
Page 5: Installation
WARNING: Hard drives, like all computer equipment can also be severely damaged by static electricity. Be sure that you are properly grounded before opening your computer case or touching any components. StarTech.com recommends that you wear an anti-static strap when installing any computer equipment. If an antistatic strap is unavailable, discharge yourself of any static electricity build-up by touching a large grounded metal surface (such as the computer case) for several seconds. -
Page 6: Installing The Drive Bay Into The Computer
2. Attach the 2.5” SATA hard drive to the circuit board, and fasten it to the board from the bottom using the provided mounting screws. 3. Once the hard drive has been secured to the circuit board, carefully slide the circuit board (with hard drive attached) into the drive enclosure housing. - Page 7 4. Remove the side cover(s) from the computer case and the cover to the front bay you wish to mount the Drive Bay into (see documentation for your computer system for details). 5. Insert the Drive Bay into the front bay slot as appropriate (see documentation for your computer system for details).
-
Page 8: Connecting The Removable Drive Enclosure - Internal
Improper usage may result in data loss or damage to the drive. Using SAT2510U3S Externally Use the provided USB A to B cable to connect the SAT2510U3S to a USB 3.0 host port. Using the Storage Device Windows XP/Vista/7/8 If you are using brand new hard drives that do not contain any data, then you will first need to prepare the hard drive for use before you can write data to it. - Page 9 Locate the Disk that says it is “Unallocated” (check hard drive capacity to confirm it’s the correct hard drive) and then right-click in the section that says “Unallocated” and select “New Partition”. The New Partition Wizard will appear. Follow the instructions in the wizard to complete setting up the drive.
-
Page 10: Specifications
Specifications Number of Hard Drives Supported 1 x 2.5” SATA revision 3.x Host Interface SuperSpeed USB 3.0 ASMedia ASM1053 Chipset ID ASMedia ASM1456 Drive Bay: 1 x 7-pin SATA port 1 x 4-pin SP4 small Floppy male External Connectors Enclosure: 1 x USB 3.0 micro-B female 1 x 7+15 pin SATA data+power port LEDs... -
Page 11: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 12 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
