1-Bay 2.5in SATA/SAS Hard Drive Backplane
SATSASBP125
*actual product may vary from photos
FR: Guide de l'utilisateur - fr.startech.com
DE: Bedienungsanleitung - de.startech.com
ES: Guía del usuario - es.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
IT: Guida per l'uso - it.startech.com
JP: 取扱説明書 - jp.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 03/20/2018
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for StarTech.com SATSASBP125
Summary of Contents for StarTech.com SATSASBP125
- Page 1 DE: Bedienungsanleitung - de.startech.com ES: Guía del usuario - es.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com IT: Guida per l’uso - it.startech.com JP: 取扱説明書 - jp.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 03/20/2018...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
-
Page 3: Table Of Contents
Table of Contents Product Diagram ..................1 Front View ..............................1 Rear View ..............................1 Introduction ....................2 Packaging Contents ..........................2 System Requirements ..........................2 Hardware Installation ................3 Hard Drive Installation ................4 Specifications ..................8 Technical Support ..................9 Warranty Information ................9 Instruction Manual... -
Page 4: Product Diagram
Product Diagram Front View 1. Power button 2. 1x 2.5” Drive bay/tray 3. 1x 2.5” Drive bay key hole 4. 1x Drive Tray Release Latches Rear View 1. 1x SATA power connector port 2. 1x SATA data connector port Instruction Manual... -
Page 5: Introduction
Introduction Packaging Contents • 1x 1-Bay 2.5in SATA/SAS Hard Drive Backplane • 2x Drive bay keys • 1x 2.5” HDD/SSD Drive Tray • 1x SATA cable • 4x Drive mounting screw kit • 4x Backplane mounting screw kit • 1x Instruction Manual System Requirements •... -
Page 6: Hardware Installation
WARNING! Hard drives and storage docks require careful handling, especially when being transported. If you are not careful with your hard disk, lost data may result. Always handle your hard drive and storage device with caution. Be sure that you are properly grounded by wearing an anti-static strap when handling computer components or discharge yourself of any static electricity build-up by touching a large grounded metal surface (such as the computer case) for several seconds. -
Page 7: Hard Drive Installation
4. Connect the included SATA data cable from an available SATA/SAS host ports on your motherboard to the SATA/SAS data connector port on the back of the Backplane. 5. Connect a SATA Power connector from your power supply to the SATA power connector port on the back of the backplane. - Page 8 3. Slide the drive tray with installed hard drive back into the slot and close the door. Instruction Manual...
- Page 9 4. (Optional) If you would like to lock the drive door for added security, use the key to turn the key counter clockwise into the locked position. Instruction Manual...
-
Page 10: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. -
Page 11: Specifications
