Moog LABYRINTH User Manual page 40

PATCH BAY
(Continued)
M VCO 1V/OCT
VCA
ROW TWO
BLEND
M VCO
NOISE
M VCO 1V/OCT
This is a calibrated CV input that controls the frequency of the triangle wave
MOD VCO following the 1 Volt per Octave standard. It is summed with the
setting of the MOD VCO FREQUENCY panel control.
CV INPUT: –5V to +5V
VCA
Labyrinth's audio output at Eurorack level (10 Vpp)
AUDIO OUTPUT: –5V to +5V (10V peak to peak)
BLEND
This CV input is for the BLEND crossfader. It sums with the BLEND
panel control.
CV INPUT: –5V to +5V
M VCO
Output for the MOD VCO
AUDIO/CV OUTPUT: –5V to +5V
NOISE
Audio output for the variable-tone NOISE generator
AUDIO OUTPUT: –5V to +5V
