11.4.14

NMEAPNCTGST (ACSII)

This message satisf ies the UKOOA compliance requirements by starting with the standard NMEA GST message
and scaling all error statistics by 1.96, and by adding a value f or the F-Test of Unit Variance.

Table 50: PNCTGST Message Output Format

Output
$PNCTGST,time,rms,majoraxis,minoraxis,orientation,lateer,loner,alterr,f isher*chec
Format:
ksum
Field#
Field Name
F1
time
F2
rms
F3
Majoraxis*
F4
Minoraxis*
F5
orientation
F6
Laterr*
F7
Loner*
F8
Alter*
F9
f isher
F10
*Indicates the result is scaled by 1.96. This output stream reports pseudo -range noise statistic inf ormation and
is in compliance with NMEA-0183 Standards version 3.0.
Examples:
$GNGST,192518.00,0.3762,0.1054,0.0953,074.8583, 0.0960,0.1048, 0.2168*7A
$PNCTGST,193028.00,0.2993, 0.1722,0.1448, 084. 7181,0.1451,0. 1720,0.3391,1*65
11.4.15

NMEAPNCTMDE (ASCII)

This output stream reports the Marginally Detectable Error (MDE) generated by the receiver as part of the self -
monitoring duties perf ormed to support Receiver Autonomous Integrity Monitoring (RAIM).
proprietary NMEA type message, and it conf orms to the header, checksum and electrical characteristics of a
standard NMEA string, but is not recognized by the NMEA governing body as an of f icially sanctioned message.

Table 51: PNCTMDE Message Output Format

Output
$PNCTMDE,time,svid,Type,bias,mde,laterr,longerr,alterr,*checksum
Format:
Field#
Field Name
F1
time
F2
svid
F3
Type
CNAV-MAN-061
Revision B
C-NavX1 GNSS Receiver User Manual
Description
UTC time f or position f ix in hours, minutes, seconds
(hhmmss.ss) (000000.00 to 235959.99)
Total RMS standard deviation of ranges inputs to the navigation
solution
Standard deviation of semi-major axis of error ellipse in meters
Standard deviation of semi-minor axis of error ellipse in meters
Orientation of semi-major axis of error ellipse in true north degrees
(0 to 180°)
Standard deviation of latitude error in meters
Standard deviation of longitude error in meters
Standard deviation of altitude error in meters
Fisher Test Result
Checksum
Description
UTC time f or position f ix in hours, minutes, seconds
(hhmmss.ss) (000000.00 to 235959.99)
The GNSS svid
Measurement type: 0 = CA, 1 = P1, 2 = L1, 3 = P2, 4 = L2, 5 =
RCCode, 6 = RC PHASE
DOC-TEM-28-NUM Rev A Uncontrolled copy when printed
It is a C -Nav
C-Nav
Page 90 of 111
