11.2.6 Paddle LTE Antenna Specifications
Table 35: Paddle LTE Antenna Specification Sheet
Part Number
RF Specifications
Polarization
Frequency bands:
Gain ( LEO):
VSWR Port 1 & 2:
Input Impedance
Environmental
Operating Temperature
Storage Temperature
Mechanical
Cable Connector
Dimensions
Mounting
CNAV-MAN-061
Revision B
C-NavX1 GNSS Receiver User Manual
CNV-A-LTE-PAD-1
Linear Vertical
824 – 2700 MHz
≤3.0 dBi
≤3.0 across 92% of the band
50 Ohms (Nominal)
-20 C to + 80 C (-40 F to 176 F)
-20 C to + 80 C (-40 F to 176 F)
Direct Mount (SMA)
190 x 16 mm
N/A
